Introduction
Frame screen series
More smooth, more delicate, clearer
Screen fabric is optional
+ Micropore acoustic transparent screen
+
4K woven acoustic transparent screen
+
Woven acoustic transparent screen
+
1.1 Gain white flexible screen
+
Matellic acoustic transparent screen
+
Matellic flexible screen
+
HD grey flexible screen
+
Matellic hard screen
+
Rear hard screen
Exquisite manufacturing process+delicate appearance
Spend all our efforts, create exquiste products!
This frame screen adopts aluminum alloy frame. The four angles are connected with the way of 45
°
splicing,
thus it is tight. With ultra velvet surface, the aluminum alloy frame can prevent reflection caused by
projection. Populated precision spring device adjusts the tension of screen surface from all angles. If there
is shrinking because of temperature and humidity, the device can stretch the screen to avoid ripples. The
smoothness is very advantageous. The screen is easy to install so you can install it by yourself. What' s
more, the screen position can be adjusted in the transverse direction after installation.
2
Introduction
Curve frame screen series
Advantages of XV curve frame screen
First, the curved shape looks more beautiful, in line with the modern aesthetics.
More comfortable, More stereo, More shocking effect
Screen fabric is optional
+
Micropore acoustic transparent screen
+
4K woven acoustic transparent screen
+
Woven acoustic transparent screen
+
1.1 Gain white flexible screen
+
Matellic acoustic transparent screen
+
Matellic flexible screen
+
HD grey flexible screen
+
Matellic hard screen
Second, the curved structure can obtain larger display area in a limited space. For example, a place with 3 meters in width can only holds a 128-inch flat frame screen,
but it can holds a 130 inches curved frame screen.
Third, viewing angle is wider. Curved design brings the same visual enoyment whether it is the edge or center of the screen.
Fourth, ii bring more realistic stunning scene feeling. Its surface facing the audience is curved, as if people are surrounded by the projected image like curved
IMAX
screen. 3D display is immersive.
Fifth, human visual experience is more comfortable. Curved screen meets the spherical characteristics of human eye, enabling the distance from the eye to every
point on the screen is the same, eliminating visual distortion when looking at the edge of the screen, to create the most natural and comfortable feeling.
3
Introduction
Fixed frame screen 60B parameter
E
T.1--]-
E
i
O'
"'I
I
L_
lJ _t!l_
60B Frame sketch drawing
L(Screen)
H :
◄-•--·-•--·-·--· ·--·----·---;·_►
'f
Screen plan sketch
Ratio Size
80"
90"
100"
110"
120"
130"
16:9
135"
140'
150"
160"
170"
180'
100"
4:3 120"
150"
120"
2.35: 1 135"
150"
Projection area
W(mm)*H(mm)
1771 996
1992 1120
2213 1245
2435 1369
2656 1494
2877 1618
2988 1681
3099 1743
3320 1867
3542 1992
3763 2116
3984 2241
2032 1524
2438 1828
3048 2286
2804 1193
3155 1342
3505 1491
4
60B Fixed frame screen
Frame size Packing size Weighl(kg)
Frame length Frame height Frame
(Lsize) (Asiza) L(mm)*W(mm)*H(mm) G.W. N.W.
1891 1116 1985*214*87 6CM 8.3 5.4
2112 1240 2206*214*87 6CM 9.4 6.1
2333 1365 2427*214*87 6CM 10.4 6.9
2555 1489 2649*214*87 6CM 11.5 7.6
2776 1614 2870*214*87 6CM 12.6 8.4
2997 1738 3091 *214*87 6CM 15.8 9.9
3108 1801 3292*300*126 6CM 16.4 10.4
3219 1863 3403*300*126 6CM 17.1 10.8
3440 1987 3624*300*126 6CM 18.4 11.7
3662 2112 3846*300*126 6CM 20.6 13.4
3883 2236 4067*300*126 6CM 22 14.4
4104 2361 4288*300*126 6CM 23.5 15.5
2152 1644 2246*214*87 6CM 10.5 7.2
2558 1948 2652*214*87 6CM 12.7 8.8
3168 2406 3352*300*126 6CM 18.9 12.4
2924 1313 3018*214*87 6CM 14 8.5
3275 1462 3459*300*126 6CM 15.8 9.6
3625 1611 3809*300*126 6CM 18.4 11.5
Curve frame screen 60B parameter
Ratio Size
80"
90"
100"
110"
16:9 120"
135"
150"
160"
170"
1aa·
120"
4:3 150"
120"
2.35:1 135"
150"
J.--]-
Ei
o!
co!
1 __
! 35mml
;--------I
Planform
60B Frame sketch drawing
60B Curve frame screen
Projection area Frame size(chord length)(mm)
W(mm)*H(mm) Frame length(L) Frame height(A)
1771 996 1890 1116
1992 1120 2111 1240
2213 1245 2332 1365
2435 1369 2553 1489
2656 1494 2773 1614
2988 1681 3103 1801
3320 1867 3433 1987
3542 1992 3653 2112
3763 2116 3871 2236
3984 2241 4090 2361
2438 1828 2552 1948
3048 2286 3163 2406
2804 1193 2920 1313
3155 1342 3269 1462
3505 1491 3616 1611
5
Introduction
L/Screen\
H :
l<llf·--·-·--·----·- -----·-·--·-; __ ►
'f
Screen plan sketch
Frame Chord Camber Weight(kg)
chordlenath radius heiaht Frame
(mm) m (mm) G.W. N.W.
1891 12.9 34
6CM 8.3 5.4
2112 12.9 43
6CM 9.4 6.1
2333 12.9 52
6CM 10.4 6.9
2555 12.9 63
6CM 11.5 7.6
2776 12.9 74
6CM 12.6 8.4
3108 12.9 93
6CM 16.4 10.4
3440 12.9 114
6CM 18.4 11.7
3662 12.9 129
6CM 20.6 13.4
3883 12.9 145
6CM 22 14.4
4104 12.9 162
6CM 23.5 15.5
2558 12.9 63
6CM 12.7 8.8
3168 12.9 95
6CM 18.9 12.4
2924 12.9 82
6CM 14 8.5
3275 12.9 103
6CM 15.8 9.6
3625 12.9 127
6CM 18.4 11.5
42mm
80mm
100mm
52mm
100mm
52mm
