Elkay OBFAVRFRD Manuale di installazione

97571C (Rev. E - 11/04)

OBFAVRFRD

Page 1

Installation, Care & Use Manual

FIG. 1

27 SEE FIG. 6

26,29

23, 24, 25

933 38 9

OBFAVRFRD

Page 2

97571C (Rev. E - 11/04)

FIG. 2 *ADAREQUIREMENT

LEGEND

A=RECOMMENDEDWATERSUPPLYLOCATION 3/8O.D.UNPLATEDCOPPERTUBECONNECT STUB1-1/2IN.(38mm)OUT FROMWALLSHUTOFF BYOTHERS

B=RECOMMENDED LOCATIONFORWASTE OUTLET1-1/4”O.D. DRAIN

C=1-1/4TRAPNOTFURNISHED**

D=ELECTRICALSUPPLY(3) WIRERECESSEDBOX

E=INSURE PROPER VENTILATIONBYMAINTAINING6"(152 mm)(MIN.)CLEARANCEFROM CABINET LOUVERSTOWALL.

F=7/16 BOLTHOLESFORFASTENINGUNITTOWALL

FINISHEDFLOOR

97571C (Rev. E - 11/04)

OBFAVRFRD

Page 3

IMPORTANT

ALLSERVICE TOBE PERFORMEDBY AN AUTHORIZED SERVICE PERSON

HANGERBRACKETSANDTRAPINSTALLATION

1) Remove hanger bracket fastened to back of cooler by removing one screw.

2) Mount the hanger bracket and trap as shown in Figure 2.

NOTE: Hanger Bracket MUST be supported securely. Add fixture support carrier if wall will not provide adequate support.

IMPORTANT:

y7-3/4 in. (197mm) dimension from wall to centerline of trap must be maintained for proper fit.

yAnchor hanger securely to wall using all six 1/4 in. dia. mounting holes.

3) Install straight valve for 3/8" O.D. tube. INSTALLATION OF COOLER

4) Hang the cooler on the hanger bracket. Be certain the hanger bracket is engaged properly in the slots on the cooler back.

5) Loosen the two screws holding the lower front panel at the bottom of cooler base. Pull front panel forward to gain access

inside cooler.

6) Connect water inlet line - See Note 4 of General Instructions.

7) Remove the slip nut and gasket from the trap and install them on the cooler water line making sure that the end of the

waste line fits into the trap. Assemble the slip nut and gasket to the trap and tighten securely.

START UP

Also See General Instructions

8) Stream height is factory set at 35 PSI. If supply pressure varies greatly from this, adjust the screw on regulator item 15 by

using a small screwdriver through the small hole in the push button item 2 (See Fig.3). Clockwise adjustment will raise

stream and counter-clockwise adjustment will lower stream. For best adjustment stream should hit basin approximately

6-1/2" (165mm) from bubbler.

PROTECTFROMHARD FREEZING

9) If the ambient air temperature drops below 0° F, the cooler needs to be drained of all water by blowing out all water lines

and the drain trap.

FIG. 3

34 8

13 14

20 930 10

OBFAVRFRD

Page 4

97571C (Rev. E - 11/04)

PRINTED IN U.S.A.

PARTS LIST

PART NO

22897C

45662C

75672C

45663C

35906C

35907C

35909C

56033C

75500C

70864C

27469C

75566C

40045C

15005C

61313C

50986C

75532C

35900C

38417001

27295C

55996C

98118C

40614C

50400C

50401C

70444C

21903C

27306C

70016C

55931C

15009C

56092C

26999C

22814C

22822C

22854C

22862C

22955C

100322740560

400660943730

75519C

75520C

75674C

Panel - Bottom Dispenser

Button - Push

Screw - Cap

Sleeve - Push Button

Heater Strip

Switch - Rocker

Heater Thermostat Assy

Washer

Screw - Torx

Screw - #8 x 5/8” Lg. Torx/Slot

Panel - Screen

Screw - Torx

Hex Nut

Retaining - Nut

Regulator

Holder - Regulator

Screw

Power Cord

Screw - #8-18 x 3/8” HHSM

Panel - Front Dispenser

Strainer

Bubbler Assembly

DrainTube

Gasket - Drain

Ring Support - Drain

Clamp - Drain Gasket

Basin - Stainless Steel

Adaptor - Basin

Hex Nut #10-32

Cover-Dispenser Bottom Gray

Bubbler - Nipple

Poly Tubing (Cut To Length)

Cover - Bottom

Panel - LH No Push

Panel-RH No Push

Panel - LH Rear

Panel-RH Rear

Panel - Front Lower

Gasket

Hanger Bracket

Bit - Pinned Torx T-15

Bit - Pinned Torx T-25

Wrench - Allen 7/64

ITEM

NO DESCRIPTION

NOTE: All correspondence pertaining to any of the above water

coolers or orders for repair parts MUST include Model No. and

Serial No. of cooler, name and part number of replacement part.

WARNING!

This unit is frost resistant down to 0° F with no wind. Prevail-

ing winds can reduce the ability of the heater element to

preventlightfreezing. If the ambient air temperaturewilldrop

below 0° F, the cooler needs to be drained of all water by

blowing out all water lines and the drain trap.Aheater strip

is used to heat the unit and will begin to cycle at 40° +/- 5°

F. Acheck at this temperature will ensure the heater is

working and the unit is resistant to light freezing.

ALSO,MAKE SURE THERE ARENO PLASTIC OR

FLAMMABLECOMPONENTS DIRECTLYABOVETHE

HEATER STRIP.

FIG. 5

FIG.4

FIG. 6

www.DrinkingFountainDoctor.com 800-518-5388
