MX-1 New Baseplate Installation Guide

1

WARNING: Before you begin installing the new MX-1 baseplate, make sure that your MX-1 unit is not

plugged into anything else, including the optional ELMO Connect Box.

Fold up the MX-1 unit and flip it over so that

the baseplate is facing upwards and the

serial numbers are visible.

Using a screwdriver, carefully remove the 2

screws from the bottom of the baseplate.

The baseplate is magnetized and will not

come off until manually removed.

Take off the baseplate and screws. Do not

throw away your baseplate –you may

need the serial number for later reference.

Place the new MX-1 baseplate on the

bottom of the unit, making sure that it is

properly aligned with the unit.

Replace the 2 screws and screw them back

into the bottom of the new baseplate to

finish installation.

1

2

3

4

5

Bottom of baseplate

Bottom of baseplate

Top of folded MX-1

Bottom of MX-1

with new baseplate

MX-1 New Baseplate Installation Guide

2

To use the MX-1 Writing Board, slide the

baseplate of the MX-1 unit into one of the

two slots located on the bottom of the

Writing Board. This will keep the camera in

place as you write

The MX-1 Writing Board is now ready to be

used! Simply connect the MX-1 to the input

source of your choice.

When you are finished using the MX-1 and

Writing Board, the MX-1 unit can be folded

shut while it is still attached to the Writing

Board.

6

7

8
