INSTRUCTION MANUAL
Read all the instruction carefully before you use
the appliance and keep it for future use.
ReChARgeAbLe SUpeRbRIghT
QUARTzhALOgeNLANTeRN
31394c
• Swivel handle and stand • Weatherproof
• Equipped with a sealed lead acid battery
• Dual recharge, either AC/DC charger or 12v DC
car plug adaptor (both included)
• Camping, shing, hunting & outdoor uses.
1,000,000
CANdLe pOweR
SpOTLIghT
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed,
to reduce the risk of fire, electrical shock or injury, please read and understand all instructions
before using the spotlight.
WARNING
• Close supervision is necessary when any appliance is used by or near children. Do not allow to be
used as a toy.
• To protect against risk of electrical shock, do not put unit in water or other liquid.
• Do not put this unit in a re or near any ammable object as this may cause explosion.
• Do not use excessive force on the product as it may cause permanent damage to the unit.
• Unplug the charger from outlet before any routine cleaning or maintenance.
• Always keep the unit fully charged when not in use. Fully recharged, the battery can be stored for
up to 3 months without recharging. Storage of the unit for more than 6 months without recharging
can damage the battery.
• It is important to recharge the unit as soon as possible after each usage.
• Do not shine directly into eyes.
• The sealed battery in this unit contains lead and must be recycled or disposed of properly.
• Lens becomes very hot during operation. This is designed for intermittent use only. Continuous
use is specically not recommended and may cause damage to the unit.
• Never block lens and reector during operation.
• Do not shine directly into eyes.
• To reduce the risk of electric shock, unplug the unit and allow to cool before attempting any
cleaning and replacement.
• Risk of uncoverable damage, replace the bulb and battery with same rating only.
PRODUCT FEATURES
• Two positions of handle
• Swivel stand
• Super powerful Quartz Halogen spotlight
• Battery service time up to 20 minutes.
• Equipped with sealed lead acid battery and an
AC/DC charger (included).
• Using 12V DC car plug adaptor for charging (included).
OPERATION
• Push the handle button and turn the handle to upper or lower position. Upper pistol prole for pin
pointing long range objiecet, lower lantern profile for searching around.
• Charge the battery prior to initial use. (see RECHARGING THE BATTERY).
• Turn the lantern ON and OFF by the switch on the main body.
RECHARGING THE BATTERY
• Before recharging the battery, turn the function switch to off position.
• Before using the spotlight for the rst time, charge the battery for 20 continuous hours using the
AC battery charger.
• Plug the AC charger unit into any electrical outlet, and plug the other end of cord adapter to the
DC jack of the spotlight. The LED indicator lights on and time required to fully charge the battery is
around 20 hours.
• Plug the car plug charger unit into the cigarette lighter socket on your car, and plug the other end
of cord adapter to the DC jack of the handle of spotlight. Red LED lights on and time required to
fully charge the battery is around 20 hours.
REPLACE BULB
• Remove the lamp hood by turning it counter-clockwise.
• Grasp and lift out the bulb guarding wire.
• Replace the burned bulb with a new one and re-assemble the guarding wire, screw and lamp
hood.
REPLACE BATTERY
• Remove the lamp hood by turning it counter-clockwise.
• Screw off the battery cover, pull out the battery and its terminals, replace the Lead Acid battery
with a new one.
• Replace the battery cover and turn back the lamp hood.
• It is important to recharge the spotlight as soon as possible after each usage.
• Do not completely discharge battery before recharging. Deep discharge will decrease battery life.
• To ensure the battery will not be fully exhausted when the lantern is not in use or in storage,
recharge the battery every 3 months.
• If operating time decreases signicantly, a replacement battery is recommended. To replace or
obtain a new battery, contact your local Authorized Service Center.
NOTE
• To assure product SAFETY and RELIABILITY, repairs, maintenance and adjustment should be
performed by authorized service centers or other qualied service organizations, always using
identical replacement parts.
• Make sure the spotlight is completely dry before using it.
• The female connector must be connected to the lead of the battery correctly, red wire to positive
(+) lead and blackwire to negative (-) lead.
MAINTENANCE
Use only mild soap and damp cloth to clean the unit. Never let any liquid get inside the unit; never
immerse any part of the unit into a liquid.
CORRECT DISPOSAL OF THIS PRODUCT
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environment or human
health from uncontrolled waste disposal, recycle it responsibly to promote the
sustainable reuse of material resources. To return your used device, please use the
return and collection systems or contact the retailer where the product was purchased.
They can take this product for environmental safe recycling.
1,000,000
CANdLe pOweR
SpOTLIghT
ReChARgeAbLe SUpeRbRIghT
QUARTzhALOgeNLANTeRN
