EM2GO FW101 Manuale utente

Model: FW101

USER MANUAL

Thank you for purchasing our EM2GO product . For optimum performance

and safety please read these instructions carefully before operating the

product. Please keep this manual for future reference.

1. General Information

2. Product Overview

2.1 Introduction

2.2 What you need to know

3. Product Description

3.1 Unfolding

3.2 Assembly

3.3 Folding

3.4 How to adjust height of extension pole

4. How to ride

5. SCOOTER SAFETY PRECAUTIONS

6. Weight and Speed Limitations

6.1 Weight Restrictions

6.2 Speed Limits

7. Operating Range

8. Battery Information and Specications

9. Charging your scooter

10. Inspection, Maintenance, and Storage

11. Scooter Specications

12. Thank you

13. Warranty

CATALOG

1. General Information

Front Wheel

Motor

Kickstand

Charging port

Deck

Rear Brake

Vibration Light

( Please Remove the protection foil)

Folding Latch

Lock buckle

Handle

Display

LED Light

Accelerator Electric Brake

2. Product Overview

3. Product Description

2.1 Introduction

2.2 What you need to know

The E-Scooter can be assembled within 2 minutes:

The enclosed Allen key is used to adjust the brake

and manual accelerator pedal.

To do this, turn it counterclockwise, set the desired

position and turn it clockwise.

Install the Handlebars and tighten the handles.

Before Installing the handles, please

make sure to differentiate the

left & right handles carefully.

Please mind the difference between

the left and right handle that you

can see in the images below.

3.2 Assembly

Pull up the spring loaded tube out of its socket

of the folding latch to unlock the front pole.

Now you can push it down until the tube locks

into the bottom latch into the folded position..

The E-Scooter can be folded within a matter

of seconds.

3.3 Folding

You can unfold the E-Scooter easily within a

matter of seconds.

Pull up the spring loaded tube out of its socket

of the folding latch to unlock the front pole.

Now you can push it up until the tube locks into

the top latch into the unfolded position.

3.1 Unfolding

Before you first experience your E-Scooter, please read the USER MANUAL thoroughly and learn the basics to ensure your safety and the safety of others.

The power will be shut down if nobody operate in five minutes, you need press power button before you ride.

The EM2GO E-Scooter is an intuitive, technologically advanced solution. Using the latest technology and production processes, each scooter undergoes strict

testing for quality and durability. With its lightweight, portable design, ease of use, range, and low carbon footprint.

Failure to follow the basic instructions and safety precautions listed in the USER MANUAL, can lead to damage to your scooter, other property damage,

serious bodily injury,and even death.

WARNING

Screw

3.4 How to adjust height of extension pole

1. Open the lock buckle of extension pole. 2. Press down height-limit button (the metal bead in hole of

extension pole), and pull extension pole to the length(3 levels

of height for option) to t the riders height. When the bead goes

into the hole, the height is xed.

3. Close the lock buckle.

lock buckle

Height-limit button

In order to tighten or loosen the folding tube or to increase the stability of the front pole,

gently adjust the screw as shown in the picture.

The extensive height is prohibited to exceed the first upper Limit hole.

Limit ball must be perfectly placed into the limit hole when the extensive height is finalized. Before riding you must fasten the lock buckle first.

Any operation violating the instructions above may result in accidents due to the loose front pole.

Screw

4.1 How to ride

4. How to ride

1. Turn on the E-Scooter by pressing the power button

for 2 seconds and check the battery power level.

Power key

3. Turn o the scooter by holding the power button when

you are done riding.

2. In order to let the electronic motor accelerate, push yourself of the ground a few times to

reach the minimum speed and hold down the accelerator paddle to accelerate.

You can control your speed by easing up on the accelerator. If you come to a complete halt

you have to push yourself o again.

Power key

Warning: If the E-Scooter has an electric brake and a rear physical break, the

electric brake is to be used first and the rear break only as auxiliary brake,

in case of the electric brake not working properly or is not sufficient.

Do not use the rear brake excessively, as it could damage the tire or fender.

Warning: Accidents could occur during practice. Make sure to wear an appropriate helmet and protectors during

riding. E-Scooter is not suitable for people under 14 Years!

The quoted regulations pertain to gerrman law. Please inquire about your countries/states legislations.

You can choose 3 lighting modes by pressing the button.

4.2 Display description

4.3 Light description

Speed level +

Power key

Switch display mode

Display mode: ODO, VOL, TIME, DIS, RPM

Speed level: 1--Max 5km/h

2--Max 15km/h

3--Max 23km/h

Speed level -

Km/h

TIME

Battery power

Selected speed level

Speed (Km/h)

Display mode (TIME)

Using time

Km/h

DIS

Battery power

Selected speed level

Speed (Km/h)

Display mode (DIS)

Single distance (km)

Km/h

RPM

Battery power

Selected speed level

Speed (Km/h)

Display mode (RPM)

Motor speed

Km/h

ODO

Battery power

Selected speed level

Speed (Km/h)

Display mode (ODO)

Total mileage (km)

Km/h

VOL

Battery power

Selected speed level

Speed (Km/h)

Display mode (VOL)

Battery voltage (V)

1. Press the button to switch on, the LED ashes with

short intervals.

2. Pressing again, the LED ashes with longer intervals.

3. Press the button again to activate the permanent

lighting.

4. Press the button the fourth time to turn o the light.

5. E-SCOOTER SAFETY PRECAUTIONS

Failure to follow any of the following safety precautions can and may lead to damage to your E-Scooter, void your manufacturer warranty, lead to property damage,

cause serious bodily injury, and can lead to death.

1. Please wear all appropriate safety and protective gear as previously mentioned in the User Manual before operating the E-Scooter.

2. Make sure to wear comfortable clothes and at closed toe shoes when operating your E-Scooter.

3. Please carefully read the User Manual, which will assist in explaining the basic working principles and provide tips on how to best enjoy your E-Scooter

experience.

4. Do not try to open or modify your E-Scooter, as doing so will void your manufacturer warranty, and may cause failure to your device leading to serious bodily

injury or death.

5. Do not use the E-Scooter to place yourself or anyone else and their property in danger.

6. Do not operate the E-Scooter while under the inuence of drugs and/or alcohol.

7. Do not operate the E-Scooter when you are restless or sleepy.

8. Use your best judgment to keep yourself out of dangerous situations with your E-Scooter.

9. Do not ride your E-Scooter o of curbs, ramps, or attempt to operate in a skate park, empty pool, or in any ways similar to a skateboard or E-Scooter.

THE E-SCOOTER IS NOT A SKATEBOARD.

10. Do not turn sharply, especially at high speeds.

11. Do not abuse your E-Scooter, doing so can damage your unit and cause failure to the operating system leading to injury.

12. Do not drive in or near puddles of water, mud, sand, stones, gravel, debris or near rough and rugged terrain.

13. The E-Scooter can be used on paved roads that are at and even. If you encounter uneven pavement, please lift your E-Scooter over and past the obstruction.

14. Do not ride in inclement weather: snow, rain, hail, sleek, on icy roads or in extreme heat.

15. Do not ride in or near pools or other large bodies of water.

16. For Bumps and Uneven pavement-Bend your knees when riding on bumpy or uneven pavement to absorb the shock and vibration and help you keep your

balance. If you are unsure if you can safely ride on a specic terrain, step o and carry your scooter. ALWAYS ERR ON THE SIDE OF CAUTION.

17. Do not attempt to ride over bumps or objects greater then 1.5 cm even when prepared and bending your knees.

18. PAY ATTENTION - look at where you are riding and be cognoscente of the road conditions, people, places, property and objects around you.

19. Do not operate the E-Scooter in crowded areas. Please pay attention on riding of E-Scooter in Public road and it´s regulations.

20. Operate your E-Scooter with extreme caution when indoors, especially around people, property, and narrow spaces like doorways and other narrow spaces.

21. Operate your E-Scooter with extreme consideration for people and property at all times.

22. Do not operate the E-Scooter while talking, texting, or looking at your phone.

23. Do not ride your E-Scooter where it is not permitted.

24. Do not ride your E-Scooter near motor vehicles or on public roads.

25. Do not climb or travel down steep hills with your E-Scooter.

Maximum Weight: 90 kg.

6.1 Weight Restrictions

6.3 E-Scooters must be equipped with front and rear lights, bell

and reflectors.

Maximum Speed: 20 km/h

6.2 Speed Limits

PLEASE NOTICE

Speed and weight limits are set for your own safety. Please do not exceed the

limits listed in the User Manual.

6. Weight and Speed Limitations

7. Operating Range

26. The E-Scooteris intended for use by a single individual, DO NOT attempt to

operate the scooter with two or more people.

27. Do not carry anything while reding the E-Scooter.

28. Individuals with lack of balance should not attempt to operate the

E-Scooter.

29. Women who are pregnant or who may become pregnant should not

operate the E-Scooter.

30. Young children under 14 Years and the elderly should not operate the

scooter without proper instruction and supervision from a Certied

scooter trainer.

31. At higher speeds, always take into consideration longer stopping distances.

32. Do not step forward o your E-Scooter.

33. Do not attempt to jump on or o your E-Scooter.

34. Do not attempt any stunts or tricks with your E-Scooter.

35. Do not ride the E-Scooter in dark or poorly lit areas.

36. Do not ride the E-Scooter near or over potholes, cracks or uneven pavement.

37. Do not operate yout E-Scooter o-road.

38. Do not exceed the maximum or minimum weight limits.

39. Avoid driving the E-Scooter in unsafe places, including near areas with

ammable gas, steam, liquid, dust, ber, which could cause re and

explosion accidents.

40. Please Contact your insurance, if and under what conditions your E-Scooter

insures.

Please notice the E-Scooter can travel a distance of 8-10km on a fully charged

battery in ideal conditions. The following are some of the major factors that will

aect the operating range of your scooter.

Terrain: A smooth, at surface will increase your driving distance, while driving

uphill, as well as rough or uneven terrain will reduce your distance signicantly.

Weight: The weight of the user can aect driving distance, a lighter user will

have further range than a heavier user.

Ambient temperature: Please ride and store the E-Scooter under recommended

temperatures, which will increase driving distance; battery life, and overall

performance of your scooter.

Maintenance: Reasonable battery charging and maintenance will increase the

distance. Overcharging the battery can reduce range.

Speed and Driving Style: Maintaining a moderate speed will increase your

distance; while travelling at high speeds for extended periods, frequent starts,

stops, idling, along with frequent acceleration and deceleration will reduce

your overall distance.

8. Battery Information and Specifications

This section is intended to provide you basic information about your battery

and charger. Please read this section carefully to ensure you. For user safety

and to prolong the life of your battery, as well as improve battery

performance, please follow these instructions.

When the battery indicator shows lowbattery capacity, please charge your

battery 3 hours utilizing the charger that you received in your scooter package.

To fully recharge your battery please follow the instructions under

“Charging your E-Scooter”.

Battery Lithium Battery

6 months

-20 ℃- 25 ℃

5 % -95 %

0 ℃- 40 ℃

-15 ℃- 50 ℃

3 hours

25.2 V

Charging time

Voltage

Initial Capacity

Working Temperature

Charging Temperature

Storage Time

Storage Temperature

Storage Humidity

4400 mAh

8.1 Weight Restrictions

Battery Specifications

BATTERY WARING

9. Charging your E-Scooter

Failure to follow the Safety Precautions listed in the Battery Warning could

lead to serious bodily injury and death. Seek immediate medical attention if

you are exposed to any substance that is emitted from the battery.

• Do not attempt to modify, change, or replace your battery.

• Do not use your scooter if the battery begins to emit odor, overheats, or

begins to leak.

• Do not touch any leaking materials, or breathe fumes emitted.

• Do not allow children and animals to touch the battery.

• The battery contains dangerous substances, do not open the battery, or

insert anything into the battery.

• Please only use the charger provided by scooter.

• Do not attempt to charge the scooter if the battery has discharged or

emitted any substances. In that case, the battery should be abandoned for

safety.

• Please follow all local, state and federal laws in regards to recycling,

handling and disposing of Lithium Ion batteries. Batteries contain harmful

substances that have a negative impact on health and the environment.

• The E-Scooter should only be shipped in its original packaging.

• Do not throw away your box as you need you E-Scooter packaging for future use.

Step 1: Ensure that the charging port is clean and dry.

Step 2: Plug the charger into the cable socket, then connect the cable with the

power supply (100V～240V; 50,60Hz), make sure the light on the charger

is lit GREEN.

Step 3: Male DC connector plug into the charging port ofthe E-Scooter. The

indicator light on the charger should change to RED, indicating that your

E-Scooter is now, being charged. When the RED indicator light on your

charger turns to GREEN then your E-Scooter is fully charged. A full charge

typically occurs within 3 hours.

Step 4: Please unplug the charger from your E-Scooter and from the power outlet.

IMPORTANT NOTES ABOUT CHARGING

If the green light on your charger does not turn RED when you plug it tinto your

E-Scooter, it could mean you have to check the cables to ensure you have a

proper connection; or that your scooter is already fully chaged. Push and hold

your power button next to the charging port to check the status of your battery

in the display.

• Do not overcharge, as this will affect the life of the battery.

• Batteries should be charged at least once every 3 months.

• The best charging temperatures are between 0°~40°. Extreme cold and

extreme heat will prevent your battery from charging fully.

• Make sure to unplug your charger before standing on or operating your

E-Scooter, as this can be very dangerous.

• Use only the E-Scooter charger that you received in your box.

• If the scooter is powered on when you enter the plug, the Battery Indicator will

begin blinking, if the E-Scooter is powered off when you enter the plug,

the Battery Indicator will not blink.

Indice

Altri manuali EM2GO Scooter

EM2GO

EM2GO FW103 Manuale utente

Manuali Scooter popolari di altre marche

TEKTRO

TEKTRO CHEETAH Manuale utente

Douglas

Douglas Vespa Sprint Guida all'installazione

PLAYTIVE

PLAYTIVE AS-2448 Manuale utente

Ebinger

Ebinger DONKEY XL Manuale utente

Flyer

Flyer Mountain Guida utente

BackCountry eBikes

BackCountry eBikes Storm Manuale utente

equipmed

equipmed FreeRoam II Manuale utente

Yoto

Yoto Lion Manuale utente

WESTHILL BIKES

WESTHILL BIKES LINK Manuale utente

BAnff

BAnff eProdigy series Manuale utente

Winther

Winther 475 Manuale utente

Jetson

Jetson JBZL17 Manuale utente

First Choice Mobility

First Choice Mobility Roma Medical Corella S741 Manuale utente

Carrera

Carrera impel Manuale utente

Afikim

Afikim Superlight SL-3 Manuale utente

CareCo

CareCo ZOOM Manuale utente

Douglas

Douglas Vespa G.S. Manuale utente

Gazelle

Gazelle with BOSCH System Manuale utente
