The Emerson PrPMC800

series processor PCI

mezzanine card (PMC) is

the ideal solution when

time-to-market and flexibil-

ity are important.

MPC7410 PowerPC®

microprocessor

AltiVec technology

Latest high-performance

PowerPlus III Architecture

2MB/1MB of L2 cache

Up to 512MB on-board

ECC SDRAM

32MB on-board ash

72-bit ECC memory

controller ASIC

Single-wide PMC with a

66/33 MHz PCI interface

Optional 10/100BaseT

Ethernet interface

64-bit PCI host bridge

One asynchronous serial

debug port

Hardware DMA channel

Four 32-bit timers

Two watchdog timers

The Emerson PrPMC800 series processor PCI mezzanine card (PMC) is the ideal

solution when time-to-market and exibility are important. In addition to the

highlighted features, this PMC module also includes a full-length heatsink, creating

a CPU package capable of handling the thermal requirements of complex tasks.

Processor PMC (PrPMC) modules provide a complete host CPU and memory subsys-

tem to a base board full of PCI-based I/O controllers in a compact, rugged, industry

standard form factor. The PrPMC isolates the complexities of a high-speed CPU, cache

and memory signals from application-specic hardware, enabling OEMs to focus

on their market requirements while simplifying their product release. These modules

also simplify CPU and memory upgrades in performance-driven embedded and

telecom applications.

PrPMC800 Series

High-Performance Processor PMC

Front page

Interior page

EIA232

Planar

Base Board

PCI Bus – A32/D64-bit

66/33 MHz

10/100 Base T

PMC Interface to

Base Board

Pn4

Pn3

Pn2

Pn1

Ethernet

PCI Bridge and

Memory Controller PowerPC Bus – A32/D64-bit

ECC DRAM

Up to 512MB

Flash

32MB

L2 Cache

2/1MB

MPC7410

processor

COM1

I2C Serial

EEPROM

Specications

PROCESSOR

Microprocessor: MPC7410 class

Clock Frequency: 400 – 500 MHz

On-chip Cache (I/D): 32KB/32KB

L2 Cache: 1MB – 2MB

Cache Bus Clock Frequency: 180 MHz – 225 MHz

MEMORY

ECC Protected Main Memory: PC100 SDRAM

On-board Capacity: Up to 512MB

Single Cycle Accesses: 10 read/5 write

Read Burst Mode: 8-1-1-1 idle; 3-1-1-1 aligned

page hit (CL3)

Write Burst Mode: 4-1-1-1 idle; 3-1-1-1 aligned

page hit

User I2C Serial EEPROM: 8KB

EEPROM/Flash: 32MB surface mount (on-board

programmable), up to 512MB addressable on

carrier (optional)

PrPMC800 Block Diagram

SYNCHRONOUS SERIAL PORT

Controller: 16C550 compatible

Number of Ports: One

Conguration: DTE

Async Baud Rate, b/s max.: 38.4K EIA-232,

115Kb/s raw

IEEE P1386.1 INTERFACE

Address/Data: A32/D32/D64, PMC Pn1, Pn2, Pn3,

Pn4 connectors

PCI Bus Clock: 33 MHz or 66/33 MHz capable

Signaling: 3.3V output; VIO input

Power: +3.3V

Height: 13.5 mm from top of carrier board

(one slot)

Module Type: Single-wide

ETHERNET

Controller: Intel®82559ER/82551IT

PCI Bus Master: 33 MHz with PCI burst

Connector: Models congured for Ethernet routing

via Pn4 do not have a front bezel.

Front page

Interior page

COUNTERS/TIMERS

Real-Time Timers/Counters: Four 32-bit

programmable

Watchdog Timers: Two, time-out generates

interrupt or reset

MISCELLANEOUS

Reset, Abort and JTAG/COP via on-board debug

connector

Two planar LEDs for Fail and CPU active

POWER REQUIREMENTS

(AltiVec disabled)

+ 3.3V ± 5% @ 20° C

PrPMC8005E-12xx: 3.3 A typical, 3.9 A

maximum

PrPMC8005E-13xx: 4.1 A typical, 4.5 A

maximum

VIO: PCI buffer diode clamping

voltage

DEMONSTRATED MTBF

(based on a sample of eight boards in accelerated

stress environment.)

Mean: 190,509 hours

95% Condence: 107,681 hours

SAFETY

All printed wiring boards (PWBs) are manufactured

with a ammability rating of 94V-0 by UL recognized

manufacturers.

ENVIRONMENTAL

Operating Non-operating

Temperature: 0° C to +55° C,

forced air

cooling

Humidity (NC): 5% to 85% 5% to 95%

Vibration: 1.0 G sine

sweep, 5.0

to 100 Hz, 25

octaves/min

0.5 G sine sweep;

50-500 Hz; 0.1

octaves/min 3.0 G

sine sweep; 5-50 Hz;

0.25 octaves/min

ELECTROMAGNETIC COMPATIBILITY (EMC)

Intended for use in systems meeting the following

regulations:

U.S.: FCC Part 15, Subpart B, Class A (non-residen-

tial)

Canada: ICES-003, Class A (non-residential)

This product was tested in a representative system

to the following standards:

CE Mark per European EMC Directive 89/336/EEC

with Amendments; Emissions: EN55022 Class B;

Immunity: EN50082-1

Front page

Interior page

Business-Critical Continuity, Emerson Network Power and

the Emerson Network Power logo are trademarks and

service marks of Emerson Electric Co.

www.EmersonNetworkPower.com/EmbeddedComputing

Emerson Network Power.

The global leader in enabling

Business-Critical Continuity™.

Precision Cooling

Services

Site Monitoring

Surge & Signal Protection

AC Power Systems

Connectivity

DC Power Systems

Embedded Computing

Embedded Power

Integrated Cabinet Solutions

Outside Plant

Power Switching & Control

Emerson Network Power

Offices: Tempe, AZ U.S.A. 1 800 759 1107 or +1 602 438 5720 Madison, WI U.S.A. 1 800 356 9602 or +1 608 831 5500

Shanghai, China +86 215292 5693 Paris, France +33 1 69 35 77 00 Tokyo, Japan +81 3 5424 3101

Munich, Germany +49 (0) 89 9 608 2 333 Hong Kong, China +852 2966 3210 Tel Aviv, Israel +972 3 568 4387

PrPMC800-D1 2/08

SOLUTION SERVICES

Emerson Network Power provides a portfolio of solution services optimized to meet your needs throughout the product lifecycle. Design services help speed

time-to-market. Deployment services include global 24x7 technical support. Renewal services enable product longevity and technology refresh. Plus solution

extras include enhanced warranty and repairs.

PowerPC is a trademark of IBM Corp. and used under license. Intel is a registered trademark of Intel Corporation or its subsidiaries in the U.S. and other countries. All other product or service names are

the property of their respective owners.

This document identies products, their specications, and their characteristics, which may be suitable for certain applications. It does not constitute an offer to sell or a commitment of present or future

availability, and should not be relied upon to state the terms and conditions, including warranties and disclaimers thereof, on which Emerson Network Power may sell products. A prospective buyer should

exercise its own independent judgment to conrm the suitability of the products for particular applications. Emerson Network Power reserves the right to make changes, without notice, to any products or

information herein which will, in its sole discretion, improve reliability, function, or design. Emerson Network Power does not assume any liability arising out of the application or use of any product or circuit

described herein; neither does it convey any license under its patent or other intellectual property rights or under others. This disclaimer extends to any prospective buyer, and it includes Emerson Network

Power’s licensee, licensee’s transferees, and licensee’s customers and users. Availability of some of the products and services described herein may be restricted in some locations.

Ordering Information

Part Number Description

33 MHz PCI, Front Ethernet

PRPMC8005E-1261 450 MHz MPC7410, 256MB ECC SDRAM

33 MHz PCI, Rear Ethernet

PRPMC8005E-1259 450 MHz MPC7410, 128MB ECC SDRAM

PRPMC8005E-1269 450 MHz MPC7410, 256MB ECC SDRAM

66 MHz PCI, No Ethernet

PRPMC8005E-2261 450 MHz MPC7410, 256MB ECC SDRAM

PRPMC8005E-2271 450 MHz MPC7410, 512MB ECC SDRAM

Note: Additional PrPMC800 series models may be available; contact your local sales representative.
