Emicro One Manuale utente

we are emobility*

Please read carefully!

emicro one

operating instructions

THE BATTERY Page 20

Important information Page 20

Important care instructions Page 21

Disposal information Page 23

Range Page 23

COMPONENTS Page 24

MAINTENANCE Page 24

Footboard maintenance Page 24

Folding mechanism maintenance Page 24

Telescopic handlebar maintenance Page 27

TECHNICAL DATA Page 28

WARRANTY Page 30

Index

INTRODUCTION Page 3

WARNING Page 4

PRIOR TO FIRST USE Page 6

IMPORTANT INSTRUCTIONS AT A GLANCE Page 7

General instructions Page 7

Safety instructions Page 8

For lasting riding enjoyment Page 9

Warranty information Page 11

OPERATION Page 12

Side stand Page 12

Unfolding and folding Page 13

The 'Motion Control' system Page 14

Charging the battery and displaying the charge level Page 15

The three riding programs Page 16

Changing the riding programs Page 18

Welcome to the club of emicro one riders.

We are delighted to welcome you into the community of emicro riders and are certain that you will really

enjoy the smallest electric scooter in the world.

This operating manual explains the most important instructions to be followed. It provides you with tips on

the maintenance and use of your emicro and describes how to operate the vehicle correctly for safe and

long-term use.

All data are based on the technical status at the time of writing this operating manual. Any modiﬁcations and

additions made in the meanwhile are not included in this version. The latest version of the operating manual

can be found online at www.micro.ms.

Our global dealer network will be pleased to help you with any questions or problems. Please contact your

local dealer and we will do our utmost to provide rapid and straightforward assistance.

Introduction

CAUTION: Please note that riding with electrical support takes getting used to. The acceleration – and hence the

forward force – is much greater than with a normal kick movement. With inexperienced riders, this unfamiliar accel-

eration can lift the front wheel off the ground and lead to falls. Begin carefully and always ensure some room for

manoeuvre. Never bend backwards while riding.

CAUTION: As well as the normal braking performance due to friction, pressing the foot brake also brakes the emicro

with an electrical motor brake. This greatly improves the braking performance and results in a shorter braking dis-

tance. But please be aware that the motor brake is not supported if:

• The battery is discharged and you are riding with muscle power alone.

• The battery is 100% charged and hence energy cannot be regenerated.

The additional braking performance of the motor brake is enormous and greatly shortens the braking distance.

Always be aware of this, especially if the additional braking performance is not present in the situations mentioned

above.

CAUTION: Always use the rear wheel brake to slow down and stop. Never brake by rubbing the soles of the feet on

the ground! This activates the 'Motion Control' system and you will not stop. It's like attempting to drive a car with

the accelerator and brake pedal pressed at the same time.

Warning

Before each trip, check the emicro for road worthiness.

The vehicle is delivered by the manufacturer fully ready for use. Because defects potentially impairing the

function of the vehicle can occur during transport as well as any periods off the road, we ask you to always

pay attention to the following points before using for the ﬁrst time - as well as before each trip:

BRAKE: Check that the brake is working correctly. In particular, you must know whether you are setting

off with or without electronic brake assistance (motor brake) as this makes a huge difference to the braking

power (see Warning chapter).

GENERAL CONDITION: Before each trip, check the emicro to make sure that all screws are tight and there

are no loose components.

FOLDING MECHANISM: The folding mechanism is correctly clicked in place and the clamping lever is closed

and tightened.

SIDE STAND: The side stand is correctly folded in under the footboard.

BATTERY CHARGE STATUS: Check the charge status of the battery by means of the LED display on the

footboard.

The battery is only partially charged when the emicro is delivered. Before using for the ﬁrst time, fully charge

the battery using the charger provided.

Prior to ﬁrst use

Safety of children and vulnerable persons

• Children older than 8 years and persons with limited physical, sensory or mental capacity or lackinge

experience and/or expertise may use this device only when they are supervised by a person responsible

for their safety or if they have been trained in the safe operation of the device and understand the risks

associated with the device.

• Children must not play with the unit.

• Children may not maintain or clean the unit without proper supervision.

• Keep all packaging material out of children's reach.

Warning

Always comply with the applicable national laws and regulations relevant to road trafﬁc and vehicle class.

Please note that the legislation can differ from country to country and that the emicro one is not approved for

use on public roads. Information is also available at www.micro.ms.

Study the Warning chapter thoroughly before using for the ﬁrst time.

• Comply with local trafﬁc regulations at all times. It is your duty to be informed of the law applicable in your coun-

try and to follow it accordingly.

• The emicro is not a toy. It is not designed for the weight of children. We recommend a minimum age of 16 years.

• The serial number is found on the underside of the footboard. Please note the serial number.

Safety instructions

• Only ride on dry surfaces. Driving on wet surfaces can be very dangerous and must be avoided.

• Never brake by rubbing the soles of the feet on the ground! This movement activates the 'Motion Control' system

which in turn leads to acceleration. Always brake with the rear wheel brake (foot brake)!

• Never ride with motor support on the pavement. Not only is this dangerous for you and others, but also illegal

in many countries.

• For reasons of safety, we recommend not to ride in the dark.

• Always wear protective equipment, especially a helmet suitable for protection against head injuries.

Important information at a glance

General information

• The vehicle is not approved for general use on public roads and, for this reason, can only be used on private

property. Any use outside this area is at your own risk and without liability of the manufacturer.

• The emicro is designed for transporting a single person up to a maximum weight of 100 kg and should only be

used for this purpose. Ignoring this instruction is deemed improper use and is at the sole risk of the user.

• Any interventions for increasing the performance or speed and, in general, modifying the features of the scooter

are actionable and will be prosecuted by law. They will invalidate the warranty.

For lasting riding enjoyment

• Do not jump with the scooter as this causes excessive stresses and ultimately damage to the scooter

which is not covered by the warranty.

• Make sure you always avoid potholes and ride at a right angle over curbstones and other obstructions.

See the section on Operation and Maintenance for further information.

• In the rain or after cleaning the vehicle, the braking action may be delayed due to moisture. For this reason the

brakes should be "braked dry" on safe, private property after cleaning the scooter.

Study the Warning chapter thoroughly before using for the ﬁrst time.

Caution on steep descents! The braking performance is not sufﬁcient to guarantee safe riding on steep,

rapid descents.

Protecting the emicro against unnecessary damage and lasting riding joy

• Immediately after your purchase, fully charge the battery.

• When you store the scooter, charge the battery every three months.

• In principle, the emicro is splash-proof. However, you should avoid contact with water.

• Batteries are sensitive to temperatures. Do not park your scooter in direct sunlight or in a very cold envi-

ronment. We recommend that you store the scooter at room temperature.

Side stand

The emicro has a side stand. This is located under the footboard next to the folding mechanism. Always fold

in the stand forwards so it can be folded down again with the toes when required.

Warranty information

• Strictly follow the instructions for maintaining the footboard in the Maintenance section. Non-compliance

with the maintenance intervals of the scooter will invalidate any warranty claims.

• The emicro is splash-proof and occasional riding on damp grounds should not damage the electronics.

However, you should avoid any contact with water.

• Do not carry out your own repairs. Always contact your service centre. Opening the footboard will auto-

matically invalidate the warranty. In individual cases, Micro allows opening of the footboard under cer-

tain preconditions in consultation with the customer.

• "Tuning" the emicro is forbidden. This endangers your personal safety and operating safety, as well as

decreasing the operating life of your vehicle. This will also invalidate the warranty.

For more information on warranty, refer to the Warranty section.

Operation

The 'Motion Control' system

The 'Motion Control' system makes riding with the emicro an unforgettable experience. Some brief informa-

tion on the 'Motion Control' is given below:

• 'Motion Control' only becomes active from approx. 5 km/h. This means the rider must use muscle power

alone to accelerate to 5 km/h before the initial support is noticeable.

• The stronger and more intensive the kick (pulse), the stronger and longer lasting the support of the motor.

• A few powerful kicks are more economical and efﬁcient than many small kicks.

Please note that riding with electrical support takes getting used to. The acceleration is much greater than

with a normal kick movement. This unfamiliar acceleration comes unexpectedly. When riding for the ﬁrst

time, be extremely cautious and at the same time learn how to brake properly with the foot brake at the very

beginning.

Unfolding and folding up

Your emicro is delivered folded up. It is unfolded and ready to ride in a few simple steps. How to unfold the

emicro is described below.

1. Release the clamping lever on the right side of the folding mechanism

2. Push both blue knobs on the right and left of the black block at the same time and unfold the front part of

the scooter with the handlebar until the locking mechanism fully clicks into place.

3. A click tells you that the scooter is fully unfolded. Now close the clamping lever again on the side.

(To fold up, carry out the same steps in reverse. Make sure that the clamping lever is always closed and fully

tightened when riding.)

The three riding programs

The emicro has three different riding programs. This allows optimum riding performance and correct pro-

gramming in a wide range of situations as well as conformity to the applicable legislation.

Riding program Position in the circle

on the footboard

Power

or force

Maximum support speed

Eco mode O 250 Watt 15 km/h

Standard mode OO 250 Watt 25 km/h

Sport mode OOO 500 Watt 25 km/h

Only ride with the scooter using the riding program with which you feel safe and that complies with the relevant

legislation in your country.

Charging the battery and displaying the charge status

Only use the power supply unit supplied by Micro for charging your emicro.

The charging process is described below:

1. Connect the charger to a power socket. The lamp on the charger should now light green.

2. Now connect the emicro to the charger. You can see that the charger and scooter are connected correctly

when the lamp on the power supply unit changes to red (can take a few seconds).

3. When the emicro is fully charged, the display on the charger changes back to green.

In order to see the current charge status, switch on the scooter by turning the rear wheel. The same applies

to checking the charge status during the charging process.

Changing the riding program

Changing the program is very simple and takes no time at all. The setting tool included in the scope of deliv-

ery is needed for this.

Hold the setting tool on the circular cut-out on the footboard. The tool must be aligned to the small arrow

head engraved on the setting tool. Now you can switch between the three programs by turning the setting

tool and aligning the arrow to the empty circles. The LED display shows which riding program is set by ﬂash-

ing dimly three times, followed by ﬂashing brightly three times. One LED ﬂashes in Eco mode, two LEDs

ﬂash in Standard mode and three LEDs in Sport mode.

Eco Standard Sport

Setting tool

Ride slowly to become used to the novel riding sensation, especially when riding for the ﬁrst time. Do not

forget that a higher speed also needs a longer braking distance.

Please also note that, depending on the country, different maximum speeds and restrictions in terms of

maximum power apply to electrically supported vehicles. It is your responsibility to be aware of these values

accordingly and to adhere to them.

The setting tool contains strong magnets. Be careful never to hold the setting tool close to electronic devices

such as your mobile phone or close to credit cards as they could be damaged.
