OWNER'S MANUAL
PORTABLE DVD PLAYER
PD-7201
DVD/VCD/CD/MP3/CD-R/CD-RW/HDCD/JPEG PLAYER
TABLE OF CONTENTS
To ensure proper use of this product, please read this owner's manual carefully and retain for future
reference.
This manual provides information on the operation and maintenance of your DVD player. Should the
unit require service, contact an authorized service location.
SPECIAL FUNCTION PLAYBACK
MP3 Playback
Kodak Picture CD Function
JPEG Disc Playback
01
02
04
04
05
07
07
08
10
11
12
12
12
12
12
12
12
13
13
13
13
13
13
13
13
14
14
14
14
14
14
14
15
15
System Setup
Trouble Shooting
Supported by DVD Discs
Specification
Special Function of DVD
Function
REFERENCE
16
20
21
21
22
BASIC PLAYBACK REMOTE CONTROL
Preparations
Basic Playback
Pause/Step Playback
Stop Playback
Previous and Next
Fast forward and Fast reverse
Slow
PBC
MENU
A-B REPEAT
REPEAT
ZOOM
OSD
SUBTITLE
SEARCH
PROGRAM
AUDIO
RANDOM
VOLUME and MUTE
ANGLE
TFT-M
Safety Precautions
Important Safety Instructions
Notice
Disc Protection
Battery
Playable Discs
Accessories
Lithium
Basic connection
Remote control
Panel
BEFORE USE
Advanced Playback
CONTROL and CONNECTION
TITLE 13
SAFETY PRECAUTIONS
01
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE, DANGEROUS HIGH VOLTAGES ARE
PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE CABINET. REFER
SERVICING TO QUALIFIED PERSONNEL ONLY.
When replace the direct plug in power supply or a separable, cord-connected power
supply, the replacement must be exact duplicate, or one recommended by the manu-
facturer.
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE
SLOT, FULLY INSERT.
This Digital Video Disc player employs a laser System.
Use of controls, adjustments or the performance of procedures other than those
specified may result herein hazardous radiation exposure. To prevent direct expo-
sure to laser beam, do not try to open the enclosure. Visible laser radiation when
open and interlocks defeated.
DO NOT STARE INTO BEAM.
The lightning flash with arrowhead symbol, within an equila-
teral triangle, is intended to alert the user to the presence
of uninsulated "dangerous voltage " within the product's en-
closure that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
The symbol for CLASS II (Double Insulation).
WARNING:
CAUTION:
Manufactured under license from Dolby Laboratories. " Dolby " and the double-D
symbol are trademarks of Dolby Laboratories. Confidential unpublished works.
Copyright 1992-1997 Dolby Laboratories. All rights reserved.
This product incorporates copyright protection technology that is protected by
method claims of certain U. S. Patents and other intellectual property rights owned
by Macrovision Corporation and other rights owners. Use of this copyright protection
technology must be authorized by Macrovision Corporation, and is intended for
home and other limited viewing uses only unless otherwise authorized by Macrovision
Corporation. Reverse engineering or disassembly is prohibited.
Waste bin
02
Notes on discs
Do not play discs that are damaged or warped, including discs with cracks, scratches or parts missing discs
with burns; poor quality discs.
Route all cords so that they do not interfere with driving or with entering or exiting the
car
Run the cords so tat they do not wrap around the steering wheel, brake pedal etc. or around your feet. Secure
all the cords together
Use the product at the proper volume setting
Driving while you are unable to hear sounds around you or from outside the car car can cause accidents.
Do not touch the color TFT LCD screen
Do not place any heavy objects on the product
Never put any heavy objects on the product. Doing so may cause damage to product.
Do not damage the cords.
Broken wires and short circuits can cause electrical shock or fire. Run the cords so that they do not get tangled
in moving parts. Do not damage, tighten up, twist or work on the cords. Do not place the cords near heat
sources or put heavy objects on the cords.
Do not play discs in the wrong format
For instance, if you add the ".cda" extension to a file that is not formatted as a CD file, a loud noise may be
heard through the speakers. possibly damaging them and hurting your eardrums.
Do not swing from the product or pull it
This may cause an accident. injury and/or malfunction. Be particularly careful that children follow this rule.
03
04
NOTICES and DISC PROTECTION
The pickup may be condensed with water under the
following situation.
05
LITHIUM BATTERY
Lithium battery connections
Attaching Battery
Charge the battery pack before using it for the first time.
Refer to the following steps for attaching the battery:
1. Make sure the player is off and the AC or car adapter
is disconnected.
2. Place the player on a soft.
3. With one hand on the player to prevent it from
moving, match the hooks of the battery pack into the
holes on the bottom of the unit.
4. Combine the battery pack to push toward left until
you can hear the click sound.
Make sure the power is turned OFF and the AC or car
adapter is disconnected before detaching the battery.
To separate the battery pack, pull the switch which is
locate bottom the unit and from the
main unit.
push toward right
Detaching Battery
Portable DVD Back:
Battery front:
Flush left here
Note: Follow below illustrations to match the hooks
of the battery pack along the left side of the holes on
the bottom of the unit, in case of damages to the unit
due to any improper mounting.
Please charge the battery with the unit.
Never use this battery in other devices except this unit.
Never use or keep the battery in a space has static, neither charge the battery in such area.
Never use the unit outdoors in rainy or snowy day. The battery doesn't have waterproof function.
Keep the dirt, liquid or other foreign thing stick on the power supply connector of battery.
Never touch the power supply connector of battery with metallic things.
Never change, disassemble, heat or throw batteries into a fire.
O
Never store the battery in a place which temperature is over 60 C.
Be sure to conform the related law or regulation in your country before discard the battery.
Lithium battery
Charge the battery before use it for the first time.
The unit can charge the battery during disc playback. Charging time/ playback time.
The time showed in above sheet also depends
on the operation situation.
When the unit won't be used in a long time.
Remove the battery (The unit consume little energy
even in turn off situation. This may over discharge
the battery and cause a damage to it.
Please recharge the battery again when you want
to use it.
Usage of batteryLithium
Charging time Playback time
When use TFT
LCD Screen
When not use
TFT LCD screen
About 4 hoursAbout 2.5 hours
About 20 hours About 4 hours
When unit
working
When unit
not working
06
LITHIUM BATTERY
Lithium battery
When TFT display the picture dark and dark,
please change the battery or insert adapt for
charge. Then turn right VOLUME button and the
unit will working.
1. Mount the battery properly
2.Turn on the Vol PW OFF button that main unit.
3.When the battery is being charged, the Battery
indicator is illuminated red.
4.If recharging is complete, charge indicator
changes to green colour.
5.When the battery is working, the battery
indicator is off.
When enjoying CD or not using TFT screen, close
the screen to save battery energy.
Play with batteryLithium
07
The following discs can be playback:
ACCESSORIES
Audio/Video cable ....................
Remote control ........................
Owner's manual .......................
Adapter .....................................
Lithium battery..........................
Car charger...............................
1
1
1
1
1
1
Discs than those listed above can not be played.
Non-standardized discs, even if they may be labeled as above can not be played.
The performance of recorded disc is depend on the method and quality of disc-burning. In some cases,
the disc may not be played.
TM
Designed for
TM
Windows
Media
DVD-RW
DVD+RW
RW
DVCD
SVCD
CD+G
Owner's manual
OWNER'S MANUAL
Lithium battery Adapter
Car charger
AUDIO
456
789
0SEARCH
REPEATA-BRPT
PORTABLEDVD PLAYER
VOL
-
VOL
+
RANDOM
MUTE
SUBTITLE
ZOOM
MENU
ANGLE
OSD
TFT-M
ENTER
1 2 3
PROG
TITLE
PBC
SETUP
1. TFT SCREEN
2. 4:3/16:9(Multi-aspect ratio suit to
different TFT screen size)
3. DOWN(CURSOR)
4. UP(CURSOR)
5. MENU(TFT Screen menu)
6. DISC LID
7. SETUP
8. TITLE
9. PREVIOUS
10. NEXT
11. STOP
12. SLOW
13. PLAY/PAUSE
14. CURSOR
15. OPEN
16. DISC LENS
PANEL
08
PANEL
DVD/VCD/CD /CD-R/CD-RW/HDCD/JPEG PLAYER/MP3
OPEN
MENU
UP
DOWN
4:3/16:9
SETUP TITLE
PHONE AUDIO OUT VIDEO OUT
DC 9VIN
20 21 22 23 24 19
VOL
PW OFF
20. VOLUME CONTROL
(POWER SWITCH)
21. PHONE
22. AUDIO OUT
23. VIDEO OUT
24. DC IN
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15 16
17
18
17. REMOTE CONTROL SENSOR
18. POWER INDICATOR
19
19. LOUDSPEAKERS
Left
Right
Up
Down
