EMU 2012 Mini Manuale utente
BEING GREEN HAS NEVER LOOKED SO COOL!
American Scooter Company,L.L.C.
Please note that due to continuing improvements to our products and services, pictures
and/or descriptions may differ from the model and/or parts depicted in this manual.
READ THIS MANUAL COMPLETELY BEFORE ASSEMBLING
AND RIDING
EMU Trike
Electric Multi Use Trike
Owners
Manual
2012-2013
Models –EMU-Mini & EMU-Max
Page 2
Table of Contents
Front Cover-----------------------------------1
Table of Contents---------------------------2
Technical Information----------------------3
Warning Statement-------------------------4
Safety Warning------------------------------5
EMU Parts List-------------------------------6
Tool Kit & Assembly------------------------7
Installing the Handlebar-------------------9
Connecting Electric Plugs----------------10
Removal of Battery Cover---------------11
Battery Connection------------------------12
Folding the Handlebar--------------------13
Installing Basket----------------------------14
Charging Batteries-------------------------15
Riding your EMU---------------------------16
Adjusting Brakes---------------------------17
Remote Key Fob---------------------------18
Maintenance--------------------------------19
Trouble Shooting---------------------------21
Warranty--------------------------------------22-23
Page 3
Technical Information
Type of Motor 48V Permanent Magnet Brushless DC Motor
Motor Power 350W (Mini) 500W (Max)
Battery Type Sealed Lead Acid Batteries (Mini) x 4
Lithium Batteries (Max)
Battery 14AH 48V
Charger UL Approved 110v
Charging Time 4-8 hours
Rated Speed (2 speed) Mini 0-5mph & 0-15mph*
Max 0-8mph & 0-20mph *
Single Charge distance Mini Up to 15 miles*
Max up to 20 miles*
Maximum Capacity 285 lbs
EMU. Net Weight Mini around 90 lbs
Max around 70 lbs
*Note: Speed and distance may vary depending upon the terrain and weight
load.
Page 4
Warning Statement
STOP ----- IMPORTANT!
Before you ride your EMU please read this carefully:
Your existing insurance policy may not provide coverage for your
EMU trike of electric vehicles. You should contact your insurance
company to confirm if coverage is provided.
Please do not ride your EMU until you have read this owners manual
completely and you fully understand all its contents. This manual
contains critical information for your safety. If you have any questions
about the safe operation of your EMU, you should contact your
authorized EMU dealer.
It is very important that you follow all the safety instruction within this
manual in order to ensure maximum safety.
Failure to comply with all the standards outlined in this manual could
result in fire/ or serious injury.
American Scooter Company or authorized dealers will not be liable
for any damage or injuries caused by unsafe or faulty assembly or
unauthorized repairs. Any repairs carried out by unauthorized service
technicians are the sole responsibility of the owner and the Warranty
becomes void. Always follow local laws to where you can ride your
EMU.
Our EMU range of products are designed to be ecologically
conscious, please dispose of used batteries in compliance with local
laws.
Page 5
Safety Warning
(Please read before riding your EMU)
Before riding your EMU please read and be sure you understand this manual
completely. The EMU is not a toy and should always be operated in a safe
manner. American Scooter Company will not be liable for any damages or
injuries to any person. Any questions you may have about the safe operation of
your EMU should be directed to your authorized dealer.
Failure to comply with the safety warnings and operating instructions included in
this manual could result in serious injury to the operator and to others.
The EMU is not designed for all user repairs. An authorized EMU repair
technician should carry out repairs. American Scooter Company will not be liable
for any damage or injuries due to repairs by unauthorized individuals.
The EMU should only be operated by individuals 16 years of age or older.
The EMU is not a toy and should always be used responsibly.
Safety Instructions
Always wear approved safety equipment when operating the EMU.
Observe the maximum weight capacity of 265 lbs.
No more than one person should ride the EMU at a time.
The EMU should always be operated in a safe manner under safe
conditions. Observe local laws.
Before riding, inspect the EMU to insure all quick releases and pivot points
are secured properly. Make sure handlebars are secured and hand brake
is in operating condition.
Check the battery to insure it is properly charged.
The power ignition must be off when charging.
Remove your EMU from charge once it is charged. Do not leave charger
plugged in any longer that 8 hours.
Charge the battery after when required.
Do not expose the EMU, batteries or charger to wet conditions.
Always drive on paved surfaces.
Be careful when riding on wet or uneven surfaces.
Page 6
12
EMU Parts List
!" #$%&'()*++,(
-" .$/0(1$23+(
4" 5,+6'$76(0%'%$(
8" 9+2:,7;*'(<=%:>(
?" #$%&'(@%$3(
A" 12B3+'(<%='7%&2,>(
C" #%,:7&;(92&:,+D2$(E%&&+6'7%&(
F" G;&7'7%&(H+I(<=%:>(
J" K*$%'',+(
!L" (9+2:,7;*'(MN7'6*(
!!" O$++&(1/''%&(@%$(9%$&(
!-" 92&:,+D2$(*+7;*'(2:P/B'0+&'(
!4" Q%N+$(G&:762'%$(<=%:>(
!8" M+2'(Q%B'(<R='7%&2,>(
!?" M+2'(9+7;*'(S:P/B'0+&'(
!A" 92&:D$23+(
!C" M2@+'I()*++,B(
!F" T+2$()*++,B(
!J" 12''+$I(E%U+$(
-L" 5,+6'$762,(E%&&+6'%$B(
1
2
3
4
5
6
7
8
9
10/ 8
11
16
14
15
17
18
19
20
12
Page 7
Tool Kit
Charger
Tool Kit
Assembling the EMU
1/ Unpack the E.M.U. and
inspect all the parts to insure
all are included. Please
contact your E.M.U. dealer
immediately if any parts are
missing or damaged when
shipped.
Place your E.M.U. on a flat,
clean surface. Place a block
3.5” under the front, by the
battery. This will make it
easier for the next step.
Page 8
2/ Remove the bolts and nuts
from the connecting tube
clamp (B). place the
connecting tube into the top
opening (A). Align the bolt
holes.
3/ Slide the two bolts
(1) through the holes
connecting tube and
neck. Twist the bolts,
do not hammer them
through.
4/ Tighten the bolts and nuts
(2) using the 2 allen wrenches
in the tool kit. Also tighten the
small bolts on the outside of
the tube clamp securely (B).
Note some models may have
hex bolts instead.
B
Page 9
Installing the Handlebar
Extend the handlebar tube
to full upright position and
insert it into the
connection hole on the
front forks.
6/ Ensure the handlebars
are facing front with the
brake on the left and the
throttle on the right, then
tighten the handle bar hex
bolt securely. Fold
handlebar down to the left
hand side and tighten hex
bolt
Hex Bolt
Page 10
Connecting the Electrical power plugs
6/ Make sure you connect
the 4 the connectors to the
right outlets. You will damage
your emu electrics if you
connect them wrong. All
connectors are color-coded.
7/ Match the pins of the
plugs to the holes of the
sockets, align the notches
and secure.
8/ The height of the
handlebars can be
adjusted by opening
the quick clip release
the raise the
handlebars by pulling
or pushing on the
crossbar, then firmly
closing the quick
release clip.
