www.ener-j.co.uk
6
Specification
Power supply 3.7V/800mAh rechargeable
Li-ion battery
Static Current <20 uA
Alarm Current <25mA
Alarm output photo-sonic alarm
Alarm volume ≥95db
Operated temperature -10 to 45ºC
Operated humidity <97%
Size R=5.25(cm) H=3.2(cm)
LED indicator
Self-testing condition lighting one time every 1.67s
Monitoring condition light one time every 40s
Alarming condition lighting one time every
second
Products Structure
PCB
Installation and Usage Specification
Noted
Confirm the monitor area and fixup the bracket on the cell
or roof of the monitored area with two bolts. Then open
the cover of the detector and turn on the power supply and
close the cover. In the end, fixup the detector on the bracket.
1080P HD video, two million pixels
Security host alarm linkage
Wifi and wired network port
Support SD card video file loop storage
Support remote download video files
Alarm video platform storage
Support NVR
Maintenance
After-sales service
The dust and other factors will letdown the sensitivity of the
detector so it must be test and maintain always.
Test the detector one time every week: press the test button
Clean the detector one time every half year: cutoff the
power and clean the dust with the soft brush.
1. This system is guaranteed for 1 year from purchase date
2. In guarantee period, loss resulted from use beyond
normal use, user’s factor, visitation of providence or other
force majeure is not in guarantee scope
1. Close the cover and the LED indicator and testing/restore
button should be correspond with the hole.
2. Do not fixup the detector to the vent, ventilator and door
and etc.
3. The distance between the detector and corner should be
over 0.75 meter.
4. Should be dustproof and dampproof.
5. You need to program smoke sensor into alarm host panel,
detailed step is: please take out alarm host panel firstly,
press “SET” from alarm host → Enter code( input the 6-digit
code, default: 888888) → ENT→ choose menu ”Program
Sensor” → Zone Number (press “ ” button to delete old
record, and input 03, you can randomly choose from 02
to 10) → Group Number (press “ ” button to delete old
record , and input 00, you can also choose to put 01 or 02
or 03, other digits won’t be recognized) → choose “program”
from “learn\delete” → Trigger smoke sensor twice (you can
release some gas by lighter near the gas sensor) → when
alarm host panel successfully get signal from sensors, will
show ‘success’ in LCD screen, or else, please try from very
beginning again.
Outdoor IP Camera
Product NameSKU Code
SHA5101 Smart IP Camera Indoor (Also is a HUB)
SHA5102 Long Range PIR Sensor with inbuilt
rechargeable lithium battery
SHA5103 Door Sensor with inbuilt rechargeable
lithium battery
SHA5104 Smoke Alarm with inbuilt rechargeable
lithium battery
SHA5105 Remote for On/Off the Alarm
SHA5106 Outdoor Siren with Solar (no need to wire
to mains or charge again)
SHA5107 Smart IP Camera Outdoor IP65
SHA5108
Complete Mini Automation Kit
(1x Smart IP Camera IP20, +1x PIR Sensor,
+1x Door Sensor, +1x Co2 Detector Sensor, 1
ON/OFF Alarm Remote, 1 Outdoor Siren & 1
IP65 outdoor camera)
