ENERMAX LED CASE FAN Manuale utente
LED Case Fan Series
LED Case Fan Series
Features
w w w . e n e r m a x . c o . u k
Bright Colours
Due to its patented circular LED light with 18 diodes, Apollish Vegas shines four times brighter than ordinary LED fans.
Spectacular Effects
Variety of seven different LED modes. External control unit for switching between various effects.
Curved LED flashes
High-resistant sputtering finish for long-lasting brilliance and extraordinary light reflexes.
Adjustable speed
External control unit for manual speed control. The control unit can be mounted outside the case.
Powerful cooling
High-pressure air flow up to 144m3/h (UCAPV12A).
Twister Bearing
Smooth and persistent silent thanks to patented Twister Bearing Technology (min. 100,000 hours MTBF).
Click Mechanism
Detachable blades for easy cleaning from dust.
Effective vibration reduction and comfortable installation
Four isolator mounts reduce vibrations and make the fan installation easier.
Brillant, curved LED light
Detachable fan blades
for easy cleaning
Easy installation and
effective vibration
reduction
External control unit for
manual speed control
and LED mode switch
Patented circular LED
light with 18 diodes
High-resistant, glossy
coating
UCAPV12A/14A -R
UCAPV12A/14A -BL
UCAPV12A -G
UCAPV12A -S
Twister Bearing Technology
Twister Bearing Technology
(patented)
Persistent low noise level
Longer life: up to 100.000 hours
MTBF
AMinimal contact area
For an effective noise reduction
BRotor with integrated magnet
For a frictionless and smooth motion
CSelf-lubricating bearing sleeve
Abrasion protection for a longer
lifetime
A
B
C
1
Magnetized steel ball
Self-lubricating nano bearing
Coils
Flexible magnets inside
the rotor
3
4
1
2
2
4
3
w w w . e n e r m a x . c o . u k
Switchable Light Effects
1. ALL LEDs ON 2. LIGHTHOUSE 3. PROPELLER 5. FLASH
FLASH
6. VEGAS
(2.–5. repeating)
VEGAS
7. ALL LEDs OFF
OFF
4. TRIPLE PROPELLER
Specifications
12cm 14cm
Dimensions (mm) B120 x H120 x T25 B139 x H139 x T25
Colours Blue BL / Red R / Green G / Silver SBlue BL / Red R
Type of Bearing patented Twister Bearing Technology
Surface high-glossy and high-resistant coating
LED Type patented circular LED light
LED Modes 7
Speed (RPM) 800~2,000 (+/- 10%) 700~1,500 (+/- 10%)
Air Flow (m3/h) 56.51~143.72 71.99~154.27
Static Pressure (mm-H2O) 0.971~2.383 0.855~1.772
Minimal Noise (dB(A)) 16 15
MTBF 100,000 hours
Input Power (W) 4.8 4.8
Input Current (A) 0.4 0.4
Rated Voltage (V) 12 12
Accessory 4 x isolator mounts, external control unit incl. adhesive tape for
easy mounting outside the case
Certifications & Standards
