EnGenius EP802 Manuale utente

EP 802

Extreme Range Digital

Cordless System

2,500 spuare meters•

Up to 2km(Open  eld)•

6 ﬂ oors•

10 Acre•

EP 802

Extreme Range Digital

Cordless System

2,500 spuare meters

Up to 2km(Open  eld)

Extreme Cordless Range

Offers more coverage than any other consumer rated cordless

telephone in PanEurope. Superior Multi Floor Coverage.

Penetrates Concrete, Wood and Drywall.

2-Way Radio

Multi-functional cordless system offers walkie talkie like

functionality which operates independent of the base station.

Users can take the EP802 handsets with them for a handy quick

and ef cient alternative to communications.

WiFi Friendly

The EP802 will not interfere with today’s wireless networks, unlike

your traditional 2.4 or 5.8 Ghz models available in today’s market

Easy Installation

The EP802 cordless systems can be setup in a matter of minutes

for basic Extreme Range coverage.

Exapandable Handsets

The EP802 system can start out with only (1) handset and ex-

pands to (9) handsets as needed.

38 Digital channel autoscan•

Longe range: up to 2km•

Expandable handset (up to 9 handsets)•

Multi-base (up to 4 bases)•

Vibration mode•

Multiple language (10 European)•

ETSI Caller ID supported•

Call log(Dialed/Received/Missed call)•

Date/Time stamp (For Caller ID)•

Key guard•

Call Timer•

Phonebook: 50 entries (16 characters + 25 digits)•

Handset speakerphone•

Two-way intercom•

Broadcasting•

Call hold•

Call barring (For outgoing call)•

Call manager•

Call park•

Flash (100ms ~ 900ms)•

Redial (Last 10 calls)•

Feature call•

Hearing aid compatible•

External handset/base antenna•

Built-in 2.5mm headset jack•

Optional outdoor antenna - sold separately•

Programmable PBX option key•

Inter operatable with previous EP801•

Applications

2.4/5.8 GHz Cordless

1.9 GHz DECT

EP802

EnGenius Europe

Veldzigt 30a

3454 PW Utrecht

The Netherlands

[email protected]

www.engenius-europe.com

+31-(0)30 669 1417

+44-(0)2 0323 91168

+49-(0)8 5122 60 982

+33-(0)9 7719 9128

+39-(0)2 4795 6128

Specications may be subject to change without prior notication.

Base Station Portable Handset

Frequency 863-865 MHz 863-865 MHz

RF Output Power Average: 5 dBm Peak: 7 dBm

Average: 5 dBm

Channel Spacing 50 kHz 50 kHz

Number of Channels 38 38

Modulation GMSK GMSK

TDD Frame Length 10 ms 10 ms

Number of Slots/Frame 2 2

Receiver Sensitivity <-116dBm (@ BER 10-2) <-116dBm (@ BER 10-2)

Antenna Gain 2 dBi 1.5dBi

Antenna Connector TNC Proprietary

Telephone Interface RJ11 x 2 NA

Channel Coding ½ rate Convolutional + CRC ½ rate Convolutional + CRC

Transmission Data Rate 42.667kbps 42.667kbps

Speech Coding 8 kbps G.729A 8 kbps G.729A

User Data Rate 32kbps duplex 32kbps duplex

Duplex Time Division Duplex (TDD) Time Division Duplex (TDD)

Multiple Access FDMA FDMA

Number of System ID 65536 65536

Ring Signal 20-50 Hz, 12-90 Vrms NA

Power Source AC/DC 12V/1A Adapter 3.7 V/1100mAh Li-Ion battery

Charger Current NA 550mA (550/850 mA for

desktop charger)

Operating Temperature 0 – 50 °C -10 – 60 °C

Regulation Compliance EN 301 489 (EMC)

EN 60950 (Safety)

EN 301 357-2 (RF)

EN 301 489 (EMC)

EN 60950 (Safety)

EN 50371 (RF safety)

EN 301 357-2 (RF)

EN 301 489 (EMC)

EN 60950 (Safety)

EN 301 357-2 (RF)

EN 301 489 (EMC)

EN 60950 (Safety)

EN 50371 (RF Safety)

Average: 5 dBm

Specications
