ENHANCED VISION Pebble-mini Manuale utente

Screen Size

™

3”

Users Manual

Congratulations on your purchase of the Pebble-mini from

Enhanced Vision. The Pebble-mini is a handheld electronic

video magnifier that you can take anywhere. Weighing less

than 4 ounces, and includes both near-viewing and table

reading modes. Small enough to fit in your pocket or purse,

the Pebble-mini is the ideal companion to provide

magnification on the go.

With the Pebble-mini, you can easily read bank statements,

coupons, prescriptions, restaurant menus, or sign checks -

anywhere you need portable magnification. The Pebble-mini

provides hours of low vision enhancement.

Featuring a built-in 3” LCD screen, the Pebble-mini allows you

to magnify images up to 10 times. A built in Freeze-Frame

feature allows you to capture any still image and adjust

magnification and change color. Seven different viewing

modes allow you to choose alternate color combinations based

on your personal preference.

The Pebble-mini includes a convenient carrying case, a built-in

neck strap, a rechargeable battery and an integrated battery

charger. Pebble-mini comes with a 2 year warranty.

This device complies with Part 15 of the FCC Rules. Operation is subject

to the following two conditions: (1) This device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses, and can radiate

radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and receiver.

– Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

– Consult the dealer or an experienced radio/TV technician for help.

Unauthorized changes or modication to this system can void the user’s

authority to operate this equipment.

If your Low Vision device has an option to connect to a TV, it must be used

with shielded interface cables in order to meet FCC emissions limits for

Class B digital devices. It is the responsibility of the user to use the shielded

interface cables supplied with the equipment.

FCC COMPLIANCE NOTICE

FCC Compliance Notice

Chapter 1: Safety Precautions

General Guidelines 6

Transportation 7

Care & Maintenance 7

Chapter 2: Package Contents & Controls

Package Contents & Controls 8-9

Accessories 8-9

Chapter 3: Using the Pebble-mini

Power Options 10

Connecting the Power Supply 11

Turning the Power On/Off 12

Selecting Viewing Modes 13

Capturing an Image 14

Recalling an Image 15

Deleting a Saved Image 15

Deleting All Saved Images 15

Chapter 4: Using the Menu

Menu 1 (Brightness, Light, and Key Click) 16

Menu 2 (Color Modes) 17

Menu 3 (Audio, Restore, and Firmware Version) 18

Menu 4 & 5 (Changing Languages) 19

Table of Contents

Chapter 5: Connecting to your PC

Uploading Images to Your PC 20

Updating your Pebble-mini firmware 21

Chapter 6: Charging & Using Battery

Using Rechargeable Battery 22

Replacing the Battery 23

Battery Charging Procedure 23

Battery Charger Status Indicators 24

Chapter 7: Tips for using the Pebble-mini

Attaching the Neck Strap 25

Using the Carrying Case 25

Chapter 9: Troubleshooting

Troubleshooting 26-27

Chapter 10: Specications

Specifications 28-29

Chapter 11: Warranty Information

Warranty Information 30-31

Chapter 12: Other Enhanced Vision Products

Other Enhanced Vision Products 32-33

Table of Contents

6Chapter 1 Safety Precautions

For your safety and to obtain the most benefit and life from the

Pebble-mini, please read these important safety precautions

carefully.

General guidelines for use:

▶Follow all warnings, cautions, and instructions marked on

the product.

▶Use only Enhanced Vision provided battery.

Using other battery will void your warranty and could cause

damage to the product and/or pose personal safety risk.

▶Use care when using the Pebble-mini outdoors – it

should NOT be exposed to extreme or rapid changes

in temperature or humidity.

▶Do not place the Pebble-mini near a radiator, heater, or

areas exposed to long hours of direct sunlight.

▶Prevent the risk of electrical shock by NOT

attempting to disassemble the unit. Please refer all service

to an authorized repair facility.

▶Do not use the Pebble-mini in, near, or around water.

The Pebble-mini is not designed to offer protection against

contact with liquids of any kind.

▶Do not use the Pebble-mini during an electrical storm,

lightning, or other severe weather.

▶Do not use the Pebble-mini near open ames, ammable

materials, or liquids.

SAFETY PRECAUTIONS

Chapter 1 Safety Precautions

Transportation:

▶Pebble-mini comes with a convenient carrying case for

transport. To prevent the unit from being accidentally

dropped and damaged, always return the Pebble-mini to

the carrying case while not in use.

▶While in use, securely attach and use the neck strap

to avoid damage to the Pebble-mini caused by an

accidental drop.

Care & Maintenance:

▶If needed, clean the surface of the Pebble-mini with a

soft damp cloth or an electro static dusting wipe. DO NOT

use liquid cleaners on the plastic surface. No additional

methods of sterilization or cleaning are recommended

or required.

Susceptibility to Interference:

There may be temporary performance degradation of the

Pebble-mini when subjected to a strong magnetic and/or

radio-frequency field, electrostatic discharge or transient

electrical noise. An electrostatic discharge (caused by static

electricity) may cause image distortion. If this happens, switch

the unit off and try moving the unit to a different location.

8Chapter 2 Package Contents & Controls

1. Pebble-mini (Battery included inside)

2. Neck Strap

3. Carrying Case

4. USB Cable

5. AC Adapter Power Supply With Interchangeable AC plugs

6. Lens Cloth

7. Pebble-mini Stand

A. Scroll Wheel

B. Capture Button

C. Recall

D. LCD Screen

E. Zoom (+) and Zoom (-) Buttons

F. USB Input

G. Speaker

H. Power Button (On/Off)

I. LED Lighting

J. Battery Compartment (Integrated Charger)

Please refer to the illustrations on the next page to identify the

package contents and controls of your Pebble-mini. In addition to

this users guide, you will find the following items inside the box:

Please note the locations of the following controls on your

Pebble-mini:

PACKAGE CONTENTS & CONTROLS

Chapter 2 Package Contents & Controls

10 Chapter 3 Using the Pebble-mini

Power Supply

1) Included within your Pebble-mini

magnifier box is a main power supply

and multiple inserts for the outlets of

various countries.

2) To install choose the correct insert

for your country.

Power Options

Your Pebble-mini can be powered using:

▶The included AC adapter power supply and USB cable.

▶Rechargeable Battery (installed)

When using the Pebble-mini for the first time, please

power the unit using the included AC adapter power

supply and USB cable. This will ensure

that the rechargeable battery can fully

charge, even while the Pebble-mini is

in operation.

USING THE PEBBLE-MINI

Figure 1

Figure 2

Figure 3
