EN-898X USER MANUAL
1. Introduction…………………………………………….2
2. Specification………………..…………………………..6
3. Setup
3-1. Installing the server board………………………….7
3-2. Adding components to the server board……12
3-3. Reattaching the cover…………………………..12
3-4. Installing optional peripherals and devices
Hard Drives………………………………………….13
CD-ROM/FDD………………………………………..16
Power Supply………………………………………..17
Fan……………………………………………………..18
PCI Slot……………………………………………………22
3-5. Installing 2U in the cabinet……………………..25
4. About the Back Plane………………………………...25
5. Connecting the control plane……………………….29
6. About the LED panel and front panel………………30
7. About Screws…………………………………………..32
9. About SAF-TE…………………………………………..33
10.SCSI MANAGER……………………………………….34
11. Addenda (898X series compare)………………………45
2
Introduction
The EN-898X 2U Rackmount Chassis is a brand
new product from Enlight Corporation. It provides the
perfect solution for users who need a compact 2U
rackmount server chassis.
The En-898X series is an ISP’s 2U workhouse
perfect for caching, proxy, DNS, Firewall, application.
With 4x 3.5'' (8982: 6×3.5''/ 8983: 9x 3.5'') one inch hard
disk in tray and slim CD-ROM and standard floppy disk
drive bay，5.25'' drive bay; you can stack the 2U units
inastandard19''rackcabinet.Witha300W(8982/8983:460
W) for single and redundant power supply and support
up to full ATX motherboard, Enlight’s EN-898X offers
the freedom to integrate this system to meet your
needs. Whether it’s a firewall, mail, DNS, application or
single host server, this EN-898X will serve your needs
efficiently and reliably. This 2U solution is the easiest
and quickest way to expand your capacity.
3
8981
4
8982
5
8983
notice: this pictures are just for reference.
6
Specifications
EN-898X Rackmount Chassis Specifications
Mainboard for factor follow SSI & ATX 12” x 13” specification
Power Supply follow SSI (provide 480W Single Power Supply)
LED Indicators Front Bezel:
Voltage alarm(Voltage =5V, Beep Alarm LED
Blinking 4.57 －5.51/ Voltage =12V, Beep Alarm LED
Blinking 11.25-12.7)
FAN fail(Below 2800 rpm Beep Alarm LED Blinking),
Temperature alarm(Over 60℃and return to 55℃Beep
Alarm LED Blinking)
HDD activity, Power, NIC activity, System error
Pre HDD Tray: Active & HDD status x 1 (twin color LED)
Cooling Fans 8981:4 x internal 80 x 80 x 25mm cooling fans
8982/8983: 4 x internal 80 x 80 x 38mm Easy-swap cooling
fans /3 x rear 40 x40 x 20mm cooling fans
Back Plane 8982:1(2 8983) SCSI Back plane support Ultra 320
Support up to 15,000 RPM SCSI hard disk
Support 1” SCA-2 HDD with ID setting
Drive Bays
Hard Disk Trays
IDE:
8981:4x 1” IDE drive bays
8982: 6 x 1” SCSI drive bays
8983: 9 x 1” SCSI drive bays
FDD 8981/8982:1 standard FDD bay
CD-ROM 8981/8982:1 slim CD-ROM bay and 5.25” drive bay
PCI Slot 898X C01 3 x standard PCI adapter slots
898X D01 6×Low-profile PCI adapter slots
898X E01 2x standard PCI adapter slots
Switch 1 Power switch 1 Reset switch 1 ACPI switch
1NMIswitch USB1 USB2
Annunciator FAN fail, Volt Alarm, TEMP Alarm
Dimensions (W x H x D) 430 x86.7x 674.2mm
Weight 8981:10.5 kg (chassis only) 8982/8983: 12.5 kg (chassis only)
7
Setup
WARNING
The power button on the front panel DOES NOT turn off the AC
power. To remove power from server, you must unplug the AC
power cord(s) from the wall outlet or the chassis.
3.1 Installing the Server Board
Installing the server board consists of the following steps:
1. Removing the cover.
2. Removing the riser card &Fan &pole
3. Mounting the server board in the chassis.
4. Cabling the server board to the other chassis components.
5. Adding processors and memory to the server board.
6. Adding the riser card &Fan &pole
8. Replacing the cover.
Removing the Cover
To remove the top cover of the system:
1. Press the keystroke and pull the cover back and remove it from
the chassis.(PIC 3.1)
2. Set chassis cover aside and away from immediate work area.
8
PIC 3.1
Mounting the Server Board
With the cover off, you can now mount the server board in the
chassis. Before you begin, make sure you have the server board
and other associated components (processors, memory, and
mounting hardware) available.
To mount the server board:
1 Fix the motherboard’s screws. And save the screws.
2 Fix the I/O shields. To position the shield correctly, the outline of
the connectors on the I/O shield should be view able from the
chassis opening.
3 Insert connector edge of the server board into the chassis first
making sure the connectors are properly seated in the I/O shield.
4 Lie board flat on the standoffs that are located on the chassis
floor.
9
5 Align the board by making sure the standoffs with shoulders are
inserted into their matching holes on the board.
6 Mount the board to the chassis by inserting the mounting screws
supplied with the chassis through the holes on the server board.
CPU Bracket:
To remove the CPU bracket:
Nip the hook of the bracket and pull the bracket, and then the
bracket is divorced from the hole of pedestal, pull right.
To mount the CPU bracket:
Nip the hook of the bracket, aims at the bridge type hook on the
pedestal to pull left.
The pedestal is used to support the Intel Xeon CPU.
10
Notice
The white screw is used to support the motherboard.
M/B Insulation PAD:
The M/B Insulation PAD above the pedestal will be used without
the CPU bracket.
