ENTRYPASS TECHNICAL –WIRING GUIDE
Version: 1.03
Last Updated: 22-06-2016
EP.N-MINI WIRING GUIDE
Copyright © Entrypass Corporation
ENTRYPASS TECHNICAL –WIRING GUIDE
Notes:
See http://www.entrypass.net/ for updates, revisions, and download the latest
installation manual
There are currently 2 version of EntryPass Platform1 Access Control System available for
different card number system
1) EntryPass Platform1 Access Control System (6 Digit Card Number System) cater for 6
digit card number installation
2) EntryPass Platform1 Access Control System (10 Digit Card Number System) cater for 10
digit card number installation
For EntryPass Platform1 Access Control System to work correctly, both control panel and
software MUST be using the same card number system
This software installation manual might be updated without prior notice
Please refer to separate EntryPass Platform1 User Manual for detail operation help. The
Official EntryPass Platform1 User Manual can be downloaded from our website under
“Download” section
Copyright © Entrypass Corporation
ENTRYPASS TECHNICAL –WIRING GUIDE
Technical Support
If you cannot find the answer to your question in this manual or in the Help files, we recommend you
contact your system installer. Your installer is familiar with your system configuration and should be able
to answer any of your questions.
Should you need additional information, please call our Technical Support Help desk, Monday to Friday
9:00 AM to 6:00 PM (GMT +8:00)
Method Details
Phone + 60 (3) - 8068 1929
Fax + 60 (3) - 8068 1922
Internet www.entrypass.net
Email support@entrypass.net
BEFORE YOU BEGIN
Copyright © Entrypass Corporation
ENTRYPASS TECHNICAL –WIRING GUIDE
CAUTION
Battery may explode if mistreated. Do not recharge,
disassemble or dispose of in fire. To prevent a risk of explosion do
not pry the battery out with a metal or conductive tool.
Preparing Your EntryPass Controllers
EntryPass controller contains numerous delicate electronic circuits and components which can become
damaged as a result of electrostatic discharge (ESD). Thus, prior to installation, please follow the instruction
below:
•Observe precautions while handling the circuit board assembly by using proper grounding straps and handling
precautions at all
•Visually ensure no onboard parts is broken, damage or contains burn mark
•Do not turn on the power supply until you completed all wiring and external add on devices installations
Instances of Non-Warranty
•Damage due to natural disaster, accident or human cause.
•Damage as a result of violating the conditions recommended in the user manual
•Damage due to improper installation
•Damage due to use of uncertified components
•Damage due to use exceeding the permitted parameters
Considerations Prior to Installation
Copyright © Entrypass Corporation
ENTRYPASS TECHNICAL –WIRING GUIDE
N-MINI Reader
Keypad Display Unit
Networked Lock Control
N-MINI Description
Copyright © Entrypass Corporation
ENTRYPASS TECHNICAL –WIRING GUIDE
N-MINI Reader Color Description
Red : +12VDC
Black : GND / 0VDC
Pink : Not In Used
Black : GND / 0VDC
Blue : Not In Used
Brown : Not In Used
White : Exit Reader D1
Green : Exit Reader DO
Orange : Not In Used
Yellow : Not In Used
Grey : Not In Used
Purple : Not In Used
Green : RS232 RX Separated
White : RS232 TX Separated
N-MINI Reader Color Description
Copyright © Entrypass Corporation
ENTRYPASS TECHNICAL –WIRING GUIDE
Networked Lock Control (NLC) Color Description
Networked Lock Control (NLC) Color
Description
Red / Yellow : +12VDC
Black : GND / 0VDC
Orange : Door Sensor
Yellow : Not In Used
Blue : Not In Used
Pink : Push Button
Red : +12VDC
Black : GND / 0VDC
Grey / Yellow : NO1
White / Blue : CM1
White : NC1
Brown : NO2
Grey : CM2
Green : NC2
Purple : +12Vdc Lock
Purple : +12Vdc Lock
Green : RS232 TX Separated
White : RS232 RX Separated
Copyright © Entrypass Corporation
ENTRYPASS TECHNICAL –WIRING GUIDE
White LCD Display
Enter Key
Numbered Keypad
Navigation Pad
LED Indicator
N-MINI Reader Keypad Display Unit
Copyright © Entrypass Corporation
ENTRYPASS TECHNICAL –WIRING GUIDE
Backup Battery
8-Bits Dip Switch
Buzzer
Lock Relay
Wire Connector RJ-45 Network Port
Auxiliary Input
Auxiliary Communication Port
32-Bits Processor
Power LED
Reset Button Cold Start Button
Heart Beat LED
Communication LED
RJ-45 LED
Networked Lock Control (NLC)
Copyright © Entrypass Corporation
ENTRYPASS TECHNICAL –WIRING GUIDE
ENTRYPASS
Power Supply Unit Specification:
•Switching Power Supply
•12V DC
•3 Amp (MINImum)
Power Supply Unit Specification
