Envi HH1012T Manuale utente

OWNERS

MANUAL

economical. safe. simple

TABLE OF CONTENTS

If you need Help p 2

Features and Beneﬁts p 2

Important Instructions p 2

What’s in the box p 3

Wall Mounting Instructions p 3

Locking Bar Feature p 4

Hardwiring Instructions p 4

Operating Instructions p 6

How the Envi Works p 6

Unique Safety Features p 6

Grounding p 6

Optimal Operating Conditions p 6

Maintenance p 7

Storage p 7

Troubleshooting p 7

Speciﬁcations & Certiﬁcations p 7

Warranty p 8

MODELS COVERED BY THIS MANUAL

475 Watt - 120 Volt Models:

HH1012T (Plug-In with Thermostat)

HH1012N (Plug-In No Thermostat)

HW1012T (Hardwired with Thermostat)

HW1012N (Hardwired No Thermostat)

475 Watt - 220 Volt Models:

HH1022T (Plug-In with Thermostat)

HH1022N (Plug-In No Thermostat)

HW1022T (Hardwired with Thermostat)

HW1022N (Hardwired No Thermostat)

475 Watt - 230 Volt Models:

HH1023T (Plug-In with Thermostat)

HH1023N (Plug-In No Thermostat)

HW1023T (Hardwired with Thermostat)

HW1023N (Hardwired No Thermostat)

DCN-630013-110513

wall-mounted room heater

United States Patent: 8,477,176

Page 2

economical. safe. simple.

IMPORTANT INSTRUCTIONS

SAVE THESE INSTRUCTIONS

• Eliminates hot and cold spots where central heat is

ineﬀective.

• Ultra Safe - cool to the touch (90oF/32oC) can leave on

unattended 24/7.

• Healthy - won’t blow dust and allergens around or dry

out the air.

• Totally silent fanless teachnology.

• Auto-dimming of power light for dark bedrooms.

• Easy Installation – no drill required for mounting to wall.

• Slim - space saving design, only 2in (5cm) thin.

• Long life - No moving parts, crack resistance surface

• Now available in hardwired & USA 220volt models.

FEATURES & BENEFITS

• American Owned & Built with 3 year Warranty (USA )

• ISO 9001 Quality Certiﬁcation.

• Patented, eﬃcient “Stack Convection” Technology

• Adjustable Temperature control with simple operation.

• Wall-SensTM Technology, safety cut oﬀ feature.

• NEW!Internal Safety Locking Feature, locks heater to

wall using provided allen key tool.

• Convenient cordset storage inside the heater.

• Turn down the central heat thermostat and use envi

heaters where needed.

• Environmentally friendly - low power consumption.

THANK YOU FOR CHOOSING THE ENVI HEATER

Please take a few moments to thoroughly read the instructions and familiarize yourself with all the operational aspects, instal-

lation and care of your new Envi Heater. For your own records, please attach a copy of your sales receipt to this manual. Also,

write the store name/location, date, and serial number in the warranty section on the back of this manual (page 8).

MISSING PARTS? HAVE QUESTIONS OR NEED HELP?

(PLEASE DO NOT RETURN TO RETAIL STORE BEFORE YOU CALL THE ENVI HELP DESK)

We are here to help you with any questions you might have. Before you call for help though, please read this manual as it

contains instructions to help you to install, operate and maintain your heater properly. If you receive a damaged heater - please

immediately contact the dealer that sold you your Envi heater. If you still need help please call the Envi Help desk in the

USA/Canada Toll Free @ (800) 807-0107 or if calling from outside the USA call +1 (281) 516-1577.

HEATER WILL NOT OPERATE UNLESS MOUNTED

When using electrical appliances, basic precautions should

always be followed to reduce the risk of ﬁre, electric shock, and

injury to persons, including the following:

1. Read all instructions before installing or using this heater.

2. Extreme caution is necessary when any heater is used by or

near children or invalids, or when the heater is left operat-

ing and unattended.

3. Do not operate any heater after it malfunctions. Discon-

nect power at service panel and have heater inspected by

a reputable electrician before reusing.

4. For plug-in heaters, to disconnect, push power button to

turn heater OFF (the power indicator light will turn oﬀ),

then remove plug from outlet. Pull ﬁrmly on the plug, do

not unplug by pulling on the cord.

5. Connect to properly grounded outlets only.

6. For hardwired heaters, to disconnect, turn controls to oﬀ,

and turn oﬀ power to heater circuit at main disconnect

panel (or operate internal disconnect switch if provided).

7. Do not insert or allow foreign objects to enter any ventila-

tion or exhaust opening as this may cause an electric shock

or ﬁre, or damage the heater.

8. To prevent a possible ﬁre, do not block air intakes or ex-

haust in any manner.

9. A heater has hot or arcing parts inside. Do not use in areas

where gasoline, paint, explosive and/or ﬂammable liquids

are used or stored. Keep unit away from heated surfaces

and open ﬂames.

10. Use this heater only as described in this manual. Any other

use not recommended by the manufacturer may cause ﬁre,

electric shock, or injury to persons

11. Use only for the intended household or oﬃce uses as de-

scribed in this manual. Any other use not recommended by

the manufacturer may cause ﬁre, electric shock, or injury to

persons. The use of non-recommended attachments sold

by unauthorized dealers may cause hazards.

12. Do not use outdoors.

13. This heater is intended for use as a WALL MOUNTED heater

only. Failure to properly secure the heater to a ﬂat, level

and vertical wall may result in heater malfunction and/or

property damage.

14. This heater will not operate (power is disconnected) unless

it is attached to a wall using the supplied wall mounting

clips which engage the internal “wall-sens” safety switch.

15. DO NOT attempt to repair or replace any electrical or

mechanical functions on this unit. Doing so will void your

warranty. The inside of the unit contains no user service-

able parts. Qualiﬁed personnel should perform all servicing

only.

Page 3

economical. safe. simple.

Remove the heater, mounting kit, and packaging insert frame

from the box. Keep the packaging materials for future use.

1. Unwrap and ﬂatten the sides of the packaging insert

frame (mounting template) and stand the template on

the ﬂoor. The sides of the template have pre-punched

holes to mark the heater mounting height for either 6” or

or 8” (15 or 20cm) from the bottom of the heater to the

ﬂoor. Choose either mounting height, and mark three

hole locations on the wall. (see Fig. 1). The top two hole

locations are for the mounting clips and the bottom

location is for a third mounting screw hidden inside the

bottom access door as described in step 5 below.

NOTE:Mostinstallersusetheinternallockingbarscrew

insteadofthebottommountinghole.

2. Screw the anchors into wall at the marked locations .

(Fig. 2). The distance from the top screws to the ﬂoor

should be approx. 18”to 20” (45cm to 50cm).

If a stud is in the way, do not use the drywall anchor

supplied, just screw directly into the stud. The anchor

shown in the illustration is for drywall installation. For

masonry walls, use the masonry wall anchors provided

and drill a 4.5mm (3/16inch) hole using a masonry drill

bit (not supplied).

3. Screw the two mounting clips (with arrow pointing

upward) into the top two anchor locations and secure

ﬁrmly to the wall anchors using the provided screws.

(see Fig. 3). DO NOT overtighten. There should be a gap

behind the mounting clip to hang the heater on.

4. If you plan on using bottom screw, remove the bottom

access door before you mount the heater.

WHAT IS IN THE BOX

• 475 Watt Envi Wall Mounted Heater

• Owners Manual

• 2 x Mounting Clips

• 3 x #8 Mounting Screws

• 3 x Drywall Anchors / 3 x Masonry Anchors

• Locking Bar Screw and Allen Key tool

• Knockout Hole Grommet (hardwired models only)

• Wall Anchor Marking Template. Template holes are

marked on the outer edge of the packaging insert frame.

INSTALLATION INSTRUCTIONS

WALL MOUNTING

Fig. 3

supplied, just screw directly into the stud. The anchor

Fig. 2

Fig. 1

IMPORTANT MOUNTING TIPS

1) Only use the bottom mounting screw if you do not

intend to use the internal locking bar/screw mechanism.

2) The bottom mounting screw can be marked by hang-

ing the heater ﬁrst, then using the heater as a template.

3) The right hand side of the heater must be securely and

ﬁrmly pushed down on the clip to engage the “wall-sens”

power cut-oﬀ switch inside the heater. Align this side

of the heater ﬁrst, to ensure the switch is activated. For

uneven walls, a thin washer can be used to widen the gap

behind this clip to help seat the heater properly.

Fig. 1

17 3/4”

(451mm)

Mounting Clip

Hole Location-

Choose 6” or 8”

Height (15 or 20cm)

OPTIONAL WHEN

INTERNAL LOCK-

ING BAR USED!

Bottom Mounting

Hole Location

Choose 6” or 8”

Height (15 or 20cm)

Fig. 5

Page 4

economical. safe. simple.

HARDWIRING INSTRUCTIONS

The Envi Heater is available in some regions as a hardwired model: HW1012T / HW1022T / HW1023T (with built in thermostat)

and HW1012N / HW1022N / HW1023N (with no built in thermostat, instead a cover plate is in its place)

The Envi Heater can be hardwired direct to a mains supply, branch circuit or it can be hardwired to a line voltage external ther-

mostat of the same voltage as the heater (eg. 120v) or to an external switch or timer. Consult the instructions for each of these

control devices for speciﬁc wiring instructions. The Envi Heater can also be wired as multiple heaters on the same circuit or

controller. For these Multi-Heater Hardwiring instructions please consult the installation page of the website www.eheat.com.

The Envi Heater can also be hardwired to a 24volt thermostat using a 24v relay. Please consult a certiﬁed electrician and ensure

that all electrical work is done in accordance with applicable electrical and building codes.

CAUTION: To prevent short circuits and electrical shocks turn the power oﬀ at the main electrical panel before attempting the

hardwiring installation or any repairs. If the internal power cable (cordset) is damaged it must be replaced by the manufacturer.

NOTE: This hardwired heater must be connected to the correct voltage circuit according to its model designation, ie.

(HW1012 = 120volts, HW1022 = 220volts and HW1023 = 230volts). Disconnect the power supply before making wiring connec-

tions to prevent electrical shock and equipment damage.

WIRING SCHEMATIC

NOTE: The following wiring schematic is for a single Envi Heater installation to the applicable ac mains supply circuit and as-

sumes that the there are no external controls being wired into the unit. For wiring of external controls (thermostat/switches or

timers) please consult the website www.eheat.com for examples of external control wiring instructions.

5. Install heater on mounting clips (align right side ﬁrst) and

make sure to press down ﬁrmly on the heater to ensure a

secure ﬁt. You will hear it “snap”into place. (Fig. 5 above)

6. (OPTIONAL) Install the third screw inside the bottom access

door area (Fig. 6). Replace the door. Please note: for clarity

the cordset is not shown exiting the heater.

For additional information visit www.eheat.com

MOUNTING INSTRUCTIONS (CONT)

Fig. 6

NEW LOCKING BAR FOR PERMANENT ATTACHMENT

Fig. 7

The Envi Wall-Mounted Heater models now come with an additional

method to permanently attach the heater to the wall. A locking bar

mechanism is built inside the heater, which is engaged by screwing an

external locking screw into the bottom of the heater vent. The lock-

ing screw and Hex/Allen Key are both provided in the mounting kit.

This locking bar method is an alternate method to the existing bottom

screw installation procedure above, however many customers will ﬁnd

that the locking bar attachment method is suﬃcient by itself.

STEP 1 - Installing the Locking Bar Screw (Fig. 7) BEFORE YOU

MOUNT THE HEATER TO THE WALL. Take the locking bar screw out of

the mounting kit and while the heater is laying ﬂat, use the Hex/Allen

key provided to get the screw started in the hole at the bottom left

hand side of the envi heater (Fig 1). Screw the locking screw in about

3/8 of an inch (Fig 2) but make sure you do not screw it in too far as it

will obstruct the mounting holes at the back of the heater and prevent

mounting on the wall.

STEP 2 – Mount the Heater. Attach the heater to the wall by following the rest of the mounting instructions shown above.

STEP 3 – Tighten Locking Screw (Fig 7) Follow the rest of the mounting instructions to ensure the heater is properly seated on

the mounting clips and then tighten the locking screw to ﬁx the heater to the wall. DO NOT USE A POWER TOOL!!!

DO NOT OVERTIGHTEN, just turn the screw until the locking bar presses gently up against the left hand mounting clip inside the

heater. Congratulations,youhavenowpermanentlymountedyourEnviHeater!

Gently tighten Locking

Screw using supplied

Allen-key tool

Page 5

economical. safe. simple.

STEP 1

Determine the best wall mounting location of the Envi Heater in a room. If the proper electrical wiring and wall box already

exists at a suitable height on the wall, then choose a suitable knock-out hole on the back of the heater (4 holes to choose from)

and position the heater on the wall so that the knockout hole lines up with the electrical wall box.

If new electrical wiring and a wall box is to be installed, then it is

best to mount the heater ﬁrst and then determine the correspond-

ing location on the wall for the new electrical wiring wall box. When

installing a new wall box, ensure it is at a proper location on the wall

to allow the heater to remain at 6”to 8” (15 to 20cm) or so above the

ﬁnished ﬂoor level.

Turn the power OFF at the main electrical panel to the heater circuit.

Run the electrical wiring and secure it properly to the electrical box

per applicable electrical and building codes. (NOTE: Although the

Envi Heater has a low amperage draw (eg. 4amps@120v), the electri-

cal code requires a minimum supply wire gauge to be used, so make

sure you check ﬁrst.)

STEP 2

Mount the Envi Heater using the two mounting clips per the “Wall

Mounting Instructions” (see page 2) contained herein to ensure that

the heater is at the proper location on the wall and that the knockout hole is aligned with the supply wiring.

STEP 3

Remove the Envi heater from the wall to continue with the hardwiring steps. If not already done at Step 1, remove a knock out

hole (a screw driver can be used), on the back of the heater, and install the supplied protection grommet into the knockout

hole. The bottom access door is already removed and supplied in the mounting kit. Pull the supply wiring into the Envi Heater

and out through the bottom access opening. Then pull the Envi cordset wiring through bottom access opening, and using wire

nuts (not supplied) connect the heater wires L1 (live) , L2 (neutral) and G (ground) to the corresponding supply wires per the

wiring schematic above. Push the connected wiring/nuts inside the opening and re-attach the bottom access door.

NOTE: ENSURE YOU ONLY CONNECT 120VOLT SUPPLY VOLTAGE TO 120VOLT ENVI HEATERS. IF YOU ARE NOT SURE IF YOU HAVE 120VOLT

OR 220/240VOLT SUPPLY AVAILABLE - YOU SHOULD NOT BE PERFORMING THIS INSTALLATION! PLEASE HIRE A QUALIFIED ELECTRICIAN.

STEP 4

Re-mount the Envi Heater to the wall, ensuring all three mounting screws are used. Ensure that any wiring is pushed inside the

wall electrical box and is not trapped between the Envi Heater and the wall.

STEP 5

Turn the power ON at the main electrical panel to the heater circuit. Check that there are no obvious problems with the hard-

wiring to the heater (such as crackling noises, sparks or smoke) and if everything is okay, turn on the power to the heater by

pressing the on/oﬀ button. If the wiring has been performed correctly, then the power indicator light will glow red.

HARDWIRING INSTRUCTIONS (CONT.)

Knock-out Holes

1.5in (3.8cm) apart

(Twist to remove)

Hardwired

Cordset

Bottom Screw

(Optional - see notes)

GGROUND

WIRE

SUPPLY

VOLTAGE

(see note above)

Envi Heater

Hardwired

Models Only

Envi Heater Hardwired Cordset

Wire Color Guide

L1 = Black Wire (Live)

G = Green Wire (Ground)

L2 = White Wire (Live)

Page 6

economical. safe. simple.

HOW IT WORKS

The Envi Heater is designed with innovative “Stack Convection Technology” that eﬀectively heats a room with minimal energy.

The Envi’s inner chamber simulates “stacks”of varying height, which boost airﬂow through the heater to achieve maximum

eﬃciency. The end result is enhanced airﬂow at safe air temperature, all without the use of a fan. The Envi heater will provide

consistent, comfortable, silent heat without drying out the air or leaving cold spots in the room.

OVERHEAT SAFETY FEATURE

This heater is equipped with an overheat safety feature. When the heaters internal components reach a certain temperature

that could cause overheating and a possible ﬁre, the heater will automatically shut oﬀ. To reset the heater, unplug the heater

power cord from the electrical outlet for 10 minutes. After 10 minutes, plug the heater into the electrical outlet and turn on us-

ing the heater’s on/oﬀ switch located on the front of the unit.

WALL-SENSTM SAFETY FEATURE

In addition to the overheat safety cut-oﬀ, the Envi Heater is now equipped with an additional layer of safety to give you greater

peace of mind. Wall-SensTM technology means that in the event that the Envi heater is ever removed from the wall, power will

be immediately cut to the heater. This of course means that the heater will not work if it is simply removed from its packaging

and plugged into a wall outlet. It must be mounted properly (safely) and then plugged in (or hardwired) in order for it to be

begin to heat.

GROUNDING

Plug-in models of the envi heater are for use on standard electrical circuits (eg. 120v for USA/Canada). The cord has a three-

blade grounding plug. An adapter can be obtained at most hardware or electrical stores for connecting three-blade grounding

type plugs to two-slot receptacles. The grounding lug extending from the adapter must be connected to a permanent ground

such as a properly grounded outlet box. The adapter should not be used if a three-slot grounded receptacle is available.

DO NOT DEFEAT THE SAFETY PURPOSE OF THE GROUNDED PLUG.

OPERATING INSTRUCTIONS

1. Install the heater on a ﬁrm, level wall and plug the power cord

into a grounded power outlet (or hardwire it if applicable). The

heater will only operate when it is properly attached to the

mounting clips. Be sure to mount in upright position with the

thermostat knob on the top of the heater.

2. Once the heater is connected, press the front on/oﬀ power

switch and the POWER INDICATION LIGHT will glow red. (Fig. 5)

3. The Envi Heater is equipped with a built-in thermostat which is

adjusted with a dial at the top of the heater. Adjust the room

temperature by turning the THERMOSTAT DIAL clockwise to

increase the room temperature. If the area becomes too warm,

rotate the THERMOSTAT DIAL counter-clockwise until you reach a point where the temperature is more comfortable. (Fig. 5)

4. Once you have chosen the desired setting, the thermostat will maintain a constant temperature. NOTE: Models with no

thermostat have no temperature control and will stay on until the heater is powered oﬀ.

5. The heater is equipped with an innovative auto dimming feature that dims the power indication light for light sleeper in

darkened bedrooms. The heater automatically

detects when the light level in a room drops and then dims the power light.

6. The plug-in cordset of the Envi heater can be stored inside the bottom access door. Determine how much cordset you

require to extend out of the heater. Remove the heater from the wall, and remove the bottom access door. Carefully push

the excess cordset inside the heater and replace the bottom access door. Re-install the heater to the wall and plug-in the

cordset to continue using your heater. For more information please visit the installation web page of www.eheat.com

OPTIMAL OPERATING CONDITIONS

To get the most out of your Envi Heater, please follow these helpful hints:

1. VERY IMPORTANT!!! For optimal performance in a room, close all windows and doors and for ﬁrst time use, leave on

for 48 - 72 hrs. This will allow the room to reach equilibrium temperature while the heat is gradually building up.

2. For optimal performance, mount the heater on an interior wall with the bottom of the heater 6” to 8” (15 to 20cm) from the

ﬂoor. For smaller rooms this can be increased with little detriment, however try to keep the bottom of the heater a maxi-

mum of 18” (46cm) from the ﬂoor.

3. The 475 Watt Envi heater is designed to heat rooms 130 to 150 ft2feet in size (12m2to14m2). This equates to a 10ft x 14ft

room size (3 x 4meters). Of course, this will vary depending on a number of factor, including outdoor temperature, room

OPERATING INSTRUCTIONS

ThermostatThermostat

DialDial

PowerPower

LightLight

On/OﬀOn/Oﬀ

SwitchSwitch

Page 7

economical. safe. simple.

CARE & MAINTENANCE INSTRUCTIONS

OPERATING INSTRUCTIONS (CONT.)

TROUBLE SHOOTING

SPECIFICATIONS & CERTIFICATIONS

CLEANING

1. Unplug the unit and let it cool completely.

2. To remove dust from the Envi heater, use a soft cloth.

3. To remove marks or stains from the heater, the front outer shell can be cleaned with a soft, damp cloth. You may use a

mild detergent if necessary. After cleaning, dry the unit with a soft cloth. CAUTION: Do not let liquid enter the heater.

4. Do not use alcohol, acetone based cleaners, gasoline, abrasive powders, furniture polish, or abrasive or rough cloths or

brushes to clean the front of the heater. This may cause damage or deterioration to the surface.

5. Do not immerse the heater in water.

6. Wait until the unit is completely dry before using again.

STORAGE

Store the heater in a cool, dry location when not in use. However, the Envi Heater is a slim, attractive wall mounted heater

than can be left mounted on the wall year round.

If the heater will not operate, please check the following before seeking repair or service:

1. Check that the heater is correctly installed against the wall using the supplied mounting clips. The Envi Heater WILL NOT

OPERATE AT ALL unless it is mounted on a wall due to the inclusion new “Wall-SensTM Technology” safety feature!

2. Check if the heater is set to ON by conﬁrming the light on the front of the panel is lit. If not, press the on/oﬀ power

switch.

3. Check if the power cord is plugged into an electrical outlet, if not, plug it in.

4. If the heater has been hardwired, consult an electrician to check that all connections have been made correctly.

5. Check if electricity to the circuit is working. This can be found in your breaker box, check to make sure the breaker is in the

“on” position.

PRODUCT SPECIFICATIONS SAFETY LISTINGS

COMMERCIAL FIRE SAFETY COMPLIANCE & CALIFORNIA TITLE 24 CERTIFICATION

insulation, room draftiness, room objects, etc.

4. To save energy and to reduce your heating bills, place the heater in a room or area that needs extra heat instead of rais-

ing the thermostat on your central heating system. This heater will function very well as both a sole source of heat or as an

additional heating source that can easily maintain the temperature in most rooms and attached bathrooms if the correct

number of Envi heaters are installed. There is no need to increase the heat in the entire house when you only need comfort

in the room in which you are currently located.

5. We highly recommend that our customers weatherize their home to further reduce their heating bills. Simple tasks such as

replacing weather stripping around doors and windows, caulking door and window seams, sealing attics and basements

properly, and adding more insulation to your walls and ceiling will help further to reduce home heating costs.

Conforms to UL Std: UL 2021

Cert. to CAN/CSA Std: C22.2 No. 46-M1988

Conforms to IEC Std: 60335-1 & 60335-2-30

Conforms to AS/NZS: 60335.1 & 60335.2.30

Power Rating: 475 Watts (All Models)

Volt & Amp Rating: HH/HW1012 Models = 3.95 Amps@120volts

HH/HW1022 Models = 2.16 Amps@220volts

HH/HW1023 Models = 2.06 Amps@230volts

Unit Size: 19.3in W x 2.2in D x 22.2in H

(49.0cm W x 5.6cm D x 56.4cm H)

Net Weight: 10 lbs (4.5 kg)

Packaged Wt: 12 lbs (5.5 kg)

The Envi Heater is in compliance with the requirements of The Life Safety Code, NFPA 101 (2012), section 19.7.8. The Envi

heater is a ﬁxed wall heater (not portable) and operates with low surface temperatures and is thus suitable for commercial use

in Elderly Care, Childcare, corporate and government facilities. The envi heater is also compliant for California Title 24 use in

Residential New Construction, Alterations and Additions. Contact the manufacturer for a copy of the certiﬁcation.

Page 8

economical. safe. simple.

WARRANTY

Three Year Limited Warranty

1. The manufacturer warrants the accompanying Envi Heater to be free of defects in material and workmanship for the ap-

plications speciﬁed in its operation instructions for a period of THREE (3) years from the date of original purchase in the

United States of America. If the unit exhibits a defect in normal use, the manufacturer will, at its option, either repair or

replace it, free of charge within a reasonable time after the unit is returned during the warranty period.

2. As a condition to any warranty service obligation, the consumer must present a copy of the original purchase invoice.

3. THESE WARRANTIES DO NOT APPLY FOR:

• Damage, accidental or otherwise, to the unit while in the possession of a consumer not caused by a defect in material

or workmanship.

• Damage caused by improper installation or connection to incorrect supply voltage.

• Damage caused by consumer misuse, tampering, or failure to follow the care and special handling provisions in the

instructions.

• Damage to the ﬁnish of the case, or other appearance parts caused by wear.

• Damage caused by repairs or alterations of the unit by anyone other than those authorized by the Manufacturer.

• Freight and Insurance cost for the warranty service.

4. ALL WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANT ABILITY ARE LIMITED TO A THREE-YEAR DURA-

TION OF THIS EXPRESS LIMITED WARRANTY. THE MANUFACTURER DISCLAIMS ANY LIABILITY FOR CONSEQUENTIAL OR

INCIDENTAL DAMAGES AND IN NO EVENT SHALL THE MANUFACTURERS LIABILITY EXCEED THE RETAIL VALUE OF THE

UNIT FOR BREACH OF ANY WRITTEN OR IMPLIED WARRANTY WITH RESPECT TO THIS UNIT.

5. Note: This warranty does not renew or extend with a replacement product. All warranties are from the date of the original

product purchase.

6. This warranty covers only new products purchased from our authorized dealers or retailers. It does not cover used, sal-

vaged, or refurbished products.

7. As some states do not allow the limitation or exclusion of incidental or consequential damages, or do not allow limitation

on implied warranties, the above limitations and exclusions may not apply to you. This warranty gives you speciﬁc legal

rights, and you may also have other rights that vary from state to state.

Manufacturer’s Contact Information:

eheat, Inc. / Conservetec International

Tomball, TX, United States of America

Email: [email protected]

Phone: +1 (281) 516-1577

Web: www.eheat.com or www.envi-heat.com

Registration Details

Store Name:

Location:

Date Purchased:

Serial Number:

(Serial # is found on back of unit)

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Envi Stufa

Envi

Envi LE5012P Manuale utente

Manuali Stufa popolari di altre marche

oventrop

oventrop Regucor Series Manuale utente

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manuale utente

ELMEKO

ELMEKO ML 150 Manuale utente

BN Thermic

BN Thermic 830T Manuale utente

KING

KING K Series Guida

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guida rapida

Well Straler

Well Straler RC-16B Manuale utente

EUROM

EUROM 333299 Manuale utente

Heylo

Heylo K 170 Manuale utente

Eterna

Eterna TR70W Manuale utente

Clarke

Clarke GRH15 Manuale di istruzioni

IRSAP

IRSAP The Radiator Company Ovali Manuale utente

Empire Heating Systems

Empire Heating Systems WCC65 Manuale utente

Wetekom

Wetekom 92 86 43 Manuale utente

Desa

Desa SPC170-F Manuale utente

Watlow

Watlow Watrod Electric Tubular Heaters Manuale utente

Haverland

Haverland ECO-DRY GPS Series Manuale elenco delle parti

Stelpro

Stelpro ASILVC2060 Series Manuale utente
