OWNER’S

MANUAL

GSM070709

STEAM MOP

welcome!

Thank you for purchasing the Garry™ Steam

Mop. You’ll soon agree that this is the fastest

and easiest way to steam clean your ﬂoors.

You’ll simply be amazed at how beautiful

your ﬂoors can be. We guarantee it!

Please carefully review all the valuable

information contained in this manual prior

to use and keep this manual for future

reference.

Welcome to clean.

TABLE OF CONTENTS

IMPORTANT SAFETY INSTRUCTIONS 1

GROUNDING INSTRUCTIONS 2

PRODUCT SPECIFICATIONS 2

UNIT OVERVIEW 4

ASSEMBLY INSTRUCTIONS 5

PRODUCT FEATURES 6

INSTRUCTIONS FOR USE 7

CLEANING FLOORS 7

AFTER USE & STORAGE 8

TROUBLESHOOTING 9

REPLACEMENT MOP RE-ORDER 9

LIMITED WARRANTY 10

ARBITRATION AGREEMENT 11

PLEASE READ ALL SAFETY INSTRUCTIONS IN THIS PRODUCT MANUAL

BEFORE USING THE GARRY™ STEAM MOP.

KEEP THIS PRODUCT MANUAL FOR FUTURE REFERENCE.

1 2

IMPORTANT SAFETY INSTRUCTIONS

Read all instructions before using your Garry™ steam mop

When using electrical appliances, basic precautions should always be followed to

reduce the risk of ﬁre, electric shock, and injury to persons, including the following:

Do not direct steam at people, animals, or at electrical outlets.

Do not expose unit to rain.

Store indoors.

Unplug from outlet when not in use and before conducting maintenance or

troubleshooting.

Do not leave steam mop unattended while plugged in.

Do not service steam mop when it is plugged in.

Do not use with damaged cord or plug.

Do not use steam mop if it has been dropped, damaged, left outdoors or dropped into

water. Return it to a service center for repair.

Do not handle steam mop with wet hands.

Keep the steam mop away from water; do not allow it to get wet. If unit is wet, do not

plug unit into wall socket or turn unit on.

Do not pull or carry by cord, use cord as a handle, close door on cord, pull cord around

sharp corners or edges, or expose cord to heated surfaces.

Do not unplug by pulling on cord.

Do not use appliance in an enclosed space ﬁlled with vapor given off by oil-based

paint, paint thinner, some moth prooﬁng substances, ﬂammable dust, or other

explosive or toxic vapors.

Do not allow children to use the Garry™ steam mop.

Do not use on leather, wax polished furniture or ﬂoors, synthetic fabrics, velvet or

other delicate, steam-sensitive materials.

Do not immerse unit in water or other liquids.

Do not use for any purpose other than described in this user’s manual. Improper use will

void warranty.

Use only manufacturer recommended attachments.

Never put descaling, aromatic, alcoholic or detergent-based products into the steam

mop, as this may damage the unit.

Do not store with a wet mop pad still attached.

Close attention is necessary when used near children.

Using distilled or demineralized water will maximize the performance of your Garry™

steam mop.

Use on waxed or some unwaxed ﬂoors may diminish glossiness. Do not use on

unsealed wood ﬂoors. Test in an inconspicuous area or check the care instructions

from your ﬂooring manufacturer.

Use extra care when cleaning on stairs.

Do not use steam for space heating purposes; household use only.

SAVE THESE INSTRUCTIONS

THIS MODEL IS FOR HOUSEHOLD USE ONLY. COMMERCIAL USE OF

THIS UNIT VOIDS THE MANUFACTURER’S WARRANTY.

GROUNDING INSTRUCTIONS

This appliance must be connected to a grounded wiring system. If it should malfunction

or break down, grounding provides a safe path of least resistance for electrical current,

reducing the risk of electrical shock. The cord for this appliance has an equipment-

grounding conductor and a grounding plug. It must only be plugged into an outlet with

proper voltage which has been properly installed and grounded in accordance with all local

codes and ordinances.

WARNING: Improper connection of the equipment-grounding conductor can result in

electrical shock. Check with a qualiﬁed electrician or service person if you aren’t sure if the

outlet is properly grounded. DO NOT MODIFY THE PLUG. If it will not ﬁt the outlet, have a

proper outlet installed by a qualiﬁed electrician. No plug adapter should be used.

PRODUCT SPECIFICATIONS

Model: SM100

Power Consumption: 850W

Rated Voltage: AC 120V ~60hz

Net Weight: 1.9 kg (4.2 lb.)

Tank Capacity: 500 ml (16.9 oz.)

3 4

UNIT OVERVIEW Box Contents:

Remove all parts from the box and identify each of the items shown below before

disposing packaging.

1) Steam Mop Body

2) Lower Assembly Tube

3) Upper Assembly Tube

4) Mop Handle

5) Water Reﬁll Cup

6) Micro Fiber Mop Pad

A. Handle

B. Quick release hook

C. Cord guide

D. Water tank lid

E. Water tank

F. Lower cord hook

G. Steam adjustment

H. Indicator light

I. Swivel head

J. Upper assembly tube

K. Tube connection collar

L. Lower assembly tube

M. Tube guide

N. Power cord

O. Main body

P. Micro ﬁber mop pad

Q. Water reﬁll cup

1 5

5 6

Slide the handle over the top of the upper

assembly tube. Press the spring pin as you

do so. Gently guide the handle onto the tube

until the spring pin pops through the spring

pin hole. Verify the handle is facing forward

and that the quick release cord hook is on

the same side as the lower cord hook. Gently

rotate the handle if correction is necessary.

STEP 3

PRODUCT FEATURES:

• Steam makes it easy to clean tile, vinyl and

hardwood ﬂoors.

• The steam adjustment knob allows you to select

the level of steam you need for light or heavy-duty

jobs.

• The Garry™ Steam Mop is ready to clean in about

30 seconds.

• The transparent water tank allows you to visualize

exactly how much water is left and when to reﬁll.

See Figure1.

• Lightweight and portable, the Garry™ Steam Mop is

easy to store and won’t get in the way.

Figure 1

Insert the lower assembly tube through

the large opening in the water tank and

down into the tube guide with the end

that holds the spring pin. Gently press

the spring pin and continue to guide the

tube into the body until the spring pin

pops through the spring pin hole.

STEP 1

Slide the tube collar over the top of the

lower assembly tube unit it is fully inserted.

STEP 2

ASSEMBLY INSTRUCTIONS

7 8

INSTRUCTIONS FOR USE

CAUTION: Before ﬁlling the Garry™ Steam Mop with

water, make sure that the steam adjustment knob is

closed and the power cord is unplugged. See Figure2.

CLEANING FLOORS

1. Fully vacuum or sweep ﬂoors prior to using the

Garry™ Steam Mop.

2. Install the mop pad on the swivel head by

ﬁtting the pad over the head and tighten the

drawstring with the pad tightening clamp.

See Figure 3.

3. Unscrew the water tank lid and ﬁll the water

tank using the water reﬁll cup.

4. Release the cord by twisting the quick release

cord hook and removing the cord.

5. Plug the unit into an approved outlet as

outlined previously. When the indicator light

turns from red to green, the Garry™ Steam

Mop is ready for use; usually within 30

seconds.

6. Adjust the steam adjustment knob to desired setting.

7. To sanitize an area of your ﬂoor, place the Garry™ Steam Mop on the area for a minimum

of 5 seconds but no longer than 15 seconds.

8. When the Garry™ Steam Mop stops emitting steam, simply reﬁll the tank and continue

cleaning.

NOTE: To order more replacement mop pads, please refer to page 9 for our customer service

contact information.

WARNING:

Do not leave the mop on one spot for more than 15 seconds. Doing so could cause

damage to the surface. Do not install or remove the mop pad while steam is emitting

from the swivel head.

AFTER USE & STORAGE

Please read all instructions and warnings before any maintenance is performed.

1. Turn the steam adjustment knob from

Open to Close to shut off the steam.

See Figure 4.

2. Unplug the power cord from the

outlet.

3. Carefully remove the mop pad (if

used) from the swivel head. Use

caution as the mop head and pad will

still be hot.

4. Empty any remaining water from the

water tank before storing.

5. Machine wash the soiled mop pad and

tumble dry.

6. Wrap the power cord around the

upper and lower cord hooks.

7. To clean the Garry™ Steam Mop, wipe

down all outer surfaces with a soft

cloth.

8. Store the unit in the upright position

in a protected, dry area or hang by the

handle.

MOP PAD CARE:

The mop pads can either be handwashed or machine washed with warm water and tumble

dry. If needed only, use a non-chlorine bleach during the washing cylce.

Figure 4

Figure 3

Figure 2

9 10

ONE YEAR LIMITED WARRANTY

Your Garry™ Steam Mop is warranted to be free from defects in materials and

workmanship for one year from the original purchase date. Should the product

have a defect in materials or workmanship, we will repair or replace it without

charge to you (a shipping and processing fee may apply). To obtain service under

warranty, simply call our Customer Service Center toll-free at 1-888-544-3729.

This warranty does not cover damage caused by accident, misuse or any use other

than as intended and described in this product manual, or damage resulting from

failure to maintain and clean this product as speciﬁed in this product manual. This

warranty applies only to the original purchaser of the Garry™ Steam Mop.

Contact Info for Warranty Service:

Garry by Envion™

P.O. Box 9159, Van Nuys, CA 91409-8291

1.888.544.3729

www.envionproducts.com

Patents pending.

TROUBLESHOOTING

If you experience problems with your Garry™ Steam Mop, please review the following

before contacting customer support. If you still require further assistance, please refer

to the LIMITED WARRANTY near the end of this manual for Customer Support contact

information.

Problem: Reduced steam/no steam is coming out

Try the following:

• Make sure the water tank is ﬁlled

• Verify the unit is plugged into an approved electrical outlet and that the fuse or

breaker is functioning properly.

• Check that the steam adjustment knob is set to “open”.

Problem: Indicator light is not working

Try the following:

• Verify the unit is plugged into an approved electrical outlet and that the fuse or

breaker is functioning properly.

• Verify the plug is securely inserted into the outlet.

Problem: There is a peculiar smell coming from the unit

Try the following:

• If this is the ﬁrst time you are using the mop, continue using the product. The smell

may be due to new parts being heated up for the ﬁrst time.

• Discontinue use if problem persists and contact Customer Service or other qualiﬁed

technician for repair.

If none of these tips cover your speciﬁc problem, please contact the Customer Service

center by calling the number provided at the end of this manual.

FOR REPLACEMENT MOP PADS.

Please call our Customer Service Center toll-free: 888.544.3729

Mop Pad Part Number: SM100P

WARNING: To reduce the risk of ﬁre, electric shock or injury, unplug

appliance from outlet before servicing

11 12

NOTES:

ARBITRATION AGREEMENT

THIS ARBITRATION AGREEMENT (“AGREEMENT”) AFFECTS YOUR LEGAL RIGHTS AND REMEDIES

BY PROVIDING THAT DISPUTES BETWEEN YOU AND THE SELLER OF THIS PRODUCT (“COMPA-

NY”), MUST BE RESOLVED THROUGH BINDING ARBITRATION, RATHER THAN IN A COURT. PLEASE

READ THIS AGREEMENT CAREFULLY. YOU ACCEPT THE TERMS OF THIS AGREEMENT BY RETAIN-

ING THE PRODUCT(S) SHIPPED IN CONNECTION WITH THIS AGREEMENT (THE “PRODUCT”) FOR

MORE THAN FOURTEEN (14) DAYS AFTER RECEIPT. IF YOU DO NOT AGREE TO THE TERMS OF

THIS AGREEMENT, YOU MAY RETURN THE PRODUCT TO COMPANY WITHIN FOURTEEN (14) DAYS

OF RECEIPT AT NO COST TO YOU.

RESOLUTION OF CLAIMS OR DISPUTES.

Any claim or dispute between you and Company (or any of Company’s subsidiaries or afliates) arising out

of or relating in any way to the Product or this Agreement shall be resolved through nal, binding arbitra-

tion. This arbitration obligation applies regardless of whether the claim or dispute involves a tort, fraud,

misrepresentation, product liability, negligence, violation of a statute, or any other legal theory. Both you

and Company specically acknowledge and agree that you waive your right to bring a lawsuit based on

such claims or disputes and to have such lawsuit resolved by a judge or jury.

LIMITATION OF LEGAL REMEDIES.

All arbitrations under this Agreement shall be conducted on an individual (and not a class-wide) basis, and

an arbitrator shall have no authority to award class-wide relief. You acknowledge and agree that this

Agreement specically prohibits you from commencing arbitration proceedings as a representative of

others or joining in any arbitration proceedings brought by any other person.

ARBITRATION PROCEDURES.

a. Before commencing any arbitration proceedings under this Agreement, you must rst present the claim

or dispute to Company by calling 818-217-2500 and asking for the Legal Department and allowing Com-

pany the opportunity to resolve the claim or dispute. If your claim or dispute is not resolved within sixty (60)

days, you may commence arbitration proceedings in accordance with the terms of this Agreement.

b. The arbitration of any claim or dispute under this Agreement shall be conducted pursuant to the

American Arbitration Association’s (“AAA”) United States Commercial Dispute Resolution Procedures and

Supplementary Procedures for Consumer-Related Disputes. These rules and procedures are available

by calling the AAA or by visiting its web site at www.adr.org.

c. The arbitration of any claim or dispute under this Agreement shall be conducted in the State of Califor-

nia or the location in which you received this Agreement.

d. All administrative expenses of arbitration proceedings commenced under this Agreement shall be

divided equally between you and Company, except that: (a) if the claim or dispute that is the subject of the

arbitration proceedings is less than ten thousand dollars (US$10,000), you will be responsible for no more

than one hundred twenty-ve dollars (US$125) in administrative expenses; (b) if the claim or dispute that

is the subject of the arbitration proceedings is more than ten thousand dollars (US$10,000) but less than

seventy-ve thousand dollars (US$75,000), you will be responsible for no more than three hundred

seventy-ve dollars (US$375) in administrative expenses; and (c) if the claim or dispute that is the subject

of the arbitration proceedings is more than seventy-ve thousand dollars (US$75,000), then you will be

responsible for administrative expenses in accordance with the Commercial Fee Schedule provided by the

AAA. You acknowledge and agree that each party shall pay the fees and costs of its own counsel, experts

and witnesses

CHOICE OF LAW.

This Agreement shall be governed by the United States Federal Arbitration Act and the laws of the State

of California.

SEVERABILITY.

If any provision of this Agreement is declared or found to be unlawful, unenforceable or void, such provi-

sion will be ineffective only to the extent that it is found unlawful, unenforceable or void, and the remainder

of the provision and all other provisions shall remain fully enforceable.

Indice

Manuali Pulitore a vapore popolari di altre marche

Oreck

Oreck STEAM-IT STEAM100LRH Manuale utente

Beautural

Beautural YPZ-146 Manuale utente

MPM

MPM MZP-02 Manuale utente

Electrolux

Electrolux Refine 500 Manuale utente

Kärcher

Kärcher SC 3 Premium Manuale utente

Shark

Shark PRO Steam & Spray Istruzioni operative e di manutenzione

Jula

Jula 802-337 Manuale utente

Haan

Haan Floor Sanitizer MS-30 Manuale utente

Black & Decker

Black & Decker HSM13E1 Manuale utente

HOFFEN

HOFFEN GS-1231 Manuale utente

POLTI

POLTI VAPORETTO SYSTEME PRO Manuale utente

eta

eta AQUASIM PRO Manuale utente

Maxwell

Maxwell MW-3715 G Manuale utente

VAPamore

VAPamore Primo MR-100 Manuale

Bestron

Bestron AZQ016 Manuale utente

Nilfisk-ALTO

Nilfisk-ALTO Steamtec 312 Manuale utente

Tempo di saldi

Tempo di saldi SPINSCRUBBER Manuale utente

DOMENA

DOMENA HYGIAFLOR Manuale utente
