Enviro C34 Manuale utente

INSTRUCTION MANUAL

This Cool Surface System has been tested for compliance to Standards:

ANSI Z21.88-2014 and CSA Z2.33-2014.

This Cool Surface System has been approved for use on the ENVIRO C34/44/60 Direct Vent

replaces only and must be installed at the time of replace installation.

The following instructions must be followed in conjunction with the replace installation

instructions to comply with the standards and allow safe operation of the installed replace.

Version Française: www.enviro.com/fr.html

4001609

Cool Surface System

SIDE VENT [50-3455]

PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE

C Series

50-3455

6 7

General Information

Figure 1. Cool Surface System Side Vent - Parts Diagram

The purpose of this optional Cool Surface System, or CSS, is to naturally re-direct the convective heat

from the replace. Using this kit lowers the temperatures of the front wall for installations where a

TV, artwork etc. is desired directly above the replace. It can also be used if you are intending to use

combustible framing and combustible facing materials depending on conguration.

The Side Vented CSS is a modular system that can be installed in either a Horizontal or Vertical

orientation.

Note: You can install the Cool Surface System without the Combustible Facing Kit. Doing so requires a

non combustible facing material (see Owner’s Manual for replace installation instructions).

Note: Dual Convection Fan Kit (50-3212) may not be used in conjunction with CSS.

Prior to installation of the CSS make sure the desired location is large enough to comply with the

combustible clearances of both the CSS and the replace (see Owner’s Manual for replace installation

instructions). Refer to the Framing and ClearanCes section of this manual for the required installation

dimensions of the CSS in tis different congurations.

Please refer to Figure 1 to ensure that all CSS parts are accounted for and have not been damaged.

Item Description Item Description Item Description

1 Top Standoff 4 C34 Main Wall 7 C44 Extension

2 Main Body 5 C60 Extension 8 Bag of Screws

3Trimable Deector 6 Vent Collars

8.00

7.67

13.64

6.17

10.75

0.88

2.63

7.47

11.74

0.50

4.68 6.07

12.18

14.92

12.24

1.39

Figure 2. Cool Surface System Side Vent- Overall Dimensions

36.00

26.00

9.95

4.75

0.50

0.92 4.75

2.00

2.48

0.49

Dimensions

Figure 3. Combustible Facing Kit - Overall Dimensions

Framing & Clearances

QUALIFIED INSTALLERS ONLY

Figure 4. C-Series - CSS Front Framing & Rough Opening

Front Framing & rough opening:

Min. Height

51-3/8”

( 130cm)

C34 = 45” (114cm)

C44 = 55” (140cm)

C60 = 71” (180cm)

Min Framing and rough opening for C-Series. C44 Shown.

Framing & Clearances

QUALIFIED INSTALLERS ONLY

15.00” (38cm)

11.50”

(29cm)

Min. Height

to Ceiling

14.50

Min. Height

66.00”

(168cm)

Min. to

Ceiling

5” (12.5cm)

Min. Height

from oor

69.5” (176.5cm)

39” (99 cm) Min.

Length 5” dia. ex vent

(not supplied)

Min. Vent

The CSS has been designed to allow for installations where a vertical run of vent is required without

having to jog the vent pipe around the CSS. The horizontal vent shield supplied with the replace is not

required (see Owner’s Manual) when vertically venting and the vent pipe can simply be run straight up

between the side vents of the CSS.

Shown below in Figure 5 are the minimum framing and clearances for the CSS with the side vents

installed horizontally and when the replace is installed with the minimum allowable vent length:

Figure 5. CSS Horizontal Vent - Min. Framing & Clearances

minimum ClearanCes - horizontal instalation - minimum vent:

Framing & Clearances

QUALIFIED INSTALLERS ONLY

Min. Distance to

wall 5.00” (13cm)

Min. Ceiling

Height

18.75”

(48cm)

*15.75” (40cm)

11.5” (29cm)

Min. Dist

61.75”

(157cm)

*NOTE: 15.75” from the

header is required for min.

ceiling height. Rest unit on

lower standoff. There will be

a 3/4“ (2cm) gap on from

the top standoff to the

header in this confirguration.

Min Framing is 15” x 11.5”

3/4” (2cm)

Gap Shown

Min. Distance

to Ceiling

4.5” (11.5cm)

Min. Distance

to oor

64” (162.5cm)

minimum ClearanCes - vertiCal vent - minimum vent:

The CSS has been designed to allow for installations where a vertical run of vent is required without

having to jog the vent pipe around the CSS. The horizontal vent shield supplied with the replace is not

required (see Owner’s Manual) when vertically venting and the vent pipe can simply be run straight up

between the side vents of the CSS.

Shown below in Figure 6 are the minimum framing and clearances for the CSS with the vents installed

vertically and when the replace is installed with the minimum allowable vent length:

Figure 6. CSS Horizontal Vent - Min. Framing & Clearances

Min. Vent

39” (99 cm) Min.

Length 5” dia.

ex vent

(not supplied)

Initial Installation

QUALIFIED INSTALLERS ONLY

revised mantel requirements:

Refer to Figure 7, 8 for a combustible mantel installation, measurement is from bottom of the unit to the

bottom of the mantel.

If you are planning on installing a TV above the replace refer to page 9 to see the options available.

Note: Minimum height of mantle if you intend on using a surround is 31”

1 2 3 4 5 6 7 8 9 10 11 12 13 14

MANTLE HEIGHT

MANTLE DEPTH

Minimum Mantle Clearances

8” MANTLE

4”MANTLE

35”

34”

33”

32”

31”

30”

29”

27”

28”

12” MANTLE

Figure 7: Minimum Mantel Height

29 “

(74cm)

31 “

(79cm)

Min. Height

For Surround

33“

(84cm)

4” (102mm)

8” (203mm)

12” (305mm)

2-1/16”

(75cm)

Min. Height

to Ceiling

55-1/16”

(1399cm)

Initial Installation

QUALIFIED INSTALLERS ONLY

Figure 8. Mantle Instalation

Installation

tv installation Considerations:

If you are planning to mount a TV above your replace some considerations must be made to ensure

it is protected from the heat.

During testing temperatures did not exceed 121°F (49°C) midway up the front wall (Figure 9 &

10). There is no guarantee that these temperatures will not harm the longevity of your TV. Make sure

to consult your TV manufacturer’s specications to nd the maximum allowable operating temperature.

Since every home and installation is unique, temperatures should be veried at the time of install

if possible. If desired, front wall temperatures can be lowered to 104°F (40°C) with the use of a

mantle (Figure 10). Refer to Owner’s Manual for full mantle clearances. A TV should not be installed if

temperatures exceed the manufacturers maximum allowable temperature.

Installation and service must be performed by a qualied installer,

service agency or the gas supplier.

29°F 41”

21°F 35”

21°F 29”

24°F 23”

17°F 17”

20°F 11”

30°F 5”

0”

Above

Ambient

Height from

Opening

4” Mantle

29” from oor.

Combustible

Facing Kit

1/2” Combustible Base

Material (Drywall)

Up to 1” Combustible

Material.

NOTE: You cannot install a Surround

with the mantle at its lowest position.

Install mantle at 31” for a Surround

Min.

2-1/2”

(6.4cm)

Min. 2” (5cm)

Gap

Combustible

Facing Kit

1/2” Combustible Base

Material (Drywall)

Up to 1” Combustible

Material

29°F 41”

29°F 35”

29°F 29”

27°F 23”

35°F 17”

38°F 11”

49°F 5”

0”

Above

Ambient

Height from

Opening

1-1/2” Air Gap behind the TV.

(Typically provided by a wall

mount)

Figure 9. CSS - TV Clearances Figure 10. CSS - TV Clearances

TV must be 5” min from

discharge if no mantle

Installation

QUALIFIED INSTALLERS ONLY

duCt Collars:

Prior to replace installation, the two supplied duct collars

must be attached to the top of the replace as shown in

the steps below:

Step 1: Using a T20 screwdriver, remove the inner and

outer cover plates from the replace as shown (Figure

11). Each cover plate has four (4) mounting screws.

Both sets of cover plates are no longer required and can

be recycled. Retain eight (8) of the removed mounting

screws to secure the duct collars.

Inner Cover

Plate (x2)

Outer Cover

Plate (x2)

Figure 11. Cover Plate Removal

Step 2: Attach the supplied duct collars to the top

of the cabinet as shown (Figure 12). Secure the

collars by re-using the eight (8) screws saved in the

previous step.

Duct Collars

Figure 12. Duct Collars Installed

Figure 13. Trimmable Deector trim notches

Note: You can install the Cool Surface System

without the Combustible Facing Kit. Doing so

requires a non combustible facing material

(see Owner’s Manual for replace installation

instructions).

Step 1: Prior to installation of the CSS Combustible

Facing Kit determine your unit. Then retreive the

trimable defelctor. The deector is trimable to t the

unit being installed. It comes in the length required

to t a C60 and must be trimmed to t either the

C44 or the C34. Notches on the top and bottom of

the trimable deector show where to cut it. The rst

notch on the far left will size it for a C44 and the

second notch will size it for a C34.

Combustible FaCing Kit (optional):
