EO Genius & EO Hub
Installation Guide.
© EO Charging 2021
EO Genius & EO Hub Installation Guide
© EO Charging 2021
EO Genius & EO Hub Installation Guide
1.0 Introduction (p2)
2.0 Installation instructions: EO Genius (p5)
3.0 EO Hub installation & Wiring connections (p11)
4.0 Support (p31)
1
Contents
Introduction
Your EO Hub & EO Genius must be installed by an EO Approved
and onboarded installer.
The installation should be in accordance with the IET Code of
Practice for Electric Vehicle Charging Equipment Installation and
local regulations.
This document includes:
+ Installation instructions for EO Genius hardware.
+ EO Hub installation & Wiring connections.
+ How to power the EO Genius hardware for the rst time.
+ Support.
© EO Charging 2021
EO Genius & EO Hub Installation Guide
2
1.0
EO Genius & EO Hub Installation Guide
© EO Charging 2021 3
Introduction
This document is designed to
complement the EO Academy
training and does not replace
any onboarding or online
academy certications.
It is still mandatory for installers
to have made contact with our
onboarding team as not do so
can aect product warranty and
help via the support desk.
The details of all EO Academy
training can be obtained by
emailing:
onboarding@eocharging.com
Experience has shown that
often the most dicult part
of the installation is enabling
the communications between
the EO Hub and the EO Cloud
back oce portal. Therefore
it is recommended that the IT
settings (section 3.13, pg. 22)
are discussed with the customer
soon as possible.
1.0
1.02
Log in and access the EO Portal.
It is the Installers responsibility
to create the Host, and allocate
the appropriate Hub and
chargers accordingly on the EO
Cloud.
We recommend you do not
proceed until you have carried
out tasks described on the EO
Cloud user guide.
Please see the EO Cloud User
Guide for assistance.
1.03
Create the host (customer).
1.04
Allocate the EO Hub & charge
points.
Actions to take prior
to hardware install.
EO Genius & EO Hub Installation Guide
© EO Charging 2021 4
1.0
© EO Charging 2021
EO Genius & EO Hub Installation Guide
2.0 Installation
instructions for the
EO Genius.
5
Your EO Genius MUST be installed
by an EO Approved Installer. The
Installation should be in accordance
with the IET Code of Practice
for Electric Vehicle Charging
Equipment Installation and current
local regulations..Completing the
online EO Academy training is also
mandatory prior to installation.
2.03
Level the base plate against the
wall (or EO post). Fix the base
plate to the wall or post using
the 4mm holes.
2.01
Remove the EO charger and
base plate from the packaging.
2.02
Unscrew the locking plate (bar)
from the base plate using the
tool provided.
EO Genius & EO Hub Installation Guide
© EO Charging 2021 6
2.0
2.04
Unscrew the cover on the back
plate connector.
2.05
Using a hole cutter, cut a hole
into the rear plate connector for
the gland.
2.06
Fit the correct sized gland for
your power cable.
EO Genius & EO Hub Installation Guide
© EO Charging 2021 7
2.07
Unscrew the 6 screws (10
screws if installing a 3-phase
unit), feed the cable through the
gland and secure. Prepare the
ends and if stranded or multi-
stranded cable is utilised make
sure to t ferrules.
2.08
Connect the power cables to
the pins as shown – Single
Phase or Three Phase.
2.09
Replace the cover.
EO Genius & EO Hub Installation Guide
© EO Charging 2021 8
2.10
An additional screw is provided
should you need another earth.
2.11
Replace the locking plate and
screws to secure the unit.
Power up the unit and test.
EO Genius & EO Hub Installation Guide
© EO Charging 2021 9
2.0
The installer should select the
RCD and earthing conguration
in accordance with the IET
Code of Practice and local
regulations.
Note:Where the EO Genius
includes DC leakage protection
(DCL) a Type A RCD can be
tted at the supply. Otherwise
a Type B RCBO or equivalent
should be used. EO recommend
a dedicated 40A supply rated
circuit for each charging station.
2.12
Important Installation Information
Characteristics of power supply input Permanently connected to 230/400V AC supply
Characteristics of power supply output Supplies 230V AC to the vehicle
Normal environmental conditions Can be installed indoors or outdoors
Access requirements Can be installed with no access restrictions
Mounting method Stationary equipment intended for surface or post
mounting
Protection against electric shock Class II equipment
Charging mode (MODE 3) DO NOT USE: Adaptors, converters and cord
extensions with this device
Ventilation during supply of energy Does not support ventilation during charging
