Epson Elp-3000 Manuale utente

or transmitted in any form or by any means, electronic, mechanical, photocopying, recording,

or otherwise, without the prior written permission of Seiko Epson Corporation. No patent

liability is assumed with respect to the use of the information contained herein. Neither is any

liability assumed for damages resulting from the use of the information contained herein.

Neither Seiko Epson Corporation nor its affiliates shah be liable to the purchaser of this

product or third parties for damages, losses, costs, or expenses incurred by purchaser or third

parties as a result of: accident, misuse, or abuse of this product or unauthorized modifications,

repairs, or alterations to this product, or (excluding the U.S.) failure to strictly comply with

Seiko Epson Corporation’s operating and maintenance instructions.

Seiko Epson Corporation shall not be liable against any damages or problems arising from the

use of any options or any consumable products other than those designated as Original EPSON

Products or EPSON Approved Products by Seiko Epson Corporation.

EPSON is a registered trademark of Seiko Epson Corporation.

EPSON Connection is a service mark of Epson America, Inc.

General Notice: Other product names used herein are for identification purposes only and may

be trademarks of their respective owners. EPSON disclaims any and all rights in those marks.

4003816-01

Torrance, California, USA

3/24/95

Introduction

vii

Getting the Most Out of Your Projector

Optional Accessories

About This Manual

Safety Instructions

Where to Get Help

CompuServe online support

1 Installation

Unpacking the Projector

Additional components

Setting Up the Projector

Connecting to a Computer

Connecting to a PC desktop computer

Connecting to a PC laptop computer

viii

Xii

xiv

Contents

111

Connecting to a desktop Macintosh

Connecting to a PowerBook

Connecting to a Video Source

Connecting to an Audio Source

Connecting to an External Speaker or PA System

Setting Up Serial Communication

Connecting the serial cable

Installing the software

Connecting the Remote Control with the Lead Wire

2 Using the Projector

Turning the Equipment On and Off

Focusing

and

Positioning the Screen Image

Controlling the Projector

Adjusting the settings from ELP Link

Monitoring the Projector

Using Rear Projection

3 Using the Menus

Accessing the Menus

Changing menu settings

Accessing ELP Link menus

Restoring the default settings

Menu Settings

Computer menu

Contents

Video menu

Display menu

Audio menu

Options menu

Custom menu

Remote Control of the Computer

ELP Remote Programmer Templates

Starting the ELP Remote Programmer

Assigning a Macro to a Programmable Button

Using record mode

Using manual mode

Activating a Template

ELP Remote Programmer Menus

5 Maintenance

Cleaning the Lens

Cleaning the Projector Case

Cleaning the Air Filter

Cleaning the Trackball

Replacing the Lamp

Replacing the Fuse

Contents

6 Troubleshooting

Problems with the Projector

Problems with the Image or Sound

Problems with the Remote Control

A Technical Specifications

General

optical

Projector Lamp

Mechanical

Electrical

Environmental

Supported Monitor Displays

Pin Assignments

Glossary

Index

Contents

Introduction

compact, lightweight EPSON” ELP-3000 Projector allows you to project

computer images and video onto a large screen for full-color presentations. The

projector can connect simultaneously to two image sources; one can be your PC

or Apple” Macintosh’ computer and the other can be a video source, such as a

VCR, camcorder, digital camera, or laser disk player. Audio can be supplied with

one or both image sources.

Images are displayed in up to 16 million colors at a resolution of 640 x 480

pixels. The projector’s 250-lumen bulb produces bright images that can be easily

seen in rooms light enough to take notes. You can play audio on the projector’s

internal speakers or route it to an external speaker for amplification. You control

the projector through a hand-held remote control, which allows you to switch

between image sources and make adjustments to the projected image.

The projector supports any computer capable of VGA output, including IBM

compatible PCs and laptops and Apple Macintosh computers, including the

PowerBook™ and Power Macintosh.” The video source can be NTSC, PAL,

and SECAM in composite video or S-Video format.

vii

Getting the Most Out of Your Projector

The projector comes with a full set of features that allow you to control the

settings for the image display, video, and audio. To get the most out of your

projector, read this section for a quick summary of the important features.

Remote control

The buttons on the remote control allow you to directly change the volume,

control the brightness, or switch from one image source to the other. Additional

adjustments can be made by using the buttons on the remote control to access

the projector’s menu system.

The menus, which you can superimpose on the projector image or display on

your computer screen, allow you to do the following:

Control the brightness, contrast, sharpness, color, and position of the image.

Adjust the volume, balance, treble, and bass settings.

Adjust the display by rotating or inverting it.

Additional settings are described in Chapter 3.

You can also use the remote control to control your computer if you install the

Serial Communication Kit.

viii

Introduction

Serial Communication Kit

The Serial Communication Kit allows your computer and projector to communi-

cate over an RS-232C connection. The kit includes an RS-232C serial cable and

two software utilities: ELP Link and ELP Remote Programmer.

ELP Link allows you to make adjustments to the projector from your computer.

The same controls that are available on your remote control, including the

ability to access the projector menus, are available from the main ELP Link

screen.

The ELP Remote Programmer allows you to use the remote control to control

your computer. The trackball moves the mouse on your computer monitor, and

five buttons on the remote control can be programmed to drag or click

windows and icons or perform the same functions as keys on your keyboard.

For information on using ELP Link, see Chapters 2 and 3. For information on the

ELP Remote Programmer, see Chapter 4.

Standby mode

Standby mode conserves electricity by automatically turning off the lamp if the

projector has not been used for a specified period of time (the default is

minutes). In standby mode, the projector remains on but the lamp is turned

off. This conserves electricity, cools the projector, and extends the life of the lamp.

Use the Standby button on the remote control to turn standby mode on or off.

Getting the Most Out of Your Projector
