3.1 ERİS-GC.2 xxx Intended use
ERİS - GC.2 xxx controllers are designed for flame control on mid-scale atmospheric or blast-sweeping
gas burners with 1 or 2 stages. It is suitable for use with gas burners which are manually stopped or
have automated thermostat which stops, at least once in every 24 hours.
Product Introduction:
Manufacturer Co. :ERA END.Röle İML.SAN.ve TİC.LTD.ŞTİ.
Brand :ERA-ERİS
Model : GC.2 xxx (micro-processor controlled)
Intended use : Gas burner flame controller
Control system : 2 staged structure
PCB Structure : UL 94 – V0 + Protective Coating
Operating voltage : 230 VAC. 50/60 Hz.
Operation principle : Electronic controller which utilizes ionization electrode or
UV photo-detector for 1 or 2 stage burners
Outer casing : PC+ABS
Connection socket : PC+ABS
3.3 Specifications
Front panel displays failure codes “in letters and numbers”,
In case of a flame failure prior to program, initiates lock phase and gives a failure notice,
Remote reset is available
2 outputs for solenoid valves
1 output for ignition transformer,
1 output for ignition transformer,
A two color status lamp on controller unit, (Red – Green)
Can work with ionization electrode or ERİS-3 UV photocell with rectification output
Detection and ignition via single electrode (with TAR-10 transformer, see Picture 7)
Low voltage detection,
Microprocessor controlled
During the production, product can be custom-programmed as per customer requirements upon
request (See program examples, Figure 3 and Figure 4)
3.2 Structure of Controllers
3. INTRODUCTORY BASIC INFORMATION
