240W PALM SANDER
ERB106SDR
WARRANTY
YEARS
240W PALM SANDER
GUARANTEE
This product carries a guarantee of 24 months. If your product develops a
fault within this period, you should in the first instance contact the retailer where the
item was purchased.
This guarantee specifically excludes losses caused due to:
- Fair wear and tear
- Misuse or abuse
- Lack of routine maintenance
- Failure of consumable items (such as batteries)
- Accidental damage
- Cosmetic damage
- Failure to follow manufacturer’s guidelines
- Loss of use of the goods
This guarantee does not affect your statutory rights. This guarantee is only valid in the UK.
For further technical advice, spare parts or repair service (outside of guarantee) please
contact the customer helpline number on 0845 607 6380.
Congratulations on your purchase of a quality power tool from Erbauer (UK)
Ltd. This product should give you reliable service but for your peace of mind
this power tool does carries a 24-month guarantee, the terms of
which are detailed below.
If this product develops a fault within the guarantee period contact your
retailer.
Please retain this handbook in case you need to refer to safety, care or guarantee
information in the future.
SAFETY INSTRUCTIONS
WARNING! Read all instructions. Failure to follow all instructions listed below
may result in electric shock, fire and/or serious injury.
SAVE THESE INSTRUCTIONS
1. Work area
a. Keep work area clean and well lit.Cluttered and dark areas invite
accidents.
b. Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in
any way. Do not use any adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions.Water entering a
power tool will increase the risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords increase the risk of electric
shock.
e. When operating a power tool outdoors, use an extension cord suitable
for outdoor use. Use of a cord suitable for outdoor use reduces the risk of
electric shock.
f. Use a Residual Circuit Breaker on all 230V Power tools. This can help
minimise the risk of an electrical shock if an earth fault or short circuits occurs.
g. If using a power cable extension ensure that the cable is fully unwound
and that its length is less than 30m. Lengths over 30 m will effect the tools
performance as a result of voltage drop.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired
or under the influence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in serious personal injury.
b. Use safety equipment. Always wear eye protection. Safety equipment
such as dust mask, non-skid safety shoes, hard hat, or hearing protection used
for appropriate conditions will reduce personal injuries.
c. Avoid accidental starting. Ensure the switch is in the off-position
240W PALM SANDER
before plugging in. Carrying power tools with your finger on the switch or
plugging in power tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool
on. A wrench or a key left attached to a rotating part of the power tool may result
in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your
hair, clothing and gloves away from moving parts. Loose clothes, jewellery
or long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used. Use
of these devices can reduce dust related hazards.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the rate
for which it was designed.
b. Do not use the power tool if the switch does not turn it on and off.
Any power tool that cannot be controlled with the switch is dangerous and must
be repaired.
c. Disconnect the plug from the power source before making any
adjustments, changing accessories, or storing power tools. Such preventive
safety measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to operate
the power tool.Power tools are dangerous in the hands of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may affect the
power tools operation. If damaged, have the power tool repaired before
use. Many accidents are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools
with sharp cutting edges are less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc., in accordance with
these instructions and in the manner intended for the particular type of
power tool, taking into account the working conditions and the work
to be performed.Use of the power tool for operations different from intended
could result in a hazardous situation.
5. Service
a. Have your power tool serviced by a qualified repair person using only
Safety Instructions identical replacement parts.This will ensure that the
safety of the power tool is maintained.
ADDITIONAL SAFETY RULES - FOR PALM SANDERS
1. Never use this sander for wet sanding or liquid polishing. Failure to follow this rule
may result in risk of electrical shock.
2. Always wear eye protectors when using this sander.
3. Always wear a dust mask when using this sander.
4. Always inspect and remove all nails and screws etc from timber before sanding.
5. Always check walls and ceiling to avoid hidden power cables and pipes. A metal
detector can be obtained from any good DIY store for this purpose.
6. If possible, ensure the workpiece is firmly clamped to prevent movement.
7. Your sander is a hand held tool, do not clamp into a fixed position.
8. Never stop the sander by applying a force to the base plate.
9. Only use sanding paper in good condition. Do not use torn or worn sanding
paper.
10. Do not sand magnesium material due to the risk of fire.
11. Do not sand material including asbestos due to a health rise.
12. Do not sand lead based paint due to the rise of lead poisoning, test any paint work
with a lead paint test kit to confirm if lead paint is present.
13. Do not eat or drink in the working area of the sander.
14. Do not allow people to enter the working area without wearing a dust mask.
15. Where possible, seal off the working area to contain the dust for later removal.
WARNING! Some dust created by using power tools contains chemicals known
to cause cancer and birth defects or other reproductive harm. Some examples
of these chemicals are:
1) Lead from lead-based paint
2) Crystalline silica from bricks and cement and other masonry products
3) Arsenic and chromium from chemically-treated lumber
Your risk to these exposures varies, depending on how often you do this type of work.
To reduce your exposure to these chemicals:
1) Work in a well ventilated area
2) Work with approved safety equipment, such as those dust masks that are specifi-
cally designed to filter out microscopic particles.
HEALTH ADVICE
WARNING! When drilling, sanding, sawing or grinding, dust particles will be
produced. In some instances, depending on the materials you are working with,
this dust can be particularly harmful to you (e.g. lead from old gloss paint).
You are advised to consider the risks associated with the materials you are working
with and to reduce the risk of exposure. You should:
- Work in a well-ventilated area.
- Work with approved safety equipment, such as those dust masks that are specially
designed to filter microscopic particles.
240W PALM SANDER
VIBRATION
The European Physical Agents (Vibration) Directive has been brought in to help re-
duce hand arm vibration syndrome injuries to power tool users. The directive requires
power tool manufacturers and suppliers to provide indicative vibration test results to
enable users to make informed decisions as to the period of time a power tool can be
used safely on a daily basis and the choice of tool.
Further Advice can be found at www.hse.gov.uk
Vibration total values (triax vector sum) determined according to EN 60745:
Work mode description 1 Vibration emission value ah =4.86 m/s²
Uncertainty K = 1.5 m/s²
The declared vibration emission value should be used as a minimum level should be
used with the current guidance on vibration.
Calculating the actual period of the actual period off use can be difficult and the HSE
website has further information.
The declared vibration emission been measured in accordance with a standardised
test stated above and may be used to compare one tool with another
The declared vibration emission value may also be used in a preliminary assessment
of exposure.
Warning: The vibration emission value during actual use of the power tool can
differ from the declared value depending on the ways in which the tool is used
dependant on the following examples and other variations on how the tool is used:-
How the tool is used and the materials being cut or drilled.
The tool being in good condition and well maintained
The use the correct accessory for the tool and ensuring it is sharp and in good condi-
tion.
And the tool is being used as intended by its design and these instructions.
This tool may cause hand-arm vibration syndrome if its use is not adequately
managed
Warning: identify safety measures to protect the operator that are based on
an estimation of exposure in the actual conditions of use (taking account of all
parts of the operating cycle such as the times when the tool is switched off and when
it is running idle in addition to the trigger time).Note The use of other tools will reduce
the users’ total working period on this tool.
Helping to minimise your vibration exposure risk.
ALWAYS use sharp chisels, drills and blades
Maintain this tool in accordance with these instructions and keep well lubricated
(where appropriate)
Avoid using tools in temperatures of 10C or less
Plan your work schedule to spread any high vibration tool use across a number of
days.
Health Surveillance
All employees should be part of an employer’s health surveillance scheme to help
identity any vibration related diseases at an early stage, prevent disease progression
and help employees stay in work.
SYMBOLS
Read the manual Warning WEEE marking
Wear dust mask,eye & ear protection Double insulation
240W PALM SANDER
1. ON-OFF SWITCH
2. PALM GRIP HANDLE
3. MOTOR HOUSING
4. DUST COLLECTION OUTLET
5. BASE PLATE
6. CLAMP LEVER LOCK
7. SAND PAPER CLAMP
8. CLAMP LEVER
9. PAPER PUNCH
10. SANDING PAPER (See fig.A)
11. DUST BAG (See fig.B)
TECHNICAL DATA
Rated voltage: 230-240 V~50Hz
Rated power: 240W
Rated no load speed: 14000min-1
Dimension of base: 100 x 110 mm
Protection class: //II
Weight: 1.3 kg
Orbital dia: 1.6 mm
ACCESSORIES
Dust bag 1pc
Dust extraction adaptor 1pc
Sanding paper 2pcs
Paper punch 1pc
Indice
Altri manuali Erbauer Levigatrice
Erbauer
Erbauer ETSS260 Manuale utente
Erbauer
Erbauer ERB617SDR Manuale utente
Erbauer
Erbauer ERB107SDR Manuale utente
Erbauer
Erbauer ERB401SDR Manuale utente
Erbauer
Erbauer ERB406 Manuale utente
Erbauer
Erbauer ERB415SDR Manuale utente
Erbauer
Erbauer ERB105K Manuale utente
Erbauer
Erbauer EHSS350 Manuale utente
Erbauer
Erbauer ERB109SDR Manuale utente
Erbauer
Erbauer ERO18-Li Manuale utente
