Ergotron 45-214-026 Dimensioni

Ergotron®

870-05-084-EA

www.ergotron.com

Highlights

• Accommodatesmid-sizeddisplaysand

all-in-onecomputersweighingupto

30lbs(13.6kg)

• Positionyourdisplayformaximum

ergonomiccomforttorelieveeye,neck

andbackstrain

• Cablemanagementfeatureconceals

androutescablesunderthearm,out

oftheway

• Freeupyourtableordesktoptoincrease

yourworkspace

• UpgradeLCDmonitorsandTVswith

improvedergonomicadjustment

• Pre-assembledarmoffersmonitor/TV

theftdeterrence

• ExtendsLCDupto16.7(42cm);

pushyourdisplayoutofthewaywhen

notinuse

• PatentedCFmotion

technologyprovides

premiumease-of-use

displayadjustment.

• Easy-to-use,simpleinstallationand

effortlessoperation

Affordable elegance and adjustability for mid-sized displays

Exceptional engineering and design makes the new Ergotron MX LCD Arm the

right solution for today’s mid-sized desktop displays and all-in-one computers

weighing up to 30 lbs (13.2 kg). Combining premium features with an attractive,

polished aluminum finish, the MX Arm offers a slim profile, five inches (13 cm)

of height adjustment, integrated tilt, portrait-to-landscape capability and 360º

rotation—all on a convenient swivel base. Gain comfort and productivity with this

stylish and affordable desk mount display.

MX LCD Arms

Product Sheet

Americas Sales and

Corporate HeadquartersEMEA Sales APAC Sales Worldwide OEM Sales

St. Paul, MN USA

(800) 888-8458

+1-651-681-7600

www.ergotron.com

[email protected]

Amersfoort, The Netherlands

+31 33 45 45 600

www.ergotron.com

[email protected]

Tokyo, Japan

www.ergotron.com

[email protected]

www.ergotron.com

[email protected]

©2009Ergotron,Inc.rev.10/05/2009e-05-084-EAContent is subject to change without notification

• PatentedConstantForce(CF)lift-and-pivotmotiontechnology

• Portrait/landscaperotationincludespositionlock

• Deskmountingoptions:deskclampattachestosurfaceedge0–2.6

(0–66mm)thick;grommetmountattachesthroughsurfaceholes

.31–2(8–51mm)wideandupto3(80mm)thick

• Mountingstandards:VESAFDMI,MIS-D,75/100,C(holepatterns=

100x100mmand75x75mm).OptionalVESABracketAdaptorKit

(97-474)canbeorderedseparatelyforMIS-EandMIS-Finterfaces

(holepatterns=200x100mm,200x200mmand400x200mm)

• Weightcapacity:14–30lbs(6.3–13.6kg)

•16.7(42cm)extension

• Cablemanagementfeatureconcealsandroutescablesunderthe

arm,outoftheway

• Pansatbase180°;rotatesatextension360°;pansatmonitor180°

• Rotatescreenforportraitviewingofphotosandpages—eliminate

scrolling

• Warranty:five(5)years

ProductName MX Desk Mount LCD Arm MX Wall Mount LCD Arm

PartNumber 45-214-026 (polished aluminum) 45-228-026 (polished aluminum)

ProductIncludes MX Desk Mount Arm, desk clamp

and grommet mount

MX Wall Mount Arm

ShippingDimensions 25.6x 7.3x 6.3

(650 x 185 x 160 mm) LWH

29.25x 10.5x 6.5

(745 x 265 x 160 mm) LWH

ShippingWeight 9 lbs (4.2 kg) 10.25 lbs (4.65 kg)

Warranty 5 years

WeightCapacity 14–30 lbs (6.3–13.6 kg)

CompatibleDisplay(s) Most VESA-compliant monitors/HDTV displays up to 30diagonal in size

LCD Size LCD Weight* Lift Tilt Pan Rotation** VESA

3014–30 lbs

6,3–13,6 kg

5

13 cm 80° 360° 90° w/lock MIS-D

* Monitor depth greater than 4(102 mm) may diminish capacity. Contact Ergotron for more information

** Portrait mode is incompatible with 30displays on Desk Mount Arm

Motion range may be limited when using larger displays and/or by the position of the VESA hole pattern on the back of the display
