Ericsson R250s Pro Manuale utente

Visit us on our website

http://mobile.ericsson.com

Ericsson Mobile Communications AB, SE-221 83 Lund, Sweden

EN/SVV 000 000 R1A

Mobile Phone

R250s PRO

User’s Guide

NotforCommercialUse

EricssonMobileCommunicationsAB

This page helps you to get the phone up and running quickly. If you have not

used a mobile phone before, we recommend that you read the chapter

“Preparing Your Phone for Use” on page 4, for a more detailed installation

procedure.

• Wash the phone gently in cold water under a water tap.

• Do not immerse the phone in water!

QUICK START

NotforCommercialUse

EricssonMobileCommunicationsAB

•The R250s PRO is a mobile phone, specially designed to be used when

working outdoors. Thanks to its rugged design the R250s PRO is very

resistant to external influences such as dust, rain and shock.

•The R250s PRO is the first mobile phone which supports GSM Pro. GSM

Pro is an extended feature of the GSM network, which supports group

calls and call monitoring. (GSM Pro requires a GSM Pro subscription.)

•The R250s PRO has an vibrating call alert, which means that the phone

vibrates when you receive an incoming call or message. This is a useful

function when you are working in a noisy environment, where you

cannot hear the phone signal.

•When you work in a noisy environment, you can use Ericsson handsfree

equipment in combination with ear protection equipment. At an incoming

group call, the call is answered automatically and you will hear the conver-

sation in the earpiece.

•Key pad lock. The key pad lock prevents accidental dialling, which could

happen if you keep your phone attached to your belt. The key pad remains

locked until you receive an incoming call. While the key pad is locked,

you can still use the Push-To-Talk button on the left side of the phone for

entering the phone book.

•Alert button. The R250s PRO is equipped with an alert button on the top

of the phone, which makes it easy to call a pre-set alert number.

Note! Please read the chapter “Guidelines for Safe and Efficient Use”on

page 112, before using your mobile phone.

R250S PRO FEATURES

NotforCommercialUse
EricssonMobileCommunicationsAB
Getting Started 3
Preparing Your Phone for Use 4
Turning Your Phone
On and Off 14
Display Information and Key Functions 17
Making and Receiving Calls 19
During a Call 24
Speakerphone 26
Functions and Settings 29
Using the Menu System 30
Your Personal Phone Book 33
Keeping Track of Your Phone Calls 42
Your Voice Mail Service 44
Personalizing Your Phone 46
Sending and Receiving Text Messages (SMS) 53
Diverting Incoming Calls 62
Security for Your Phone and Subscription 64
Setting Network Preferences 70
Handling More than One Call Simultaneously 74
Knowing the Call Time/Call Cost 78
Using Two Phone Lines 81
Calling Card or Credit Card Calls 83
Sending and Receiving Fax and Data calls 85
Some Useful Tools 86
GSM Pro 89
GSM Pro 90
Additional Information 97
Accessories 98
Troubleshooting 102
Ericsson Mobile Internet 104
Quick Keys 105
Technical Data 106
Glossary 107
Guidelines for Safe and Efficient Use 112
Warranty 116
Declaration of Conformity 118
Index 119
Ericsson R250s PRO
Third edition (June 2000)
This manual is published by Ericsson
Mobile Communications AB, without any
warranty. Improvements and changes to
this manual necessitated by typographical
errors, inaccuracies of current information,
or improvements to programs and/or equip-
ment, may be made by Ericsson Mobile
Communications AB at any time and with-
out notice. Such changes will, however, be
incorporated into new editions of this
manual.
All rights reserved.
©Ericsson Mobile Communications AB,
1999
Publication number: EN/LZT 108 2554 R1C
Printed in Sweden
INNOVATRON PATENTS
Contents
at a Glance

NotforCommercialUse

EricssonMobileCommunicationsAB

Please note!

Some of the services in this manual are not supported by all net-

works. This also applies to the GSM International Emergency

Number 112.

Please contact your network operator or service provider if you are

in doubt whether you can use a particular service or not.

The symbol on our products signifies that they have been certi-

fied according to the EMC directive 89/336/EEC, the Telecommu-

nications directive 91/263/EEC, and the Low Voltage directive 73/

23/EEC when applicable. The products fulfil the requirements

according to the following standards:

Cellular Phones and Accessories in Combination:

ETS 300 342-1 EMC for European digital cellular telecommunica-

tions.

Accessories Without Direct Connection to a Cellular Phone:

EN 50081 Electromagnetic compatibility, Generic Emission Stan-

dard, and EN 50082 Electromagnetic compatibility, Generic

Immunity Standard.

NotforCommercialUse

EricssonMobileCommunicationsAB

Preparing Your Phone for Use 4

Turning Your Phone On and Off 14

Display Information and Key Functions 17

Making and Receiving Calls 19

During a Call 24

Speakerphone 26

GETTING STARTED

NotforCommercialUse

EricssonMobileCommunicationsAB

4 Preparing Your Phone for Use

Preparing Your Phone

for Use

Note! Please read the chapter “Guidelines for Safe and Efficient Use”on

page 112, before using your mobile phone.

Front

* If you are not using a SIM Pro card (see “GSM Pro”on page 90), i.e. if

you are using a regular SIM card, pressing the Push-to-talk button mutes

the microphone, if pressed during a conversation.

OVERVIEW

Indicator light

Mode switch

Earpiece/loud-

speaker

Display

On/off key

Keypad

Antenna

Alert button

Volume keys

Push-to-talk

button*

Microphone

NotforCommercialUse

EricssonMobileCommunicationsAB

Preparing Your Phone for Use 5

Top

Back

To use your phone you must:

•insert the SIM card

•attach the battery to the phone

•charge the battery

Please see the following pages.

ASSEMBLY

Indicator Light

Earpiece/Loud-

speaker

Alert Button

Connector for

external antenna

Hole for belt clip

Headset

connector

Battery release

catch

Battery

Charging

connector

NotforCommercialUse

EricssonMobileCommunicationsAB

6 Preparing Your Phone for Use

When you register as a subscriber with a network operator, you get a SIM

(Subscriber Identity Module) card. The SIM card contains a computer chip

that keeps track of your phone number, the services included in your subscrip-

tion, and your Phone Book information, among other things.

SIM cards come in two sizes. One is the size of a credit card, and the other is

smaller. Your phone uses the smaller card. Many credit card-sized SIM cards

have a perforated smaller card that you can take out easily. Before you can use

your phone, you must insert the SIM card as shown below.

Inserting the SIM Card

To insert the SIM card, remove the battery (if attached) and follow these steps:

THE SIM CARD

3. Open the holder.

1. Open the lid that covers the SIM

card holder.

2. Release the SIM card holder by

sliding it in the direction of the

arrow.

5. Lock the holder by pressing it

down and sliding it in the direc-

tion of the arrow in the picture.

6. Finally, close the lid.

4. Slide the SIM card into the

holder. Make certain that the cut

corner is in the top right-hand

corner.

NotforCommercialUse

EricssonMobileCommunicationsAB

Preparing Your Phone for Use 7

The PIN

Most SIM cards are supplied with a security code or PIN (Personal Identity

Number), which you need to access the network. Every time you turn on your

phone, it prompts you to enter your PIN. You will find your PIN in the infor-

mation from your operator.

You may need your PIN when you want to change the settings in your phone.

Furthermore, some operators may have services that require a second PIN,

your PIN2.

You should be careful with your PIN, since it is your protection against

unauthorized use of your subscription.

If your PIN is entered incorrectly three times in a row, the SIM card is

blocked. If this happens, you can unlock it by using your PUK (Personal

Unblocking Key code), which you also get from your operator.

The R250s PRO comes with a nickel metal hydride (NiMH) battery. The

battery is not charged when you buy your phone, but there may be enough

power to turn the phone on. We recommend that you charge the battery before

you use the phone for the first time.

The battery is specially designed for the R250s PRO. The battery has a special

locking mechanism that prevents it from falling off if you should drop the

phone on the ground.

The battery is equipped with a special rubber sealing to prevent leakage into

the phone. With the battery and antenna properly attached, the phone is dust-

and water-resistant. The phone can be used outdoors, even if it is raining and

the phone will not be damaged if you use it in a dusty environment.

Use only Ericsson original batteries. By using other batteries you risk damag-

ing the phone and will void the warranty.

THE BATTERY
