HDVIPCPTZC Keyboard controller

USER INSTRUCTION

USE/INSTALLATION

Rev. F21

- 0 1 -

1.Product Description

1.1 Descrip�on

The network IP keyboard adopts the new design of PC + ABS outer case. It is light and

easy to operate. The bottom is designed with a non-slip silicone pad that can be operated

with one hand. The IP keyboard uses an industrial-grade 5-inch LCD screen.

With Solution 1920 * 1080P H.264/265 stream, super wide viewing angle IP opera�on

keyboard. Using import 4D joys�ck, stepless knob buttons, and silicone buttons with

great opera�ng feel. The buttons are fully func�onal, which effec�vely solves the

inconvenience of the current web-page operation of the PTZ. The appearance is simple

and beau�ful; the display effect is excellent, and the image characters are delicate and

clear. IP keyboard supports ONVIF protocol, compatible with 99% PTZ cameras on the

market. Easy operation, only a few steps to achieve perfect control of PTZ Cameras.

1.2 Product Features

(1) Support ONVIF protocol, with independent IP address in IP mode.

(2) Equipped with stepless knob keys to adjust the control speed and zoom speed.

- 0 2 -

1.3 Product Appearance

Power switch

Power interface

IP Interface

RS232

RS422

No. Name Function

Power switch

Power interface

IP Interface

RS232

RS422

Standard5.5/2.1powerinterface;DC12V2A±10%

Connecting to the Internet

No function Currently

1.4 Interface Description

(3) With Import variable-speed 4D joystick

Twist the joystick to control the PTZ camera directly.

(4) Support standard POE power supply.

(5) The bottom is designed with non-slip silicone pad.

- 0 3 -

Product Connection Diagram with onvif protocol

Camera and keyboard need to be connected to the same LAN.

Cable

1.5 System Topology diagram

Cable

2. Keyboard function

2.1 Button Description

(1) SET PRESET: Example: Set Preset 1

[SET PRESET ] > [1] > operate the camera> [ENTER]

video

conference

camera

Dome

camera

PTZ

Camera

- 0 4 -

A. Press [SET PRESET] button, and the text “Set preset ” appears in the lower right

corner of the screen.

B. Press the number [1], the number 1 appears on the screen in the back of the

"Set preset "

C. Operate the joys�ck to move the camera to the posi�on you want to set the preset.

Press [ENTER] to conﬁrm.

(Note: set up to 99 preset Max)

CALL PRESET: Example: Call preset 1

[CALL PRESET] > [1] > [ENTER]

A. Press the [CALL PRESET] button, and the text “call preset” appears in the lower

right corner of the screen.

B. Press the number [1] button, the number 1 appears on the screen in the back

“call preset ”

C. Press [ENTER] button, the camera will move to preset 1 posi�on.

- 0 5 -

SEARCH: Example: adding the IP address of a camera

A. Press [SEARCH] key to enter, move the joys�ck to the right, select search, and

press [ENGER] or the middle button of the joys�ck to conﬁrm the search.

B. Use the joys�ck to select the IP, press the middle button of the joys�ck to select,

joys�ck move right to select the new one, and press the middle button of the

joys�ck to add.

C. Fill in the correct user name and password, and press the number keys

con�nuously to switch between uppercase and lowercase letters.

D. Select Save and press the middle button of the joys�ck to conﬁrm and save.

LIST: View the list of added devices, you can edit or delete.

Device List

Search Device

Manually Add

System Set

Network Set

Exit

Device

select Number address port protocol

Onvif

8000

8999

Select All Cancel Delete Edit

192.168.0.181

192.168.1.101

192.168.1.108

192.168.1.168

1~9: Single point is a number key function / continuously press to switch letters

CAM: For quick camera switching

Example: Press[CAM] +Serial numberincameradevicelist+[ENTER]

PREVIOUS: Quickly switchtothecamerawithaserialnumberonthe list ofadded devices

NEXT: Quickly switch to the camera with the next serial number in the list of

dded devices

CLEAR: Delete one ENTER: confirm ZOOM+

ZOOM- FOCUS+ FOCUS-

IRIS+ IRIS- AUTO FOCUS

AUTO IRIS F1: No function, it is for expanding function

F2: No function, , it is for expanding function

2.2 Knob Description

Operating Output

Control Operating Output

Control

Downward

Upward Left

- 0 6 -

2 . 3 K n o b D e s c r ip tio n

(1) P/T SPEED: PTZ control speed Turn the knob to the right + Turn to the left-

(2) ZOOM SPEED

3. PTZ and Keyboard connection

3.1 Make sure the camera has open ONVIF protocol

(Example)

(1) Input the IP address of the camera, enter the WEB interface.

(2) Conﬁgura�on---Network----Advanced Conﬁgura�on----Integra�on Protocol

(3) Tick and enable ONVIF protocol

(4) Add an administrator account (the same as the account you use to ac�vate

the camera)

(5) Save

Press the middle joystick button to confirm in menu mode

Operating Output

Control Operating Output

Control

Right Zoom + Zoom

- 0 7 -

(1) Press <SEARCH> to the search device, move the red cursor to the right to jump into

the search, press the middle button of the joys�ck to conﬁrm the search for the

device, select the device to be added, press OK, and then move the red cursor to New.

Enter the camera user name and password to save (the camera and keyboard must be

on the same network segment)

3.2 ONVIF connection

Device List

Search Device

Manually Add

System Set

Network Set

Exit

Search>Results

select Number address port protocol

IPD-D53M02

IPC

8999

Select All Cancel Delete Edit

192.168.0.23

192.168.0.149

192.168.0.108

192.168.0.214

580192.168.0.215

68999192.168.0.238

IPC

Device List

Search Device

Manually Add

System Set

Network Set

Exit

Search>Results

select Number address port protocol

IPD-D53M02

IPC

8999

Select All Cancel Delete Edit

192.168.0.23

192.168.0.149

192.168.0.108

192.168.0.214

580192.168.0.215

68999192.168.0.238

IPC

- 0 8 -

(2) Press the MENU button to enter the menu and select to manually add the

camera IP, port, user name, password, and select the Onvif protocol point to

save (the camera and keyboard must be on the same network segment)

Device List

Search Device

Manually Add

System Set

Network Set

Exit

Search>Adduser

Save Cancel

Username

Password

admin

Device List

Search Device

Manually Add

System Set

Network Set

Exit

Search>Adduser

Save Cancel

Username

Password

192.168.0.181

admin

Password onvif

ip address

port

- 0 9 -
