www.espuk.com

IP Camera Quick Start Guide

The latest product manual and software is available online:

https://www.espuk.com/technical_support/

22

Connection

Typically the IP Camera (IPC) will either be connected to an NVR or connected directly to a

network via a router.

If the IPC is connected to an NVR, in most cases the NVR will auto connect. In this case no

set-up will be required and the quick start guide can be retained for future use.

If the IPC is connected directly to a network there is a setup process required for access.

The quick start guide will assist, and the full manual will provide more support if required.

Example Connections

3

Network Connection

After applying power and connecting the IPC to the network;

Load the ‘Device Config Tool’ software onto a PC/ Laptop on the network.

Launch the Device Search software, and select ‘Search’, if the network’s existing details match

the IPC’s default details the device will be recognised.

The default IP address of the IPC is : 192.168.1.168

The default Subnet Mask of the IPC is : 255.255.255.0

Click on the IP address in the search bar to access the IPC.

If the Device Search software cannot find the IPC, then a temporary connection between

PC/Laptop is required, this is achieved by matching the default network details of the IPC to

the PC/Laptop.

Connect the IPC (with Power) to the LAN port to a laptop. Open ‘Network Connections’,

Select ‘Local Area Connection’, then ‘Properties’ to access the following menus;

3

1. Double Click

2. Enter the following details

3. Click

4. Add the

additional

TCP/IP address

5. Click OK to

complete setup

4

After the details have been applied and saved, launch the Device Search software and ‘Search’.

If the the Device Search is unsuccessful, review the full installation manual for the product or

contact the IT administrator for further support.

Tip; Other network connections on the PC/Laptop may need to be temporarily disabled to

complete IPC setup.

Modify IPC Network Details

If required, the the IPC’s network information can be modified via the Device Search to match

the intended network segment details.

5

Internet Explorer Browser Access

Once the Device Search finds the IPC, the IP address link will open Internet Explorer.

Run and Allow the latest plugin;

In the browser add the IPC’s IP address in the Compatibility View menu:

The default user name is admin, the default password is admin;

6

Mobile : APP Connectivity

1. Search ESP IP View from Google Play Store for android devices or App Store or iOS devices

and install.

2. Run the app to display the live view

3. Touch the icon to open the menu.

4. Select ‘Device List’

5. Select ‘ADD’ and scan the QR code

located on the IPC.

QR Code

6. Enter the IPC’s password and

select ‘Save’

After all settings are completed the

APP will turn to Live view display

with camera images.

7

PC: Software Connectivity

The system can be accessed remotely via PC software.

To remotely access the NVR with the supplied software, please review the full product manual

to insure PC settings and requirements are met.

Disclaimer

(i) As with all software and hardware dependent devices, ESP are unable to guarantee that

every device will be compatible with the supplied product and software.

Specific models of phone, tablet or other devices, the hardware it contains, the service

provider, the types of data services offered and variations in version numbers can affect

the performance.

(ii) IP enabled devices should always be installed by competent /experienced persons.

www.espuk.com

Elite Security Products

Unit 7, Target Park,

Shawbank Road, Lakeside,

Redditch B98 8YN

Telephone: 01527 51 51 50

Fax: 01527 51 51 43

Email: [email protected]

www.espuk.com

E&OE - Errors and omissions excepted.I19
