Page 8
FG500V-FG525-REM-I07-010317
Clearances to Non-Combustibles
Non-combustible surfaces are defined as brick, metal, marble, concrete etc., and also a
number of manmade materials impervious to flame. If in doubt, refer to the material
manufacturer for further information before proceeding with installation.
Clearances to the sides of the stove is 50mm, however clear and easy access to the
controls located on the lower right hand side of the stove must be allowed for, and we
would therefore recommend that at least 100mm be allowed. Clearance to the front of
the stove is 500mm. Care must be taken that no brickwork or other incombustible
material protrudes into the area immediately around the base of the stove or area
underneath the stove in a way that is likely to affect natural air flow into or around the
appliance.
For the 500 series the back of the stove may be installed directly against a non-
combustible wall. For the 525 stove it is recommended there should be a minimum
clearance of 25mm between the top plate and non-combustible wall.
Installation into ‘inglenook’ type fireplaces is acceptable. However it is recommended
that there is at least 460mm clearance above the outlet grille.
Clearances to Combustible materials
Combustible materials are defined as wood, fabrics, or other materials likely to combust
if exposed to flame. Generally, any material, which is likely to discolour, melt or
misshape when exposed to moderate heat, should be considered as a combustible
material of surface. Any fire surround to be used in conjunction with this stove should
be rated at a minimum of 100°C.
Clearances to the sides of the stove are 100mm but curtains, drapes and other fabrics
are not permitted within a distance of 500mm of the stove sides and back. No such
materials are permitted directly above the stove regardless of distance. Clearance to the
front of the stove is 1000mm. Clearance to the rear of the stove is 50mm from the back
of the top casting.
It is not permitted to install the stove onto carpet, rugs or fabric materials of any kind.
Installations into ‘inglenook’ type fireplaces are acceptable, providing adequate
consideration is given to any wooden cross-members and such like.
A combustible shelf may be fixed to the wall above the stove, providing that it complies
with the dimensions given below. The shelf depth is measured from the wall BEHIND the
stove.
