User Manual
Rev 1.0 May 2021
Current Conductor
S / L / HC / 8
essentia
audiotoo
s
essentia
audiotoo s
Essential Audio Tools power cords are built with two layers of screening; a 100% closed
aluminium foil and a tinned braided copper screen. This double shielding protects the
nearby signal cables from the fields generated by the current flowing through the
conductors. It also works the other way around: preventing the conductors picking-up
airborne disturbances from the environment. The twisted Oxygen Free Copper (OFC)
conductors are fully capable of transporting the current your equipment needs without
ohmic losses.
What to expect?
The result of experimenting with our power cords can vary from small changes to big
surprises. The most heard improvements are quietness in silent parts of the music as well as
more noticeable details and more holographic soundstage. A high quality recording with
on average low volume and high dynamics will benefit most from the lowered
background noise.
Description
Avoid water and other liquids
To avoid risk of fire and electrical shock: do not expose the cable to moisture. Use indoors
and in dry locations only. Do not expose to dripping and/or splashing. Do not place objects
filled with liquids -such as vases- on or near the cable. Do not use the cable if any liquid is
spilled on the cable or into the connectors; return it to your dealer for servicing.
Unplug before cleaning
Always unplug the cable before cleaning. Only clean the cable with a dry cloth or duster.
Do not use any cleaning solutions, sprays, or water.
Do not exceed maximum total load
The total current may not exceed the specified Amps.
Check your supply voltage
This cable is designed for a maximum of 250V~ @ 50/60Hz mains supply. Connecting to a
higher voltage may damage the cable and warranty will be void.
Connect power cords safely
Power cords should be routed in such a way that they are not likely to be walked on or
pinched by items. Do not route power cords near heat sources. To disconnect the power
cord, pull it out by the plug (wall outlet side first). Do not pull the cable itself, doing so may
result in damage which can lead to fire or electric shock.
Safety precautions
2.
essentia
audiotoo s
More information about our products:
Specifications
Mains Connector Schuko
Conductor type OFC, stranded
Screening Braided tinned copper + aluminium foil
Rated voltage 220-250V~ @ 50/60 Hz
Type S L HC 8
Output connector C13 C13 C19 C7
Outer Diameter 8mm 10,4mm 10,4mm 8mm
Conductors [mm2] 3x 0,75 3x 2,5 3x 2,5 2x 1,0
Maximum current 6A 10A 16A 2,5A
Warranty
Essential Audio Tools products have a warranty period of two years from date of purchase.
This warranty covers manufacturing defects and failures within products specifications.
When warranty is claimed the original bill with the buyer’s name and date of purchase
should be presented.
Warranty will void if:
• The device has not been used in conformance with the user manual.
• The device has been used in an industrial environment.
• The bill has been altered or made illegible.
• Modifications or repairs have been performed by non-authorized persons.
• Malfunction is caused by device-external conditions, such as:
overloading, atmospheric discharges and fire or water damages etc.
Warranty is limited to damages regarding the cable itself:
all eventual consequential damages are not covered by warranty.
3.
Phase indicator figure 8Phase indicator CCS / CCL / CCHC
