ESX VISION ANDROID Series Manuale utente
1
V1.0
INSTALLATION
GUIDE
VISION ANDROID™ SERIES
SMART NAVICEIVER
MOBILE INTERNET READY
INCL. START-UP INSTRUCTIONS,
CAMERA SETTINGS,
GPS RECEPTION, 4G/LTE
and much more.
VN940-TRC-4G
2
SCOPE OF DELIVERY
ITEM FIGURE QUANTITY
Main device
Art. No. VN940-TRC-4G 1
System cable set
with CAN bus module
for Ford vehicles
Art. No. ZEOS-FOCUS19-020
1
CAN bus module for
Ford Transit for plugging into
the system cable set
Art. No. VNA-CAN-TRC-i40
1
AV cable set 1
with audio and video
connections
incl. rear view camera
(14-pin plug)
Art. No. ZERW-120014-207
1
Installation-friendly AV
cable set 1 - only with the connec-
tion for the rear view camera
(14-pin plug)
Art. No. ZERW-111008-201
1
USB port 1
(4-pin plug)
Art. No. ZECL-290004-217
1
4G/LTE dongle
(6-pin plug)
Art. No. ZESW-012900-004
1
Adapter cable for
factory USB port 2
(8-pin plug)
Art. No. ZECL-29008-213
1
S
A
A
B
C
D
3
SCOPE OF DELIVERY
ITEM FIGURE QUANTITY
AV cable set 2
with power, audio and video
connections, additional
camera input
(8-pin plug)
Art. No. ZERW-120008-210
1
Y-adapter for the external
microphone and the receiver
of the separately available
remote control
(6-pin plug)
Art. No. ZERW-121506-200
1
External microphone
(Mini jack)
Art. No. ZECL-035201-330
1
GPS antenna
Art. No. ZESW-011701-007 1
DAB antenna
Art. No. VNA-ANT-DAB5 1
FAKRA Y antenna cable
Art. No. ZECW-A731016-000 1
4G/LTE antenna
Art. No. VNA-LTE 1
G
H
4
WIRING DIAGRAM
20-pin system socket
C4G/LTE dongle (6-pin plug, turquoise)
Please note the information on page 11.
BUSB port 1 (4-pin plug, purple)
Use this USB port for USB storage media. For example, the cable can be routed into the glove compart-
ment so that the USB socket is accessible there.
Radio antenna plug from vehicle (FM/AM)
4G/LTE antennaGPS antenna
WiFi antenna
Optical stereo
audio output (S/PDIF)
Fuse 10 A
DAB antenna
Inputs for
AV cable sets
S
A
E F G H
B C D
SSystem cable set (20-pin connector, black)
NOTE: If the vehicle only has one antenna connection for FM/AM and DAB, use the enclosed FAKRA Y
antenna cable (ZECW-A731016-000). Then plug the two plugs of the Y antenna cable into the connec-
tions for FM/AM and DAB on the Naviceiver.
NOTE: If an active antenna splitter is used instead of the FAKRA Y antenna cable, make sure that it is
connected to a separate power supply. With an active antenna system in the vehicle, it must also be
ensured that it is supplied with power.
Connect the included CAN bus module to the white connector (20-pin).
After plugging the 20-pin black connector into the Naviceiver, you need to connect the other end to the
vehicle‘s system connector.
Cable white (KEY1): Not in use
Cable black/white (KEY2): Not in use
Cable red (POWER 12V IN): Not in use
Cable grey (LIGHT PWM OUT): Not in use
Mini jack black (MIC): Not in use
RCA yellow (CAM OUT): Not in use
Cable blue (ANT)*: Turn-on signal for electric antenna(+12V)
Cable orange (AMP CON)**: Turn-on signal for external ampliers (+12V)
* can also be used as a +12V power supply for active antenna splitters(max. 300 mA)
** must be activated in the Naviceiver in the app “DSP” under “EXT AMP”
5
WIRING DIAGRAM
FNot in use
DAdapter cable for factory USB port 2 (8-pin plug, brown)
Connect the adapter cable to the connector of the factory USB port. Use this USB port in conjunction
with the Media Connect function to connect your Android smartphone to the Naviceiver.
HY-adapter (6-pin plug, grex)
Red jack: Connection for the IR receiver of the optionally available
remote controller VNA-REM40
Black jack: Connection for the included external microphone
GAV cable set 2 for front or additional cameras (8-pin plug, blue)
RCA red (AUX IN R): Aux audio output Rear/Right
RCA white (AUX IN L): Aux audio output Rear/Left
RCA yellow (F-CAM IN): Video input for the front or additional cameras
Cable brown BRAKE: Hand brake connection (Ground)
Cable yellow (CAM +12V): Power supply for cameras
Cable black (CAM GND): Ground connection for cameras
NOTE: Refer to page 13 for more information on camera settings.
A
A
AV cable set 1 (14-pin connector, black)
Installation-friendly AV cable set 1 (14-pin connector, black)
RCA white (FL): Audio output Front/Left
RCA red (FR): Audio output Front/Right
RCA white (RL): Audio output Rear/Left
RCA red (RR): Audio output Rear/Right
RCA green (SUB): Audio output Subwoofer
RCA yellow (VIDEO OUT 1): Video output for external monitor 1
RCA yellow (VIDEO OUT 2): Video output for external monitor 2
RCA yellow (VIDEO AUX IN): Video input for an external signal source
RCA yellow (R-CAM IN): Video input for analog rear view cam
Video input for analog HD rear view cam (AHD)*
RCA yellow (R-CAM IN): Video input for analog rear view cam
Video input for analog HD rear view cam (AHD)*
If necessary, use the CAM +12V and CAM GND connections of the enclosed connection plug G (8-pin
plug, blue) to supply power to the camera.
* Only for compatible AHD cameras such as VNA-RCAM-DBJ228HD or VNA-RCAM-CS240HD.
NOTE: Refer to page 13 for more information on camera settings.
ENot in use
6
IMPORTANT NOTES
RECOMMENDED TOOLS
Cable ties
COMPATIBILIT Y
Ford Transit 310 / 350 (Generation 7, Facelift since 2019/2020)
This device can only be installed in the following vehicles:
This guide is an aid for the professional installation of the device.
Please note the following notes before installation:
• Always handle all parts of the device and the components of your vehicle with care.
• Under all circumstances observe the regulations of the vehicle manufacturer and do not make any
changes to the vehicle which could impair driving safety.
• For safety reasons, disconnect the vehicle battery’s ground connection before installation.
• Please always pay attention to the correct polarity of the connections.
• Please do not modify any harnesses or connections of the device or the vehicle as this may affect
the warranty.
• Make sure that no cables are squashed or cause a short circuit.
• Do not lay cables in front of the airbags, e.g. in the dashboard or in a way that affects their function.
Mounting wedges
7
GENERAL INSTALLATION INSTRUCTIONS
GPS antenna
The GPS antenna should be glued horizontally to the dashboard with the
adhesive side down. Reception is not possible with a metal-coated pane.
Choose a level spot with a clear view of the sky. The location should be
about 50 - 70 cm away from the main unit, otherwise the GPS measurement
accuracy will decrease. When installing the GPS antenna in the vehicle, the
GPS accuracy is determined by the installation position and the body shape
of the vehicle. Accuracy is usually lower when the GPS antenna is installed
in the dashboard.
Remove the foil on
the bottom of the
GPS antenna
NOTE: When using the device for the rst time and installing the navigation software for the rst time,
the search for GPS signals can take up to 30 minutes. After enough GPS satellites have been found
to determine the position, they are permanently stored in the device and can therefore be found more
quickly. If no GPS satellites are found afterwards or the GPS reception is poor, please note the following:
In order for the navigation software to function properly, sufcient GPS reception must be ensured on
the Naviceiver. This is signicantly inuenced by the installation position of the GPS antenna in the
vehicle. Therefore, make sure that the GPS antenna is properly installed in your vehicle to ensure the
best possible reception.
Depending on the location or the topographical conditions in the reception area, GPS reception can vary
and thus affect the functionality of the navigation software. GPS reception is also dependent on local
satellite reception, which could be affected by current or global events.
Under certain circumstances, GPS reception can also be impaired by electronic devices such as smart-
phones, inductive charging cradle or toll devices (e.g. Telepass, GO-Box etc.) in the vicinity of the GPS
antenna. In this case, reposition the electronic devices.
8
INSTALLATION STEPS
Lever out the ventilation grille in the center dash-
board above the storage compartment with a
mounting wedge.
Now connect the system plug of the vehicle with
the enclosed system cable set including the CAN
bus module.
2
4
If a device is already installed in the radio slot, you
must rst remove it.
Then remove the tray above the radio slot.
Stow the entire wiring harness in the rear radio
slot and lead out the 20-pin system connector on
the left-hand side.
If the vehicle only has one antenna connection for
FM/AM and DAB, use the enclosed FAKRA Y an-
tenna cable ZECW-A731016-000.
1
3
5 6
9
INSTALLATION STEPS
Remove the cover with USB and 12V socket.
8
Remove the cover in the driver’s side storage
compartment where the USB and 12V socket is
located.
7
Now connect all relevant connection cables ac-
cordingly to the ESX Naviceiver.
Then plug the two antenna plugs of the FAKRA Y
antenna cable into the connections for the FM/AM
radio and DAB antenna on the Naviceiver.
11 12
Tie the connection cable for the GPS antenna into
a loop and route it inside the dashboard to the
radio slot.
10
Underneath there is a small compartment in which
the included GPS antenna can be stowed. Op-
tionally, the 4G/LTE antenna can also be stowed
here.
9
10
INSTALLATION STEPS
If you have to remove the ESX Naviceiver again,
the middle cover has to be levered out of the
dashboard. This is clipped in at the corners. Use
a suitable assembly wedge for this.
Press on the two latches on the right and left of
the metal housing of the Naviceiver.
Then slide the ESX Naviceiver into the radio slot
until it clicks into place. Finally, carry out a func-
tion test. After a successful function test, reinsert
the storage tray and ventilation grille (see section
2 & 3).
Carefully unfold the entire cover.
The Naviceiver is then unlocked and can be
pushed out of the radio slot from behind and then
pushed out to the front
