Strobe Light Kit Wiring and Installation Guide
Since the integrity of this light system depends
on proper installation and wiring, we
recommend you have it installed by a certified
emergency vehicle technician.We are not
responsible for damage caused by improper
installation.
960 Strobe Tube Kit
When you order the 960 strobe kit, you will
receive 4 tubes, 4 wiring harnesses, and a 6-outlet,
90-watt power pack. There is additional room in
the power outlet for 2 additional light heads and
harnesses. The unit also comes with 12 feet of
wire for each tube.
Installation Instructions and Tips
•The unit is designed for plug and play action
•Install the power supply in a safe location that is easy to reach under any driving conditions
•Do not route wires near engine hot spots
•Male terminals need to face power supply
•Female terminals should be near terminals
•Strobe Tube Kit Installation Instructions
•Insert terminals in Tyco connectors
•Connect cable to each light head
•Locate output sockets in power supply
•Connect cables to output sockets
Powering the Strobe Tube Kit
