ULTRA100™
LED Spot Ellipsoidal, 100W, Black
User Manual
Manual ULTRA100™ www.Eternal Lighting.com
2 / 4
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE YOU INITIAL START - UP!
INTRODUCTION
Thank you for having chosen a led profile spot. You have acquired a powerful and versatile device.
Description of the device
1. Profile
With the idea of energy saving and environment protection, the device use lower power loss and
extremely high efficiency led. The device housing cover is made of used the new high strength heat
resistance engineering plastics, with beautiful shape and smooth lines. The designing and
manufacturing is in compliance with the IEC standard. The device is suitable in the large-scale
theatrical performance, the theater, the performance hall, the bar, night club and so on.
2. Safety warning
①.warning：
● Every person involved with the installation, operation and maintenance of this device has to be
qualified
● User must follow the instructions of this manual
● Unqualified person cannot open the housing cover and operate the device, or the dealer will not
accept liability for any resulting defects or problems.
● The device against rain and moisture
②：Warning notes
● Power supply: AC100V-240V/50HZ-60HZ
● Make sure the power switch is off, the power plug, outlet and the earth connection is in well
condition before connecting the device with the mains.
● Please use qualified power plug and outlet. Never connect the power cord of this device with other
electrical equipment.
● During move and installation, make sure the device not crashed with metal parts and other tough
materials.
● Always disconnect from the mains, when the device is on installation and dismantled
● The minimum distance between light-output and the illuminated surface must be more than 50cm.
● The device must only be installed on a non-flammable surface. In order to safeguard sufficient
ventilation, leave 50 cm of free space around the device. Please note that heat -sensitive objects may
be deformed or damaged by the emitted heat.
● During the operation the housing becomes very hot! Do not operate the device for 15 minutes after
switching off.
● The maximum ambient temperature Ta = 450C must never be exceeded. The maximum housing
temperature Tb = 800C must never be exceeded.
● For indoors use only.
● Replace any visible cracked protective shield, filters and lens.
Manual ULTRA100™ www.Eternal Lighting.com
3 / 4
● The protective shield, filters and lens will require weekly cleaning as smoke fluid tends to building
up residues, reducing the light output very quickly.
1. Installation
● When installation, keep the device far away the heat sensitive objects and explosives sensitive
objects, leave at least 50cm of free space around the device.
● When the device put on horizontal place, the device must be placed directly on the place, and
devices must be secured with a mounting bracket.
● When rigging the devices on the truss and the head face to the floor, Screw one clamp each via a
M12 screw and nut onto the mounting holder.
Insert the quick-lock fasteners of the first mounting holder into the respective holes on the bottom of the
device. Tighten the quick-lock fasteners fully clockwise. Install the second mounting holder.And the
safety rope must be used at same time.
● Please use qualified safety-rope, which can hold at least 10 times the weight of the fixture. You
must only use safety-ropes with quick links with screw cap. Pull the safety-rope through the hole on the
bottom of the base and over the trussing system etc. Insert the end in the quick link and tighten the
fixation screw. Asafety rope which already hold the strain of a crash or which is defective must not be
used again.
2. Connection with mains
● The person involved with the power connection must be qualified, and has the electrical
engineering certificate.
● Connect the device to the mains with the power plug.
● The earth has to be connected.
● Power consumption 200W, input power supply AC100V-240V, 50/60Hz.
3. The use of gobo frame
●Take out the gobo frame, loose the screws, insert the gobos and lock the screws again
●Insert the gobo in the slot.
4. Use iris
●Iris is not included when the projector leave factory, user can purchase the iris if needed. Loose the
screws and insert the iris.
5. Replacing fuse
● Before replacing the fuse, unplug mains lead.
● Procedure:
Step 1: Unscrew the fuse holder on the rear panel with a fitting screwdriver from the housing
(anti-clockwise).
Step 2: Remove the old fuse from the fuse holder.
Step 3: Install the new fuse in the fuse holder.
Step 4: Replace the fuse holder in the housing and fix it.
6. Focus
●The objective lens cylinder is usually shrinked before leaving factory, after connect the projector to
the mains, user may lose the screws and pull out the lens cylinder, till the white light output circular is
clearly presented, locking tightly the two screws again.
●When the projection distance is changed; user can follow previous operating steps, and focus the
projector.
Manual ULTRA100™ www.Eternal Lighting.com
4 / 4
Appendix
1. Problem and solution
problem
Reason
resolution
Device not work
No power
AC100V-AC240V，
Check the power connection, and make sure
device connect the mains in well condition.
Check if switch is on
Check if the fuse is good
Led bulb is off
led bulb damaged
Replacing led bulb
Led driver board damaged
Replacing led driver board
temperature switch damaged
Replacing temperature switch
Fans not work
Fans damaged
replacing fans
Technical Specifications
● Power Supply: AC90-260V, 50/60Hz
● Power Consumption: 150W
● LED: 1set 100W, White Color
● LED Color Temp: 6,300K
● LED Average Lifespan: 100,000hrs
● Center Beam Lux at. 1mtr projection distance:
1) 19°: 23,500Lux
2) 26°: 16,200Lux
3) 36°: 12,650Lux
4) 50°: 7,500Lux
● Standard Lens Included: 19°
● (Optional) Lens Available: 26°/36°/50°
● High-quality optical system
● Glass reflector
● Housing: Plastic
● Housing Color: Black, White
● Insulated handle
● Delivery includes 3 shutter, 1 gel frame & 1 gobo holder
● Iris (optional)
● 2 Fans Cool
● IP Rating: IP20
● Dimensions: 24” x 11”
● Net Weight: 10.5 lbs.
Please note: Every information is subject to change without prior notice.
