Etross FWT-8818 Manuale utente

FWT-8818 GSM Gateway

(FIXEDWIRELESS TERMINAL)

USER SMANUAL

1DESCRIPTION

FWT-8818 GSMisaFixedWireless Terminaldesignedto providebetter

wireless connectivitybetweenPOTS(plainoldtelephoneset)and

existingGSM900/1800Mhznetworkwithhighsensitivitytoreceive

signalandlargetransmittingpowertoexpandextensivelytheeffective

coverageofGSMservice.Itcanbeusednotonlyincommunicationfor

vehiclessuchasautomobiles,trains,floatingvehicles,etc., butalsoin

communicationforconstructionsites,isolatedislandsandruralareas

wherehardwire-linetelephoneserviceisunavailable.Sotheyarewidely

usedinhome&office, publicphone, ruralareas, steamer, railwayetc.

FWT-8818---a solutionforexpanding GSMservice coverage!

FUN PWR USE

Front View LED Indicator

DC RJ-11 DB PORTANT

Back View

SIM CARD

Bottom View

2LEDs DISPLAY INSTRUCTIONS

No.1-4 (FromRighttoLeft), Signalstrengthindication.

No.5, Working statusIndication:InUseornotuse.

No.6, PowerOn/offindication.

No.7, Function indication (greenlight)

*Whenthesystemstartup,thegreenlightwill lightonabout30seconds

thenoff, it enterworkstatus.

*Whenthering back, thegreenlightwill flashuntil you pickup.

*whenincommunication,thegreenlightwillbealwayson.(reversal

polarity)

*whennotcheckSIMcard,thenthegreenlightwill bealwaysflash,

you shouldchecktheSIMcardInstallation.

*whenthesystemhang(Dead),thegreenlightwill bealwayson,you

shouldre-poweron.

3MAIN FUNCTION &FEATURES

l Simpletoinstall and easytomaintain

l Steady module&reliabledesign ensuresgood performance

l Provideoptimizedcircuitdirectlyconnectingtheexchangedevice

forextensions

l Compatibletomosttelephones, PBX&VoIPgateways

l Strong signalswithhigh gainantenna

l AttractivePlasticcasing

l SIMcardsupport(3V,5V)

l CallerIDDisplay

l Providereversalpolaritysignalformetering

l Nonoise&Clearvoice

l Suitableforwidevoltagerange&Lowpowerconsumption

l Suitableforall kindsofweather&environment

l RJ-11 ports(twoextensionsline/phoneand line(optional))

l Locking PIN/Network(optional)

4SPECIFICATION

1.AirInterface Standard:GSM900/1800 MHzPhase2+

2.FrequencyRanges:

Transmission Reception

GSM900 890~915MHz935~960MHz

GSM1800 1710~1785MHz1805~1880MHz

3.ChannelSpace:200KHz

4.Userline, bell signal InlinewithGB/T15279

5.Max Power:0.25W/0.5W

6.Consume Immobility≤25MA,Transmission ≤400MA

7.Sensitivity -105db

8.Dialtonefrequency:450Mhz(Standard)

9.SurroundingTemperature -10 ℃～+40 ℃Relative

humidity:45% ～90%（Withoutfrost）

10.AtmospherePressure 86 ～106Pka

11.EnvironmentNoise:〈60db

12.AntennaAmplifying:3.5db(omni directional)、12db(certaindirection

/chosendirection )

13.ACPower DC10V—20V

Input: (AC100-230V,50/60Hz)Output: (12V1A)Switchingtype

/TransformertypeAc-adapter( optional)

14.ConnectorofPower China

15.Dimensions(L WH)Average:185×135×22（mm）

16.Weight FWT400g, full setwithac-adapter&antenna&box 850g

17.Color:White/blue(Optional)

18.Connection Mode RJ-11 phonesockets

19.AntennaConnection:SMAAntennaConnection.

5APPLICATION

l Forpublicuseaspayphones

l ForOffice &Homeuse

l Forruraland mountainousarea

l Formobilecarriage, likeship, automobileand trainetc.

l Forthosewherehardwire-linetelephoneservice isunavailable.

6INSTALLATION AND CONNECTION MODE

1.Antenna

ConnecttheheadofGSMantennatotheheadofantennaofthebackof

theFixed Wireless Terminal.

2.SIMCard

2.1 Openthebottomcoveroffixedwireless terminal；

2.2 PlugSIMCardintotheSIMcardholderofPCB board,thenfixthe

cover；

3.ConnectiontoTelephone

3.1 Draftfortheconnection ofterminaltotelephoneset

Ac-adapter

WithoneofWire(thetelephonelinewithcrystalhead)to

telephone,andanothersidetoTEL1 口orTEL2 口onthebackofthe

terminal,

4.Connectionto PBX

Antenna

ACadapter

Withoneend ofthewire(thetelephonelinewithcrystalhead)to

thesocketofPBXequipment,whileanotherend totheTEL1 口or

TEL2 口on thebackofthewireless terminal.

5.Connectionto Fixedline(PSTN)(Optional)

WiththePHONEPorttoconnectTELwithwire,AndLINEPortto

connectFixedlineofTel.comwithwire.

ThedefaultisdialingoutfromGSM,ifyouwanttomakecall from

PSTN, pleasepress “#”beforeyouinputthenumber.

Andyoucanreceivecallsfromcall toPSTNandGSMnumber

both.

7FUNCTION SETTING

1. Therighttocall localNo.

“**”——“ 6 digit password”——“ 1”——“ #or*”——hang up

（#=prohibit tocall *=permit tocall ）

2. Therighttocall DDD

“**”——“6 digitpassword”——“2”——“# or*”——hang up

（#=prohibit tocall *=permit tocall ）

3. Therighttocall IDD

“**”——“ 6 digit password ”——“ 3”——“ # or*”——hang up

（#=prohibit tocall *=permit tocall ）

4. Install tocall in

“**”——“6 digitpassword”——“4”——“# or*”——hang up

（#=prohibit tocall in*=permit tocall in）

5. Install tocall IP

“**”——“6 digitpassword”——“5”——“# or*”——hang up

（#=prohibit tocall IP*=permit tocall IP）

6. Modify5 Digit Access toIP

“**”——“ 6 digit password”——“ 6”——“ 5 digitalaccess toIP”

（If notenoughNo.pleaseuse ‘#’instead。Eg. Install

IP193 put193##）——hang up

（5 digitalaccess toIPshouldbe5 No.s，Theaccess No. toIPshould

becaller’sIPNo.，eg17909、17951、17911、17921、193##、17931 etc。）

7. Modify6 digit password

“**”——“ Original6 digit password”——“ 7”——“ New6 digital

pass word”——hang up

8. Install tohave “zero”ornotforthemobilephoneofex-cities

“**”——“6 digital ”——“8”——“# or*”——hand up

（#=use “zero”*=Notuse “zero”）

9. Reversalpolarity

“**”——“6 digitpassword”——“9”——“# or*”——hang up

（#=prohibit toreversalpolarity, *=permit toreversalpolarity）

10. Install touselocalIP

“**”——“6 digitpassword”——“0”——“# or*”——hand up

（#=prohibit tocall localIP*=permit tocall localIP）

11. InitializeSystem:

“**”——“6 digit password”——“#”

（theinitialpassword:000000 or123456,thedefaultstatusforlocalcall

permit,DDD call permit,IDD call permit,reversal-polarity

permit; localIP,LongdistanceIP,localIP,longdistanceIP,

Prohibit,）

8NOTES:

1. Inordertoreducetheaffectofotherelectronicsproductsto

wireless terminal,pleasekeepthedistanceatleast1meter

betweenthem.

2. ThefrequencyofWireless terminalmayaffectsomeelectronics

equipments,sodon’tusethewireless terminalinthearea where

thewireless equipmentsareprohibitedtouse.

3. Don’tpulloutorpluginSIMcardfrequentlyifnotnecessary,if

thespringofSIMcardholderisnotproperlytouched, please

curvewarpthespring sothatit canbetouchedproperly,and

workproperly

4. Don’tswitchfrequentlythepowerofwireless terminal,the

intervalbetweenthetwoswitchesshouldbeover10 secondsand

more, otherwisetheremaybesomedamagetoit.

WarrantyCard

Pleasefill intheblankscarefully,andkeepit properlyasthevoucher

forwarranty.

TypeofEquipment

FWT-8818 GSMFixed Wireless Terminal

User’sname Contactwith:

ContactTel.no.

Address

DateofEx-works

DateofMaintenance

Damage Management Maintainer

SalesAgent

(Stamp)

Purchasing Date
