ETS-Lindgren 8000-002 Manuale utente

Model 8000-002

RF Power Amplifier

User Manual

www.ets-lindgren.com

ETS-Lindgren Inc. reserves the right to make changes to any products herein to improve

functioning or design. Although the information in this document has been carefully reviewed and

is believed to be reliable, ETS-Lindgren does not assume any liability arising out of the

application or use of any product or circuit described herein; nor does it convey any license under

its patent rights nor the rights of others. All trademarks are the property of their respective

owners.

be copied by any means without written permission from ETS-Lindgren Inc.

Trademarks used in this document: The ETS-Lindgren logo is a registered trademark and

Calibration Services Plus is a trademark of ETS-Lindgren Inc.

Revision Record

MANUAL, 8000-002 | Part #399601, Rev. A

Revision

Description

Date

Initial Release

September, 2014

www.ets-lindgren.com

iii

Table of Contents

Notes, Cautions, and Warnings.........................................................................v

Safety Information ..............................................................................................v

1.0 Introduction...................................................................................................7

Standard Configuration....................................................................................................... 7

2.0 Maintenance..................................................................................................9

Service Procedures ............................................................................................................ 9

Contacting ETS-Lindgren............................................................................................. 9

Sending a Component for Service............................................................................... 9

3.0 Specifications..............................................................................................11

Electrical Specifications.................................................................................................... 11

Physical Specifications..................................................................................................... 11

4.0 Before You Begin........................................................................................13

Unpacking......................................................................................................................... 13

Safety Information ............................................................................................................ 13

Warnings........................................................................................................................... 14

5.0 Installation...................................................................................................15

Mains Input....................................................................................................................... 15

Amplifier Protection .......................................................................................................... 15

6.0 Operation.....................................................................................................17

Equipment Use................................................................................................................. 17

Mains Switch..................................................................................................................... 17

Standby/Operate Switch (Centre Unit)............................................................................. 17

Fault Indicator (Red LED)................................................................................................. 18

Interlock Indicator (Orange LED)...................................................................................... 18

Local Lockout Indicator..................................................................................................... 18

RF Input (Either Front or Rear Panel Mounted) ............................................................... 18

RF Output (Either Front or Rear Panel Mounted) ............................................................ 18

Air Inlet.............................................................................................................................. 19

Safety Interlock................................................................................................................. 19

Fan Outlet......................................................................................................................... 19

Appendix A: Warranty ......................................................................................21

Scope and Duration of Warranties ................................................................................... 21

Warranty Exclusions......................................................................................................... 22

www.ets-lindgren.com

Buyer’s Remedies ............................................................................................................ 22

Appendix B: EC Declaration of Conformity....................................................25

www.ets-lindgren.com

Notes, Cautions, and Warnings

Note: Denotes helpful information intended to provide tips for better use of the

product.

CAUTION: Denotes a hazard. Failure to follow instructions could result in

minor personal injury and/or property damage. Included text gives proper

procedures.

WARNING: Denotes a hazard. Failure to follow instructions could result in

SEVERE personal injury and/or property damage. Included text gives

proper procedures.

Safety Information

Warning: Avoid exceeding the stated maximum input level as this can

cause a risk of damaging the equipment.

Warning: There is a significant risk of an electrical or burn hazard, to

avoid this always ensure the output is terminated prior to switching on

the equipment.

Protective Earth Ground (Safety Ground): Indicates protective earth

terminal. You should provide uninterruptible safety earth ground from the

main power source to the product input wiring terminals, power cord, or

supplied power cord set.

Waste Electrical and Electronic Equipment (WEEE) Directive: (European

Union) At end of useful life, this product should be deposited at an

appropriate waste disposal facility for recycling and disposal. Do not

dispose of with household waste.

www.ets-lindgren.com

This page intentionally left blank.

www.ets-lindgren.com

Introduction

1.0 Introduction

The ETS-Lindgren Model 8000-002 RF Power Amplifier is capable of supplying a

minimum of 275 watts into a 50 ohm load over the frequency range 80MHz to

1000MHz. The amplifier is designed with sufficient gain so that it may be used with

normal output levels of signal sources.

A safety interlock on the rear panel is also provided, which will mute the

amplifier when grounded.

The unit is powered by a switched mode power supply for high efficiency,

high power factor, and a wide voltage range operation. The unit is air cooled

with integral fans and is protected against faulty cooling by excess

temperature sensing.

A front panel fault indicator is provided to indicate over-temperature.

The amplifier is designed for rugged operation into a variety of loads and is primarily

intended for use as an RF power source for EMC susceptibility testing, but is also

applicable to other systems requiring a wide-band linear amplifier.

This amplifier is designated as Professional Equipment and should not be operated

by untrained staff. As this product has the capability to generate high levels of RF

energy it is not intended for use in a residential environment.

Standard Configuration

The 8000-002 amplifier comes either as a bench top unit or rack unit for installation

into a 19-inch rack.

The RF connectors are N type input which are located either on the front or rear

panel of the amplifier.

Introduction

www.ets-lindgren.com

This page intentionally left blank.

www.ets-lindgren.com

Maintenance

2.0 Maintenance

If you have any questions concerning maintenance or if the amplifier system is

misoperating, contact ETS-Lindgren Customer Service. See Service Procedures for

contact information.

CAUTION: Before performing any maintenance, follow the information

provided in Before You Begin on page 13.

WARRANTY

WARNING: There are no user serviceable parts within the RF Power

Amplifier system.

To prevent electrical shock, DO NOT remove covers.

Warranty will be void if the covers are opened.

ALWAYS UNPLUG THE UNIT BEFORE CLEANING. Clean the exterior of

the cabinet using a damp cloth.

Service Procedures

CONTACTING ETS-LINDGREN

Note: Please see www.ets-lindgren.com for a list of ETS-Lindgren offices,

including phone and email contact information.

SENDING A COMPONENT FOR SERVICE

1. Contact ETS-Lindgren Customer Service to obtain a Service Request

Order (SRO).

2. Briefly describe the problem in writing. Give details regarding the

observed symptom(s) or error codes, and whether the problem is

constant or intermittent in nature. Please include the date(s), the service

representative you spoke with, and the nature of the conversation.

Include the serial number of the item being returned.

3. Package the system or component carefully. If possible, use the original

packing materials or carrying case to return a system or system

component to ETS-Lindgren.

Maintenance

www.ets-lindgren.com

This page intentionally left blank.
