eufy Security S300 Manuale utente
51005003503 V01
S300 eufyCam
QUICK START GUID
E
Anker Innovations Limited. All rights reserved. eufy Security and eufy Security Logo
are trademarks of Anker Innovations Limited, registered in the United States and
other countries. All other trademarks are the property of their respective owners.
EN 01
English 01
Deutsch 15
Español 29
Français 43
Italiano 57
Nederlands 71
Portuguese 85
99
①
②
③
④
⑧
⑩
⑨
⑥
⑦
⑤
AT A GLANCE
S300 eufyCam
Model: T8161
①SYNC Button ⑥Microphone
②Camera Lens ⑦Motion Sensor
③Photosensitive Sensor ⑧Mounting Hole
④Spotlight ⑨USB-C Charging Port
⑤LED Indicator ⑩Speaker
02 EN EN 03
Prepare Your Hard Drive
Your hard drive must meet the following requirements:
Type Hard disk drive (HDD) or solid state drive (SSD) that uses the SATA
interface
Size 2.5 inch
Capacity Unlimited
Recommended Western Digital, Seagate, SAMSUNG, Kingston, PNY, Crucial, SanDisk
EXPANDING STORAGE
(OPTIONAL)
S380 HomeBase comes with 16 GB of storage for saving video recordings and
allows you to add an additional hard drive to expand the space.
Transfer all the data in your hard drive to a secure location before adding
it to S380 HomeBase.
HARD DRIVE
①
④
⑤
⑥
⑦
⑧
⑨
②
③
S380 HomeBase
Model: T8030
①Status LED ④Hard Drive Bracket ⑦USB Port 2
②Reset Hole ⑤SYNC / ALARM OFF Button ⑧Ethernet Port
③Speaker ⑥USB Port 1 ⑨Power Port
04 EN EN 05
3. Fix your hard drive to the bracket with the provided screws.
HARD DRIVE
4. Insert and screw the bracket back to S380 HomeBase, then put the top lid back
into place.
• You can follow the steps above to expand the storage whenever necessary.
• A new hard drive must be initialized through the eufy Security app to work with
S380 HomeBase.
Install Your Hard Drive
S380 HomeBase must be powered off when you install or remove a hard
drive.
1. Push down the top lid to remove it.
2. Loosen the screw, then pull out the hard drive bracket.
06 EN EN 07
3. Follow on-screen instructions to add S380 HomeBase and the cameras to your
device list(*).
* One S380 HomeBase can pair up to 16 cameras.
SETTING UP
1. Power and connect S380 HomeBase to your router. The LED indicator will turn
blue (This may take about 1 min) when S380 HomeBase is ready for setup.
2. Download and install the eufy Security app, then sign up for an account.
08 EN EN 09
CHARGING THE CAMERA
Fully charge both cameras before first use. This may take about 8 hours for each.
5V USB Charger
USB Port 1
LED Indicator Description
Blue Charging
OFF Fully charged
Option 1
Option 2
MOUNTING THE CAMERA
Select a Location
Select a location where you can get the desired view. We recommend hanging the
camera 7-10 ft (2-3 m) above the ground.
Motion
Detection
Zone
Camera
Field-of-View
Up to 26 ft (8 m)
7-10 ft
(2 - 3 m)
Motion
Detection
Zone
10 EN EN 11
Mount the Camera
1. Turn the knob of the mounting bracket counterclockwise to loosen and
disassemble it.
2. Drill holes with a 15/64 inch (6 mm) drill bit, then insert the anchors into the
holes; anchors are necessary for walls that are made out of hard materials such
as concrete, brick, or stucco.
3. Firmly screw the knob of the mounting bracket into the mounting hole.
4. Hold and screw the camera to the mounting bracket. Rotate the camera to
adjust the view and check it using the live stream, which you can access in the
eufy Security app.
For troubleshooting, check Help on the eufy Security app. Refer to the app page
for LED indicator status.
12 EN EN 13
SAFETY
- Do not use the device in the environment at a too high or too low temperature,
never expose the device to strong sunshine or too wet environment.
- The suitable temperature for T8030 and accessories is -10°C to 45°C .
- The suitable temperature for T8161 and accessories is -20°C to 50°C (Charging
temperature is 0°C to 45°C) .
- It is recommended to supply the device in an environment with a temperature
that ranges from 5°C~25°C.
- When supplying, please place the device in an environment that has a normal
room temperature and good ventilation.
- The adapter shall be installed near the equipment and shall be easily accessible.
- Please ensure to use only the adapter offered by the manufacturer. Using
unauthorized adapter may cause danger and violate the authorization of the
device and the guarantee article.
- This adapter is for indoor use only. The adapter type (for S380 HomeBase) is
KA2401A-1202000DE, rated output voltage/current is 12 Vdc/2A. The plug is
considered as disconnect device of adapter.
Warning:
- Replacement of a battery with an incorrect type can defeat a safeguard;
- Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting
of a battery can result in an explosion;
- Leaving a battery in an extremely high temperature surrounding environment
can result in an explosion or the leakage of flammable liquid or gas; and
- A battery subjected to extremely low air pressure may result in an explosion or
the leakage of flammable liquid or gas.
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
NOTICE
NOTICE (Europe and United Kingdom)
This product complies with the radio interference requirements of the
European Community.
Declaration of Conformity
Hereby, Anker Innovations Limited declares that this device is in compliance with
the essential requirements and other relevant provisions of Directive 2014/53/EU.
For the declaration of conformity, visit the website: https://uk.eufylife.com.
This product complies with the radio interference requirements of the
United Kingdom
Declaration of Conformity
Hereby, Anker Innovations Limited declares that this device is in compliance
with Radio Equipment Regulations 2017(SI 2017/1206). The full text of the UK
declaration of conformity is available at the following internet address:
https://uk.eufylife.com.
RF exposure information:
The Maximum Permissible Exposure (MPE) level has been calculated based on
a distance of d=20 cm between the device and the human body. To maintain
compliance with RF exposure requirement, use products that maintain a 20cm
distance between the device and human body.
Frequency bands and power as below:
Function Bandes Operation Frequency Max.Power
Sub-1G for T8030 Sub-1G 866-866.8 MHz ERP 12.973 dBm
Wi-Fi for T8030 2.4GHz 2412-2472MHz EIRP 19.58 dBm
Wi-Fi for T8161 2.4GHz 2412-2472MHz EIRP 19.81dBm
The following importer is the responsible party (contract for EU matters):
Anker Innovations Deutschland GmbH I Georg-Muche-Strasse 3, 80807 Munich,
Germany
The following importer is the responsible party (contract for UK matters):
Anker Technology (UK) Limited I GNR8, 49 Clarendon Road, Watford,
Hertfordshire, WD17 1HP, United Kingdom
14 EN
Your product is designed and manufactured with high quality materials and
components, which can be recycled and reused.
This symbol means the product must not be discarded as household
waste, and should be delivered to an appropriate collection facility for
recycling. Proper disposal and recycling helps protect natural resources,
human health and the environment. For more information on disposal and
recycling of this product, contact your local municipality, disposal service, or
the shop where you bought this product.
Anker Innovations Limited
Room 1318-19, Hollywood Plaza, 610 Nathan Road, Mongkok, Kowloon, Hong
Kong
15 DE DE 16
①
④
⑤
⑥
⑦
⑧
⑨
②
③
AUF EINEN BLICK
S300 eufyCam S380 HomeBase
Modell: T8161 Modell: T8030
①Status-LED ④Festplattenhalterung ⑦USB-Anschluss2 (Ausgang:
5VDC/0,7A)
②Zurücksetz-Öffnung ⑤SYNC/ALARM OFF-Taste ⑧Ethernet-Anschluss
③Lautsprecher ⑥USB-Anschluss1 (Ausgang:
5VDC/2,4A)
⑨Stromanschluss
①
②
③
④
⑧
⑩
⑨
⑥
⑦
⑤
①SYNC-Taste ⑥Mikrofon
②Kameraobjektiv ⑦Bewegungssensor
③Lichtempfindlicher Sensor ⑧Befestigungslöcher
④Scheinwerfer ⑨USB-C-Ladeanschluss
⑤LED-Anzeige ⑩Lautsprecher
