SANDBLASTPRO 30L

Réf. 30860

User manual

Edition of 14/06/2021

More information on www.euromair.com

User manual - SandblastPro 30L 202106-528-ENGP2

You just acquired one of our

machines and all the team

of Europe Projection thanks

you for the condence

you have granted us.

Manufacturer of professional

equipments for paint and

llers, we have put our

know-how for 25 years

at the service of the

users of our machines.

Our technical & commercial

team is at your disposal

for any further information

you may need about the

machine you just acquired.

EUROPE PROJECTION

228, avenue Olivier Perroy

13790 ROUSSET

Tél : +33 (0)4 42 29 08 96

contact@euromair.com

SUMMARY

1. USER MANUAL............................................................. p. 3

1.1. Importance of the manual .........................................p. 3

1.2. Receivers of the manual............................................p. 3

2. WARNING .................................................................... p. 4

2.1. Safety .....................................................................p. 4

2.2. End-of-life of the product ..........................................p. 6

3. YOUR MACHINE ........................................................... p. 7

3.1. Description..............................................................p. 7

3.2. Technical characteristics ...........................................p. 7

3.3. Identication of the components ................................p. 8

4. USE OF THE MACHINE ................................................. p. 9

4.1. Prerequisites............................................................p. 9

4.2. Starting up ..............................................................p. 9

5. FAILURES AND REMEDIES............................................ p.10

6. MAINTENANCE............................................................. p.11

7. DECLARATION OF CONFORMITY ................................... p.13

8. WARRANTY CONDITIONS.............................................. p.15

202106-528-ENG User manual - SandblastPro 30L P3

1. USER MANUAL

1.1. IMPORTANCE OF THE MANUAL

This manual is a key part for the use of your machine. It summarizes the procedures of starting-up, cleaning

and maintenance of the device and also the safety instructions you need to observe.

Read carefully all the working and safety instructions and the warnings included in this manual before

starting your machine.

Most of the accidents are caused by the non-compliance of the safety standards and rules.

This manual must be kept near the machine, within reach of the user and held in good condition until the

nal destruction of the machine.

In case of loss or deterioration of the manual, you can ask the machine manufacturer mentioned on page

4 for a copy at any moment.

1.2. RECEIVERS OF THE MANUAL

This manual is intended to any staff which will manipulate the machine :

- people in charge of the transport of the machine

- people in charge of the use of the machine

- people in charge of the cleaning and maintenance of the machine

- people in charge of the nal destruction of the machine

User manual - SandblastPro 30L 202106-528-ENGP4

2. WARNING

2.1. SAFETY

Using the machine in an incorrect way or in non-compliance of the safety instructions indicated in

this manual can cause death or serious injuries.

Read carefully all the working and safety instructions and the warnings contained in this manual

before starting your machine.

• Respect all the safety standards before running the equipment.

• Use the equipment only for the applications specied in the manual.

• Always remain alert when using the equipment.

• Transport the machine using the handles or the appropriate grips.

• During the breaks, disconnect electrically the machine.

• Run the equipment to its nominal voltage.

• Let at least 50 cm of free space between the equipment and any obstacle so that the air ow

is not blocked.

• Know how to quickly stop the equipment in case of necessity.

• Never use the equipment while it is running abnormally or it is defective.

• Do not direct a water jet or ammable liquid on the machine.

• Never direct an air jet or product jet on a person or an animal.

• Do not touch warm surfaces of the equipment.

• Never touch moving parts.

• Do not insert any object or the hands inside the protection grids to avoid any accident or

damage to the machine.

• For any outside job, only use appropriate extension cords.

• Always wear adequate body protections (glasses, gloves, overall and mask) and pay attention

to long hair.

• Maintain the equipment carefully and clean it properly after every use.

• Disconnect the equipment before any intervention.

• Avoid absolutely to unscrew any connection while the machine is under pressure.

• Check the damaged parts.

• Do not clean the plastic parts with solvant.

• In case of damage of the electric cable or the plug, do not run the machine and contact a

licensed After-Sale Service to put genuine parts instead of the defective ones.

• In case of needed After-Sale Service, always specify the machine model and its serial number.

• For any replacement of parts, only use genuine parts.

• Do not modify the machine.

• Do not cut or dismantle the protection grids.

• Do not open the electric box.

202106-528-ENG User manual - SandblastPro 30L P5

IN CASE OF NECESSITY, WE SAVE OURSELVES THE RIGHT TO MAKE ANY USEFUL

MODIFICATION WITHOUT ADVANCED NOTICE.

2. WARNING (continued)

2.1. SAFETY (continued)

WORKSPACE

• Maintain the workspace clean and clear.

• Ambient operating temperature must be from 5°C and 35°C.

• Do not use the equipment in a potentially explosive area.

• Do not place any potentially inammable objects in close proximity to the machine.

• Take away every not qualied person from the working area of the machine, as well as children and

animals.

• In case of installation of the machine on scaffolding or a plan above ground level, attach the machine

to avoid any fall while operating.

• Do not install the equipment on an inclined surface to avoid the risks of unexpected moves or falls.

HOSES

• Always use hoses and connections adapted to the used product (genuine parts), do not try to x it.

• Do not walk on the hoses, do not bend them.

• Do not use the hoses to pull the machine.

STORAGE

• Keep the equipment in a clean and clear area in which the temperature does not exceed +35°C.

User manual - SandblastPro 30L 202106-528-ENGP6

2. WARNING (continued)

2.2. END OF LIFE OF THE PRODUCT

At its end-of-life, the machine must not be eliminated with the other household waste. The

uncontrolled elimination of waste can harm the environment or human health. Individuals are

invited to contact the distributor which sold them the product or to inquire with their city hall

to know where and how to get rid of the product so it can be recycled while respecting the

environment.

Under the regulation of Waste of Electrical and Electronic Equipments (WEEE), we undertake to

process the used EEEs according to the following provisions: applicable only to products on the

market since 08/13/05, under the brands EUROPE PROJECTION or VOLUMAIR, products of other

brands sold by our company (upon presentation of the corresponding invoices), products that

operate using electrical energy (for example, thermal washers or compressors do not fall into this

category).

Treatment modality

WEEE returns collected by our clients/distributors at their own expense to our collection points in

Antony (92) or Rousset sur Arc (13). Upon receipt, the products are sorted by our employees and

directed to the most appropriate processing channels.

For any further information, please contact our hotline +33 4 42 29 08 96 or conseil@euromair.com.

202106-528-ENG User manual - SandblastPro 30L P7

3. YOUR MACHINE

3.1. DESCRIPTION

Compact and handy, this versatile sandblaster is designed for small-scale stripping jobs by sandblasting or

microblasting:

• refurbishment of old furniture

• small facade renovation jobs

• cleaning of soft stones

• preparation of metallic surfaces (railings, portals, etc.)

• restoration of former vehicles

• cleaning of wall grafti

• glass engraving

The machine is also ideal for hydroblasting (with optional kit).

3.2. TECHNICAL CHARACTERISTICS

Max. working pressure 6 bar

Air consumption 450 L/min

Tank capacity 30 L

Dimensions (L x w x h) 51 x 44 x 92 cm

Weight 32 kg

Delivered with

- a hose of 8 m

- a sanding-gun

- a Ø3 mm Venturi tungsten nozzle

- a lling bowl

- a sieve

- a pair of gloves

- a face protection screen

- a FFP2 ap respirator mask

Do not use water or moistened cotton wadding at the risk of clogging the machine.

User manual - SandblastPro 30L 202106-528-ENGP8

3. YOUR MACHINE (continued)

3.3. IDENTIFICATION OF THE COMPONENTS

AGun

BNozzle

CFilling funnel (with integrated strainer)

DAir inlet connection

EAir pressure adjustment knob

FManometer

GAbrasive ow adjustment knob

202106-528-ENG User manual - SandblastPro 30L P9

4. USE OF THE MACHINE

4.1. PREREQUISITES

• It is advisable to cover the oor where the blasting operation is to be carried out so that the work area

can be cleaned more easily. The residues from the blasting operation (paint, varnish, metal, etc.) can

be harmful to the environment and the user.

• It is imperative to use clean and dry air when using the sandblaster to avoid the risk of clogging.

Depending on the compressor used, an air dryer should be used in addition.

• Always use the personal protective equipment supplied with the machine (gloves, visor, mask) in order

to avoid risks for the operator.

4.2. STARTING UP

1. Connect the air hose to the coupling (D) and start the compressor coupled to the sandblaster.

2. Insert the funnel (C) with the sieve and pour the abrasive.

3. When all the abrasive has owed into the tank, remove the lling funnel and close the cap.

4. Fit the appropriate nozzle (B) to the gun (A).

5. To adjust the air ow, pull the knob (E) upwards. Rotate to adjust and then press the knob back in to

conrm the setting.

6. To adjust the abrasive ow rate, turn the knob (G). Counterclockwise to increase the ow, clockwise

to decrease the ow.

7. Press the gun trigger to start working.

User manual - SandblastPro 30L 202106-528-ENGP10

5. FAILURES AND REMEDIES

Failure To be checked Remedy

Air does not come out of

the nozzle.

• Compressor not connected or

switched off.

• Connect the compressor to the

sandblaster and turn it on.

• Nozzle clogged. • Remove the gun nozzle and blow it

out to remove the blockage.

• Clogged product hose. • Remove the product hose and clean

it.

• Abrasive outlet blocked. • Turn knob (G) to increase ow rate.

• Clean the tank outlet lines.

• The three-way valve in the regulation

box does not work. • Repair or replace valve.

Abrasive does not come

out of the gun.

• No abrasive in the tank. • Fill the tank with abrasive.

• Abrasive outlet blocked. • Turn knob (G) to increase ow rate.

• Clean the tank outlet pipes.

• Excessive particle size of the abrasive

used.

• Empty the tank and ll it with the

correct abrasive grain size.

• Blow out the hoses to remove any

remaining abrasive.

• Abrasive outlet knob closed. • Turn the knob (G) to increase the ow

rate.

Non-uniform ow of

abrasive.

• Wet abrasive or abrasive with foreign

particles.

• Empty the tank and ll with dry,

ltered abrasive.

• Excessive particle size of abrasive

used.

• Empty the tank and ll it with the

correct abrasive grain size.

• Blow out the hoses to remove any

remaining abrasive.

• Abrasive ow knob too open. • Turn the knob (G) to regulate the ow.

The result of the

application is not

satisfying.

• Nozzle not suitable for the application. • Change the nozzle.

• Lack of seal. • Change hoses.

• Inadequate working pressure. • Turn the adjustment knob (E) until the

desired result is achieved.

• Inadequate abrasive for the job.

• Contact the abrasive supplier to use

the most suitable product for the

application.

Before loosening the hose, make sure it is no longer under pressure.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali EUROPRO Utensili elettrici

EUROPRO

EUROPRO 0701AREN30MAS Manuale utente

Manuali Utensili elettrici popolari di altre marche

AEG

AEG OMNI-JS Manuale utente

SIP

SIP 01533 Manuale utente

Ribimex

Ribimex PRS499 Manuale utente

3M Fiber Optic Connector Crimp Tool Manuale utente

Ryobi

Ryobi P524 Manuale utente

ROJEK

ROJEK FSN 300A Manuale utente

Kemper

Kemper 1740PRO Manuale utente

WABCO

WABCO OptiTire Manuale utente

EINHELL

EINHELL TE-MS 18/210 Li Manuale utente

Orgapack

Orgapack OR-T 85 Guida rapida

TOUGHCUT

TOUGHCUT Diamond 400 Manuale utente

Yaros

Yaros PB-3603 Manuale utente

Fein

Fein BSS 2.0 E Guida all'installazione

Baileigh Industrial

Baileigh Industrial SS-2725 Manuale utente

Milwaukee

Milwaukee 2674-20 Manuale utente

Fein

Fein BLs 1.6 Manuale utente

Princess

Princess Electric Multi Sharpener Manuale utente

FOREDOM

FOREDOM K.1050 Manuale
