Euroscreen Connect C1520 Istruzioni utente

Document PDSC ver 1.0, page 1 of 2

Connect

VIDEO

4 : 3

WIDE

16 : 9

Bjurab Sweden AB

Kristinebergsvägen 22

SE-302 41 Halmstad

Sweden

Tel: +46 – 35 – 144290

Fax: +46 – 35 – 144291

Email: [email protected]

Web: www.bjurab.se

The screen has 5 cm wide

black borders. The format of

the viewing area is 4:3.

Available Formats

SQUARE

1 : 1

The screen has 5 cm wide

black borders. The format of

the viewing area is 16:9.

The screen format is 1:1. No

black borders.

NORDIC

H>W

Nordic Format, height>width,

with extra height that gives

additional ﬂexibility. No black

borders.

The screen fabric has a matt

white surface which provides

a 180º viewing angle.

Surface

Connect is a basic compact screen which is very easy to install. The case is made

of steel and painted white. It can be mounted either on the wall or in the ceiling

and is attached to the wall/ceiling with one screw at each end of the case. The

screen is operated manually.

Example – Connect Dimensions

Model: C2217-V

Screen width: 2200mm

Total width: 2200mm + 91mm = 2291mm

Width between mounting holes:

2200mm + 76mm = 2276mm

Bar width: 2200mm + 66mm = 2266mm

,ENGTHSEETABLE





Screen width Box length

1250 1440

1400 & 1500 1690

1600 1890

1800 & 2000 2190

2200 & 2400 2590

Screen Dimensions

Packaging Dimensions

All dimensions in this document are in mm

X



3CREENWIDTH

3CREENWIDTH

3CREENWIDTH

















Nordic Format, H > W

Square Format, 1 : 1

Video Format, 4 : 3 Wide Format, 16 : 9

ART. NO

SCREEN SIZE

WIDTH x HEIGHT

WT.

ART. NO

SCREEN SIZE

WIDTH x HEIGHT

WT.

ART. NO

SCREEN SIZE

WIDTH x HEIGHT

VIEW. AREA

WIDTH x HEIGHT

WT.

ART. NO

SCREEN SIZE

WIDTH x HEIGHT

VIEW. AREA

WIDTH x HEIGHT

WT.

C1420 1400 x 2000 5.4 C125 1250 x 1250 3.9 C1617-V 1600 x 1650 1500 x 1125 6.2 C1617-W 1600 x 1650 1500 x 845 6.2

C1520 1500 x 2000 5.6 C150 1500 x 1500 5.3 C1817-V 1800 x 1650 1700 x 1275 7.3 C1817-W 1800 x 1650 1700 x 955 7.3

C1620 1600 x 2000 5.9 C180 1800 x 1800 6.6 C2017-V 2000 x 1650 1900 x 1425 7.4 C2017-W 2000 x 1650 1900 x 1070 7.4

C1820 1800 x 2000 6.7 C200 2000 x 2000 8.0 C2217-V 2200 x 1650 2100 x 1575 9.7 C2217-W 2200 x 1650 2100 x 1180 9.7

C220 2200 x 2200 10.1 C2417-V 2400 x 1800 2300 x 1725 10.3 C2417-W 2400 x 1650 2300 x 1295 10.3

C240 2400 x 2400 11.3

ARTICLE NO ARTICLE NO ARTICLE NO

485030 30 cm brackets,pair 340000 Magnetic strip, 60 cm 400140 Drawstick, 140 cm

485050 50 cm brackets,pair 340004 Supermagnet with hook 400300 Screen Cleaning Spray, 250 ml

485075 75 cm brackets,pair 400100 Drawstick, 100 cm

Article Numbers for Connect

Accessories

Bjurab Sweden AB

Kristinebergsvägen 22

SE-302 41 Halmstad

Sweden

Tel: +46 – 35 – 144290

Fax: +46 – 35 – 144291

Email: [email protected]

Web: www.bjurab.se

All dimensions in this document are in mm. Document PDSC ver 1.0, page 2 of 2

All weights are gross (total weight including packaging,brackets etc.).
