Eurosound DMTP65i5 Manuale utente

DMTP65i5/75i5 User Manual

Multi interactive all in one display

Multi interactive all in one display instruction manual

Very grateful that you have purchased our liquid crystal multimedia interactive display with most natural

colors, in

order that you utilize the products, please read the manual carefully, keep it well for easy reference.

•Don't put the product under strong sunlight shining on the display and never watch it under dark

environment,

otherwise it will make your eyes wearisome. Suggest watching the display under soft light.

•20CM distance should be gapped between display and surrounding wall to ensure the ventilation.

•When using the display, don't cover the ventilation hole with newspaper. table cloth. curtain etc. to harm

its heat

radiation.

•Avoid putting display under high temperature for preventing its components aging

and damage.

The usage power supply is AC 100V-240V, 50/60 HZ.

•Power cord connected with this display must have ground wire, otherwise it may

cause fire hazard.

The display is equipped with antenna isolator, please install and

use it with the display.

•Please adjust to “off” status when not using to reduce power consumption.

•Ensure the watching quality premise, reduce the display's brightness to lighten its power

consumption.

Recycle and re-use it after display is being deserted.

•The display is fit for requirement on hazardous substances' management regulations.

There is internal high voltage component, please do not dismantle the display randomly to avoid electricity

shock. If

there is any damage on the display, please contact local dealer or manufacturer.

The display is not waterproof, please do not place liquid compartment on the display, for example vases with

water

inside.

Please unplug the power cord in time of cleaning the display, then use dry soft cloth to clean its surface.

Do not use the display upon lightning and thunder weather, and unplug the 220V power cord and antenna plug

in case

of being hit and damaged by lightning.

The screen is made of glass and it may be damaged under strong hit or sharp hard objects.

The 220V power socket must be grounded well, the wired network connected with this display must be

separated well

from the protective areas in case of causing fire.

The display must be fixed well along with hanging bracket and wall in case of dropping danger.

When the indication light of the remote controller is on “red” status, some internal components still have high

voltage

electricity.

“Lightning” symbol's safe definition

-Warning users of disobeying “caution” requirements to use the display and cause

damage on

personnel.

-Warning users of disobeying “caution” requirements to use the display and cause

damage on the

product.

“Attention” symbol's safe definition

-It reminds users of the important operation, maintenance, repair instruction.

Caution

Safe Precautions

4



Multi interactive all in one display instruction manual



Installation .............................................................................................................................................................................5
Functional Part.......................................................................................................................................................................6
Back Cover Display Port.........................................................................................................................................................6
Front Set Display Port............................................................................................................................................................7
Ops Computer Port................................................................................................................................................................7
Remote Controller Operation Instruction.............................................................................................................................8
System Instruction.................................................................................................................................................................8
1.1

Conference System Launcher.................................................................................................................................9
1.2

Side Column............................................................................................................................................................9
1.3

Notification Panel.................................................................................................................................................14
1.4

Status Column ......................................................................................................................................................16
1.5

System Set Up.......................................................................................................................................................19
1.5.1

Common Use.....................................................................................................................................................20
1.5.2

Network.............................................................................................................................................................23
1.5.3

Time...................................................................................................................................................................25
1.5.4

Intelligence........................................................................................................................................................25
1.5.5

System...............................................................................................................................................................28
Software Instruction............................................................................................................................................................29
2.1

Electrical White Board..........................................................................................................................................29
2.2

File Management .................................................................................................................................................38
2.3

Welcome Vip ........................................................................................................................................................45
2.4

Multi Screen Sharing ............................................................................................................................................47
2.5

More Application..................................................................................................................................................48
Dual System Equipment Display Remote Control Code.....................................................................................................49
1.1

6 Byte Ordering, Baud Rate 115200.....................................................................................................................49
1.2

Equipment Control Code......................................................................................................................................49
2.1 Equipment Display Port Terminal Search Code..........................................................................................................50
Rohs Environmental Instructions Of The Product..............................................................................................................51

INDEX


Batteryinstallation

press the battery back cover of remote controller and slide downwards

Put 2 batteries 1.5V(AAA spec.), ensure placing its pole (+/-) correctly with the indication on the remote controller.

Slide and fix the back cover well until hearing a “tick” sound.

Pay attention when using the battery

Please do not use new ones with old batteries

Please do not use different types of batteries together (for example “manganese” and “Alkaline” ones.

Note there are chargeable and non-chargeable 2 kinds of batteries, please do not try the non-chargeable

ones for

recharging.

If remote controller is not used for long time, please take out of the batteries.

Please do not throw batteries into the fire in case of explosion of its vented liquid.

Please send old batteries to special recycling bureau in case of polluting environment

Pay attention when using the remote controller

Please do not drop remote controller

Avoid remote controller to suffer from physical crush

Please place remote controller under cool. dry environment as humidity will easily cause failure

When power supply of the battery is not enough, please change it on time.

Accessories equipped with the display

Power cord (1.8M)

HDMI wire.

Touch wire (without OPS computer)

Remote controller

Touch pen

User's manual (with warranty card)

Certificate

Note:

We reserve the right to adjust the accessories because of different batches.

The effect chart is for reference, please refer to the actual product.

Installation

Display front view

Open power on

Place display in the suitable place and plug the power cord into AC alternating power( input voltage AC220V)

50/60hz

socket, the other part into display power socket, open “on/ off” switch, then the power indication

light becomes red,

display is in “standby” mode, if pressing on/ off button on the remote controller, or press

on/ off on bottom front

panel, the indication light will become blue and display image will appear after waiting

for a few seconds.

Shut off the power

Press power button and make the display in “standby” status or shut off the off switch, then take out the power

plug

from socket.

Note:

If the display is not in use for a long time, please shut off the display's power and take out its plug from socket.

Back Cover Display Port

Note:

Please take care when connecting to other equipment

Please read the user's manual of outer equipment when connecting the external equipment

Please cut off the power between the display and equipment to ensure the correct connection between input and

output terminal.

Functional Part

Front Set Display Port

(standard default)

Note:

OPS optional, the graphic is for reference only, actual terminal port bases on product

Ops Computer Port

Remote Controller Operation Instruction

(1)

Power Button

Press this button to enter standby mode or switch

on and off in standby mode

(2)

Mute Button

To set the silent mode or restore the sound in silent

mode

(3)

Source

To go to different input sources, such AV

(4)

Home

Press this button to go to Android homepage.

(5)

Navigation Keys

Up, down, left, right and confirmation keys with OSD

(6)

Press this button to enter menu.

(7)

Number Button

0-9 number button for channel

selection

(8) Channel + Channel -

To increase or decrease in

the number

of channels

(9) Sound + Sound -

To increase or decrease in

volume

(10) Back

Press this button to return

to the

previous interface (on

Android only)

(11) Multimedia Hot Key

Press this button to switch

directly to

the multimedia

signal

(12) HDMI Hot Key

To switch to HDMI1 with

one button

(13) VGA Hot Key

To switch to VGA1 with

one button

(14) (Invalid)

(15) Sound Mode

To select the desired sound

mode

(16) Image Mode

To select the desired image

mode

(17) Proportion

Image display switches

between 16:9

and 4:3

(18) Play/Pausebutton

Used to play/pause the

current file

(19) Stop button

To stop current play

(20) Previous / Next

PPT page turning function

(for some

models)

(21) Previous/Next

To go to the previous or

next head

(22) Fast forward / rewind

To fast forward and

rewind

(23) Built-in computer

shortcuts

One-button switch to

the built-in

computer

OPS input interface

(24) (Invalid)

(25) Sleep

To set sleep time

(26) (Invalid)

(27) (Invalid)

1.1 Conference system launcher

After starting display, enter into system main interface

1.2 Side column

1.2.1 Function introduction

Side panel is divided into left & right-side column, click floating left/ right graphic on the

screen, then you can

see the side column, functional button is: return. Main page. Task. Annotation.

Message source. notify center.

System Instruction

Return

Click

return or exit from existing program

Main page

Click

go into system main interface。

Task

Click

enter into task management interface, you can choose opening or closing the application.

（1）Under many tasks, touch “task” area, up/ down floating to see the task column

（2）Touch “task”graphic to slide left/ right side until the task column show up as below
