MINI WASHING MACHINE
Cat. No.: 23450
OPERATING INSTRUCTION MANUAL
Unpacking:
This mini washing machine has been shipped completely assembled and with
the instruction manual. After removing it from the carton, inspect it and make
sure below parts are not damaged during the delivery.
Parts Diagram
Preparation for Washing:
1. In order to keep the ventilation free, please remove the base packing foam
from under the washing machine.
2. Take off the Water Inlet Knob of the washer, then connect the Water Inlet
Tube between the inlet hole of the washer (located under the Water Inlet
Knob) and the water tap.
3. Take out the spin basket from inside the tub by turning the basket
clockwise.
4. Please attach the drain hose by the designated suspension (nozzle up as
shown in above pic.) to prevent water leaking out.
Washing:
1. Insert the plug to the power supply mains, which matches the appliance
electric rating printed on the rating label.
2. Put the clothes into the tub. Please do not overload as it is only a mini
machine.
3. 3 water levels (low, middle, high) indicated on the tub, select your water
level according to the amount of clothes.
4. Turn on the water tap and make sure the water running into the washer
smoothly via inlet tube. And turn off the water tap when the water is up
to your required level.
5. Add washing powder suitable for the textile fabrics and according to the
amount of clothes being washed.
6. Turn the wash timer between 0 to 10 minutes for washing. This will start
the washing cycle.After the washing cycle is completed, drain the water
by unhooking the drain hose from the side of the machine and laying it
over a drain or bath. The water will automatically drain away.
Spinning:
1. After the water has completely drained away, take out the wet clothes from
the tub, put the spin basket into tub, make sure basket’s clip fastened to the
cluster’s clip closely by lowering the basket slowly into the tub central
position and turning the basket anti-clockwise to clip it in place.
2. Put the clothes into the basket uniformly, and not lopsidedly so that it can
spin evenly.
3. Press the clothes down firmly and place the Pressed Clothing Cover over
them
4. Turn the spin timer between 0 to 3 minutes for spinning. This will start
spinning cycle.
Technical Data:
Model:
XPB30-40 (Cat. No.:
23450)
Rated spin power:
80W
Rated Voltage:
220V
Wash Capacity:
2.5kg
Rated
Frequency:
50Hz
Spin Capacity:
2.2kg
Rated Wash
Power:
160W
Water Protection:
IPX4
Safe guards
1. Do not install the washing machine in a bathroom or other humid
places.
2. Do not install the washing machine on an inclined or bumpy place and
keep away from the wall by at least 2 cm.
3. Never put your hands into the wash/spin tub while the washing is in
operation, to prevent injuries.
4. Keep the washing machine away from places where it is exposed to the
sun.
5. Do not pour water on the control panel where the timer and switches
are located. It may cause malfunction or short circuit.
6. Do not allow children to play with the washing machine to prevent
injury.
7. Never insert water hotter than 50 °C into the washing machine. It may
change the shape of the plastic parts in the washing machine and
cause malfunction.
8. Do not put carpet or soft object below the washing machine to avoid
blocking the
air ventilation.
9. Do neither put flammable/inflamed items near/on top of the washing
machine nor sharp/heavy objects.
Caution:
1. The machine should connect to single phase electric socket with
reliable earth connection.
2. Please use the socket within rated electric current, which is
higher than 5 Amp alone.
3. Please do not cut, twist, damage the power cord or hang heavy
items on it, to prevent power cut and avoid short-circuit.
4. Please do not pull out the plug from power supply socket when
your hands are wet.
5. This appliance is not intended for use by persons with reduced
physical fitness, sensory or mental capabilities, or lack of
experience and knowledge. Unless they have been under
supervision to ensure that they do not incorrectly operate the
appliance.
6. If the power cord is damaged, it must be replaced by the
manufacture, its service agent or similar qualified persons.
Disposal:
The packaging material is reusable. Dispose of the packaging in an
environmentally
friendly way by putting it in the appropriate recyclable waste collection
containers.
Dispose of the product and the batteries in view of the environment
if you want to separate. The device and the batteries must not be
thrown in with domestic waste. Take them to a recycling center for
used electrical and electronic devices. For more information you
can consult your local government. Remove batteries first.
Eurotops Versand GmbH
Elisabeth-Selbert-Straße 3
40764 Langenfeld, Germany
If technical support is needed, please call ...
in Austria 01 . 230 60 43 12 or info@eurotops.at
in Switzerland 044 . 28 36 125 or info@eurotops.ch
in France 0892 . 700 470** or info@eurotops.fr
* 14 Cents/minute via German landline, max. 42 cents/minute via mobile phone network
**34 Cents/minute via French landline
A possible return of products should be addressed to the return address stated
on your invoice.
The manual only reflects the technical conditions available under printing. Any
changes in technology and equipment are reserved.
© 26.11.2013
