EverFocus ED335 Manuale tecnico

1/3” CCD Indoor 3-Axis Dual Voltage

True Day/Night IR Dome Camera

O eration Instructions

Model No. ED335

Please read this manual first for correct installation and o eration. This manual should be retained for future

reference. The information in this manual was current when ublished. The manufacturer reserves the right

to revise and im rove its roducts. All s ecifications are therefore subject to change without notice.

PRECAUTIONS

1. Do not install the camera near electric or magnetic fiel s.

Install the camera away from TV/radio transmitters, magnets, electric motors, transformers and audio

s eakers since the electromagnetic fields generated from these devices may distort the video image.

2. Never isassemble the camera beyon the recommen ations in this manual nor intro uce

materials other than those recommen e herein.

Im ro er disassembly or introduction of corrosive materials may result in equi ment failure or other

damage.

3. Try an avoi facing the camera towar the sun.

In some circumstances, direct sunlight may cause ermanent damage to the sensor and/or internal

circuits.

4. Keep the power cor away from water an other liqui s an never touch the power cor with

wet han s.

Touching a wet ower cord with the hands or touching the ower cord with wet hands may result in

electric shock.

5. Never install the camera in areas expose to water, oil or gas.

Water, oil or gas may result in equi ment failure, electric shock or, in extreme cases, fire.

6. Cleaning

Use a dam soft cloth to remove any dirt from the camera body. Use lens tissue or a cotton ti ed

a licator and ethanol to clean the camera lens. Please do not use com lex solvents, corrosive or

abrasive agents for cleaning.

7. Do not operate the camera beyon the specifie temperature, humi ity or power source ratings.

Use the camera at tem eratures within 0℃ ~ 40℃ (32℉~104℉) and humidity between 20~80%.

The in ut ower source is 12VDC/24VAC.

PRODUCT OVERVIEW

ED335 is a new design IR Dome camera from Everfocus. It incor orates breakthrough DSP technology to

rovide brilliant color images in well lit environments. Using a SONY Su er HAD CCD image sensor, the

ED335 also delivers excellent true day/night low light erformance, and equi ed with 34 long lifes an/high

illumination IR LEDs the ED335 is able to deliver bright, detailed monochrome images even in low light or no

light situations out to a range of over 66 feet.

In addition, because the ED335 is easily surface or flush mounted, it can be installed in almost any indoor

environment. The 3-axis gimbal enables installers to easily mount the camera on a wall or ceiling and then

using the built in tilt and dual axis 180° twist, adjust the viewing angle and varifocal lens to frame the desired

field of view. With this unique 3-axis ositioning system, installers can ca ture images from virtually any

angle, without com romising erformance.

FEATURES

Designed with advanced digital signal rocessing circuitry for high image quality

520 TV lines of su erior high resolution technology

True Day/night with ICR module

Equi ed with 34 IR LEDs for day and night environments

IR distance u to 66 feet (20M; de ending on surface reflectivity)

May be attached to wall or ceiling; flush or surface mounted

3-Axis adjustment for almost any viewing angle

Built-in vari-focal ty e, auto Iris lens

12VDC/24VAC Dual Voltage su ort

High Out ut IR LEDs, with a lifes an exceeding 20,000 hours

PACKAGE CONTENTS

ED335 camera, including dome/cover, camera unit and outer (surface mount) base as an assembly.

This user guide.

Accessory ack #1 containing:

4 long mounting screws

4 washers

4 lastic anchors

Hex key for cover screws

4 short screws to attach flush-mounting cli s

Rubber lug for side hole in outer base.

Mounting tem late

Power su ly igtail

Video test cable

Accessory ack #2 containing two flush mounting cli s

DIMENSIONS

SPECIFICATIONS

Pickup Device 1/3” SONY Su er HAD CCD

Vi eo Format NTSC or PAL

Scanning System NTSC: 525 TV lines, 60 fields/sec; PAL: 625 TV lines, 50 fields/sec.

Picture Element 768 x 494 (NTSC); 752 x 582 (PAL)

Horizontal Resolution 520 TV Lines

Sensitivity 0 Lux (IR LED on)

0.4 Lux/F=1.2 (AGC ON)

Day/Night Type True Day/night with ICR module

S/N Ratio Over 48 dB (AGC off)

Electronic Shutter 1/50 (1/60) ~ 1/100,000

Lens Type Vari-focal lens, DC Auto Iris

f=2.8~10mm/f=9~22mm

Iris Level Adjustable

Auto Gain Control ON

Back Light Comp. ON

Auto White Balance ON

Gamma Correction 0.45

Vi eo Output 1. BNC 1.0V - , 75 ohm

2. Additional testing video out ut 1.0V - , 75ohm

Sync. Mo e Internal Sync.

Power Source 12VDC/24VAC

Power Consumption 12VDC: 6W max.; 24VAC: 6.5W max.

Dimensions 141 mm (O.D.) x 128? mm (H)/ 5.6” (O.D.) x 5.1 “(H)

Weight 0.66 kg, 1.45 lbs

Operating Temperature 0°C~40°C ; 32°F~104°F (20%~80% Humidity)

IR Distance 20M/66 feet

IR Wavelength 850nm

IR LED Lifespan 20,000 hours

Certifications CE/FCC

MAJOR PARTS: NAMES AND FUNCTIONS

Front View

Side View

2. IR LEDs

4. Light sensor

1. Outer Base

6. Focus Adjust

8. Video Out ut

9. Power In ut

3. Lens

5. Cover

7. Zoom Adjust

Back View

1. Base

The camera unit sets in the dome base, when it is shi ed from the factory. This base is used

for surface mounting, and is discarded for flush mounting.

2. IR LEDs

3. Lens

The included vari-focal, DC iris lens allows manual adjustment of the field of view (zoom & focus). The

choices for focal length range are:

1) 2.8-10mm

2) 9-22mm

4. Light Sensor

Light sensor is used to detect the lighting level the environment. (The light sensor is “down”

when the internal camera module is ro erly ositioned).

5. Camera Cover

This cover will rotect the camera from dust and damage.

6. Focus Ring

To set the focus, and loosen the focus ring knob, and turn the ring toward <F> or <N> as

necessary, and re-tighten when the adjustment is com lete.

Video Test Out ut

Iris level adjust

7. Zoom Ring

To adjust the viewing angle, loosen the zoom ring knob. Turn the ring toward <W> to Zoom out

or <T> to Zoom in as necessary, and re-tighten when the adjustment is com lete.

8. Video Out ut

Please connect to the BNC connector of the cable from the DVR or monitor.

9. Power In ut

Please connect this connector to a 12VDC or 24VAC ower source.

3-AXIS GIMBAL BRACKET

The 3-axis gimbal enables installers to easily mount the camera on a wall or ceiling and then using the built

in tilt and dual axis 180° twist, to adjust the viewing angle to the desired direction. With this unique 3-axis

ositioning system, installers can ca ture images from virtually any angle, without com romising

erformance.

Loosen this screw manually to

rotate the camera 180°

Use a screw driver to loosen this

screw. Tilt the camera 180°

Hold the bracket at both sides of the

camera. Rotate the entire camera

180°

INSTALLATION

An ED335 camera may be mounted in two ways: surface mount and flush mount. Select the one that meets

your needs.

Installation - Surface Mount

1. Paste the drilling tem late on the ceiling or wall. Please refer to the drilling tem late below.

2. Use the a ro riate tool to drill the INNER holes, and a clearance hole for the ower and video wires.

Note: The minimum recommended material thickness is 1 cm.

3. Use the lastic anchors and ush them into the 4 small holes, to fix the outer ring into ceiling or wall.

4. Remove dome cover (4 ca tive hex head screws); remove inner base from outer base (4 Philli s head

screws – retain these for later re-assembly).

5. Pull the cables to be connected to ower and video cables into the outer base from the ceiling or wall.

Attach ower su ly igtail ada ter to ower wire if needed.

6. Take a long Philli s an head screw with a washer and tighten it into a lastic anchor. Re eat the same

ste until all the 4 screws are fixed to the wall.
