Everpure CES 2750 Series Manuale utente

B E N E F I T S

A P P L I C A T I O N / S I Z I N G

I N S T A L L A T I O N T I P S O P E R A T I O N T I P S

CES 2750 Series

Water Conditioner

Water Conditioning for Commercial and Light Industrial Applications

Available in Single Tank System with 1” Porting

MRS-20T System: EV9797-92

4MR-1 Cartridge: EV9273-69

Hardness removal of 34,000 to 101,000 grains at

flow rates up to 20 gallons per minute continuous

Single tank design for simplicity, economy

and space savings

Fully adjustable 5-cycle control delivers

controlled upflow backwash, downflow brining

and slow rinse, rapid rinse, timed brine refill and

downflow service

Advanced user-friendly controls incorporates

time-tested hydraulically balanced piston,

seal and spacer design to pilot service flow

and regeneration

Large capacity brine tank maximizes time

between refills

Fiberglass reinforced resin vessels with NSF

approved polyethylene liners eliminate worries

about corrosion

Meter initiated regeneration minimizes salt,

water, and electrical costs

Locate equipment on a smooth, level surface

Maintain an air-gap at the end of the drain line

Secure drain line directly over floor drain or

stand pipe

When connecting to a water heater, install a

check valve on the soft water piping to prevent

hot water back-up

When sweating/installing copper piping,

protect the control valve from excessive heat

Check local codes for additional equipment

that may be required, such as backflow

prevention devices (i.e., RPZ)

Check for softened water each time salt is

added, by using a soap or hardness test kit

Use a good quality grade of salt -Solar

or pellet are preferred

Check the salt level on a regular basis

Maintain at minimum salt depth of 6” to

ensure a proper regeneration

On iron bearing waters, use a salt that

contains an iron “fighting” additive, or use

a resin cleaner on a regular basis

Check the water level in the brine tank

If abnormally high - refer to IO guide for

troubleshooting information

Warewashing

Laundry - Linen & Uniform

Boiler Scale Control

Water Heater Scale Protection/Reduction

General Housekeeping

CES-2750M-34: EV9982-21

CES-2750M-51: EV9982-22

CES-2750M-68: EV9982-23

CES-2750M-101: EV9982-24

CES 2750 Series

Overall Dimensions (inches):

Inlet Connection:

1” MNPT

Service Flow Rate (GPM):

Rated Capacity (grains):

CES-2750M-34 34,000

CES-2750M-51 51,000

CES-2750M-68 68,000

CES-2750M-101 101,000

Pressure Requirements:

25-100 PSI (1.7 -6.9 bar) non-shock

Temperature:

40º F to 100º F

Electrical:

115 VAC/60 HZ/1 Phase

Shipping Weight:

CES-2750M-34 120 lbs.

CES-2750M-51 150 lbs.

CES-2750M-68 190 lbs.

CES-2750M-101 280 lbs.

Operating Weight:

CES-2750M-34 670 lbs.

CES-2750M-51 750 lbs.

CES-2750M-68 850 lbs.

CES-2750M-101 1410 lbs.

Everpure, LLC

1040 Muirfield Drive

Hanover Park, IL 60133

Ph: 630-307-3000 Fax: 630-307-3030

Everpure water softening systems are covered by a limited warranty

against defects in material and workmanship for the following periods:

◆Complete System - 1 year

◆Control Valve - 5 years

◆Mineral Tank(s) -

◆6-13” diameter - 10 years

◆14” diameter and larger - 5 years

See printed warranty for details. Everpure will provide a copy of the

warranty upon request.

Outlet Connection:

1” FNPT

The contaminants or other substances removed or

reduced by this water conditioning system are not

necessarily in your water. Do not use with water that is

microbiologically unsafe or of unknown quality

without adequate disinfection before or after the

system. Systems certified for cyst reduction may be used

with disinfected water that may contain filterable cysts.

Model

Number

Width Depth Height

(A) (B) (C)

CES-2750M-34

CES-2750M-51

CES-2750M-68

CES-2750M-101

34 23 65

35 23 71

37 23 69

45 28 82

Model

Number

Cont. @

15 PSI DP

Peak @

25 PSI DP

16 20

17 22

19 25

20 26

REN

NAT

WATER CONDITIONER

CES SERIES

CES-2750M-34

CES-2750M-51

CES-2750M-68

CES-2750M-101
