EVGA GeForce RTX 2080Ti Manuale utente

2-way SLI: Install your second GeForce®graphics card in the secondary PCIe x16 slot.

Connect the two cards together using a 2-way SLI bridge.

NVLinkTM technology is only supported by each GPU Speciﬁcation.

Install your ﬁrst GeForce®graphics card into the Primary PCIe x16 slot

(the Primary slot is the one closest to the CPU).

Attention: It is very important that you wait until the graphics card has cooled down before taking the card out of the system.

Turn o your computer, disconnect the power cord and remove any existing graphics card(s).

Remove the slot covers that correspond to the PCIe slots you are installing the GeForce®graphics card in

(if there was no existing graphics card).

Note : All of the graphics cards in an SLI® conﬁguration must be identical.

Install the GeForce® graphics card, as shown below. If this card is going into an SLI® conﬁguration, follow the

directions for the number of cards you will be installing.

Hardware Installation

Option 2Option 1 Option 3

Motherboard:

▪ PCIe, PCIe 2.0 or PCIe 3.0-compliant motherboard with one dual-width graphics slot.

For an SLI® conﬁguration, you need an NVIDIA NVLinkTM (NVIDIA SLI®) motherboard.

For power supply recommendations for SLI® conﬁgurations,

visit www.geforce.com/sli and check the Certiﬁed Products section.

Operating System:

▪Microsoft Windows®10 64-bit(April 2018 Update or later) ▪Windows® 7 64-bit, Linux64-bit

System Power Supply:

GeForce®RTX 2080Ti / 2080 / 2070 : 650W power supply with one of the following PCle power connectors.

GeForce® RTX 2060 : 500W power supply with one of the following PCIe power connectors.

GeForce® GTX 1660Ti : 450W power supply with one of the following PCIe power connectors.

With the hardware installed, it is now time to install the

graphics driver.

1. Power up your computer.

2. Download the driver ﬁle from www.evga.com/drivers.

The setup program will take over and walk you through the

driver installation process.

3. You may need to reboot your PC once the driver

installation is complete.

Connecting to the Display

Driver Installation

Minimum System Requirements

1. Connect the display(s) to the graphics card.

2. Reconnect your power cord to the PC.

The terms HDMI and HDMI High-Deﬁnition Multimedia Interface,

and the HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

Included Equipment

The following equipment is included in the EVGA GeForce®graphics card box.

▪Installation Guide ▪ EVGA Accessory Pack* *On select models

Power Connectors

NVLink

Connector(s)

5. Reinstall the covers on your computer and reconnect any previously removed display cables.

2-Way 3 Slot SLI 2-Way 4 Slot SLI

4. Connect system power to the GeForce®graphics card.

GeForce®graphics cards require PCIe power plugs from the system power supply.

Ensure that all pins are populated by using the proper 6 or 8 pin PCle connector.

E009-00-000260

Option 1 Option 2 Option 3 Option 4 Option 5 Option 6 Option 7

DVI-D

HDMI

DVI-D

HDMI

USB

Type-CTM USB

Type-CTM

Display

Port Display

Port

DVI-D

Display

Port

USB

Type-CTM

Display

Port

HDMI
