1) Place the installation template that is
provided in the package on the desired
position of installation.
2) Attach the waterproof silicon band
on the bottom plate of the device.
3) Drill three holes on the template and
insert anchor blocks into the holes.
Fasten the camera with screws.
4) Make sure the cables are properly
connected by checking the LEDs. For
the position of the LEDs, please refer to
the Step1.
5) Adjust the lens position by referring to
the Step 3.
6) Put the dome cover on the main
body of the camera. Make sure the
main body and the cover fit each other
into place.
7) Fasten the cover with screws.
When assembling the main body of the camera and its dome cover, make sure they
fit each other into place.
The camera may fall off the ceiling even after the proper installation and mounting.
To prevent any accident, make sure the ceiling is firm and stable enough to support
the camera. If any reinforcement is needed, consult with your safety personnel and
proceed with the installation.
