INSTALLATION &
CONFIGURATION
MANUAL
U4D100
4K ULTRA HD 4 WIRE TO 1080P DOWN
CONVERTER
INSTALLATION AND CONFIGURATION MANUAL
U4D100
Copyright
EVS Broadcast Equipment S.A. – Copyright © 2001 – 2021. All rights reserved.
Disclaimer
The information in this manual is furnished for informational use only and subject to change
without notice. While every effort has been made to ensure that the information contained in
this user manual is accurate, up-to-date and reliable, EVS Broadcast Equipment cannot be held
responsible for inaccuracies or errors that may appear in this publication.
Improvement Requests
Your comments will help us improve the quality of the user documentation. Do not hesitate to
send improvement requests, or report any error or inaccuracy on this user manual by e-mail to
Regional Contacts
The address and phone number of the EVS headquarters are usually mentioned in the Help >
About menu in the user interface.
You will find the full list of addresses and phone numbers of local offices either at the end of this
user manual (for manuals on hardware products) or on the EVS website on the following page:
http://www.evs.com/contacts.
User Manuals on EVS Website
The latest version of Media Infrastructure manuals are available at: https://mi-sftp.evs.com/
The user manuals for other EVS products can be found at the EVS download center, on the
following webpage: https://www.evs.com/en/download-area.
EVS Broadcast E
q
ui
p
ment SA
1
WARNING: TO REDUCE THE RISK OF FIRE OR
ELECTRICAL SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE
●ALWAYS disconnect your entire system from the AC mains before cleaning any component. The product
frame (SFR18 or SFR04) must be terminated with three-conductor AC mains power cord that includes an
earth ground connection. To prevent shock hazard, all three connections must always be used.
●NEVER use flammable or combustible chemicals for cleaning components.
●NEVER operate this product if any cover is removed.
●NEVER wet the inside of this product with any liquid.
●NEVER pour or spill liquids directly onto this unit.
●NEVER block airflow through ventilation slots.
●NEVER bypass any fuse.
●NEVER replace any fuse with a value or type other than those specified.
●NEVER attempt to repair this product. If a problem occurs, contact your local EVS distributor.
●NEVER expose this product to extremely high or low temperatures.
●NEVER operate this product in an explosive atmosphere.
Warranty: EVS warrants their products according to the warranty policy as described in the general terms.
That means that EVS Broadcast Equipment SA can only warrant the products as long as the serial numbers
are not removed.
Copyright © 2001 – 2021 EVS Broadcast Equipment SA
Date created: 24-06-2014
Date last revised: 24-06-2014
EVS, the EVS logo and Synapse are trademarks of EVS Broadcast Equipment SA
This product complies with the requirements of the product family standards for audio, video, audio-visual
entertainment lighting control apparatus for professional use as mentioned below.
EN60950
EN55103-1: 1996
EN55103-2: 1996
Safety
Emission
Immunity
EVS Broadcast Equipment
U4D100
Tested To Comply
With FCC Standards
FOR HOME OR OFFICE USE
This device complies with part 15 of the FCC Rules
Operation is subject to the following two conditions:
(1) This device may cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
INSTALLATION AND CONFIGURATION MANUAL
U4D100
2
Table of Contents
Introduction to Synapse 4
An Introduction to Synapse 4
Local Control Panel 4
Remote Control Capabilities 4
Unpacking and Placement 5
Unpacking 5
Placing the card 5
A Quick Start 6
When Powering-up 6
Changing settings and parameters 6
Front Panel Control 6
Example of changing parameters using front panel control 7
EVS Cortex Software 8
Menu Structure Example 8
The U4D100 Card 9
Introduction 9
Features 9
Applications 9
Block schematic 10
Settings Menu 11
Introduction 11
IO_Prst_Act 11
IO_Prst_Edit 11
#Out-Frmt 11
#Out_Map 11
#Mode 11
#H-Sharpness 12
#H_delay 12
#V_delay 12
#F_delay 12
#OSD-Style 12
Lock-Mode 12
Ref-Type 12
Delay-Status 13
IP_Conf0 13
mIP0 13
mNM0 13
mGW0 13
NetwPrefix0 13
Status Menu 14
Introduction 14
sInp1 14
IO-Delay 14
Ref 14
IP_Addr0 14
Mac0 14
IP0 14
NM0 14
GW0 14
Events Menu 15
Introduction 15
What is the Goal of an event? 15
Events 15
Announcements 15
Ref-Status 15
What information is available in an event? 15
The Message String 15
The Tag 15
Defining Tags 16
The Priority 16
EVS Broadcast E
q
ui
p
ment SA
3
The Address 16
LED Indication 17
Error LED 17
Input_1 LED 17
Reference LED 17
Connection LED 17
Error LED 17
Block Schematic 18
Connector Panels 19
INSTALLATION AND CONFIGURATION MANUAL
U4D100
4
1 Introduction to Synapse
An Introduction to
Synapse
Synapse is a modular system designed for the broadcast industry.
High density, intuitive operation and high quality processing are key
features of this system. Synapse offers a full range of converters and
processing modules. Please visit the EVS Broadcast Equipment SA
Website at http://www.evs.com to obtain the latest information on
our new products and updates.
Local Control
Panel
The local control panel gives access to all adjustable parameters and
provides status information for any of the cards in the Synapse
frame, including the Synapse rack controller. The local control panel
is also used to back-up and restore card settings. Please refer to the
RRC18, RRC10, RRC04, RRS18 and RRS04 manuals for a detailed
description of the local control panel, the way to set-up remote
control over IP and for frame related settin
g
s and status information.
Remote Control
Capabilities
The remote control options are explained in the rack controller
manual. The method of connection to a computer using Ethernet is
also described in the ERC/ERS/RRC/RRS manual.
! CHECK-OUT: “EVS CORTEX” SOFTWARE WILL
INCREASE SYSTEM FLEXIBILITY OF ONE OR MORE
SYNAPSE FRAMES
Although not required to use Cortex with a Synapse frame, you are
strongly advised to use a remote personal computer or laptop PC
with EVS Cortex installed, as this increases the ease of use and
understandin
g
of the modules.
EVS Broadcast E
q
ui
p
ment SA
5
2 Unpacking and Placement
Unpacking The EVS Synapse card must be unpacked in an anti-static
environment. Care must be taken NOT to touch components on the
card – always handle the card carefully by the edges. The card must
be stored and shipped in anti-static packaging. Ensuring that these
precautions are followed will prevent premature failure from
components mounted on the board.
Placing the card The Synapse card can be placed vertically in an SFR18 frame or
horizontally in an SFR04 and SFR08 frame. Locate the two guide
slots to be used, slide in the mounted circuit board, and push it firmly
to locate the connectors.
Correct insertion of card is essential as a card that is not located
properl
y
ma
y
show valid indicators, but does not function correctl
y
.
NOTE: On power up all LED’s will light for a few seconds, this is
the time it takes to initialise the card.
INSTALLATION AND CONFIGURATION MANUAL
U4D100
6
3 A Quick Start
When Powering-
up
On powering up the Synapse frame, the card set will use basic data
and default initialisation settings. All LED’s will light during this
process. After initialisation, several LED’s will remain lit – the exact
number and configuration is dependent upon the number of inputs
connected and the status of the inputs.
Changing settings
and parameters
The front panel controls or the EVS Cortex can be used to change
settings. An overview of the settings can be found in chapter 5, 6 and
7 of this manual.
Front Panel
Control
Front Panel Display and Cursor
Settings are displayed and changed as follows;
Use the cursor ‘arrows’ on the front panel to select the menu and
parameter to be displayed and/or changed.
Press ►To
g
o forward throu
g
h the menu structure.
Press ◄To
g
o back throu
g
h the menu structure.
Press ▲To move up within a menu or increase the value of
a parameter.
Press ▼To move down through a menu or decrease the
value of a parameter.
NOTE: Whilst editing a setting, pressing ►twice will reset the
value to its default.
[No Alarms]
EVS Broadcast E
q
ui
p
ment SA
7
Example of
changing
parameters using
front panel control
With the display as shown below
Pressing the ►selects the SFS10 in frame slot 01.
The display changes to indicate that the SFS10 has been selected. In
this example the Settings menu item is indicated.
Pressing the ►selects the menu item shown, in this example
Settings.
(Pressing ▲or ▼will change to a different menu eg Status,
Events).
The display changes to indicate that the SFS10 Settings menu
item SDI-Format has been selected and shows that it current
setting is Auto.
Pressing the ►selects the settings item shown, in this example
SDI-Format.
(Pressing ▲or ▼will change to a different setting, eg Mode, H-
Delay).
The display changes to indicate that the SFS10 Edit Setting
menu item SDI-Format has been selected.
To edit the setting of the menu item press ▲or ▼.
All menu items can be monitored and/or changed in this way.
Chan
g
in
g
a settin
g
has an immediate effect.
RRC18 [Select Card]
>S01=SFS10
SFS10 [Select Menu]
>Settings
SFS10 [Settings]
>SDI-Format=Auto
SFS10 Edit Setting]
SDI-Format>Auto
INSTALLATION AND CONFIGURATION MANUAL
U4D100
8
EVS Cortex
Software
EVS Cortex can be used to change the settings of Synapse modules
from a PC, either locally or remotely. The software enables
communication based on TCP/IP between the Setup PC and Synapse
frames/modules.
Each Synapse frame is addressed through its rack controller’s unique
IP address, giving access to each module, its menus and adjustment
items. EVS Cortex has access to data contained within the Synapse
module and displays it on a GUI. The software has an intuitive
structure following that of the module that it is controlling.
For operation of EVS Cortex, please refer to the Cortex help files.
Menu Structure
Example
Slot Module Item Paramete
r
Settin
g
▲
▲
S02 Identit
y
▲▲
S01 SFS10
►Set-
tings
►
Standard_dig ►Auto
▼▼▼▼
S00 RRC18 Status Mode 625
▼▼▼
Events Ref-Input 525
▼
H-Delay
▼
▼
NOTE: Further information about Front Panel Control and Synapse
Cortex can be obtained from the RRC and RRS operational manuals
and the Cortex help files.
