Ewbank SURGEPLUS Manuale utente
INSTRUCTION MANUAL
SURGEPLUS 2-in-1 Brushless DC Motor Cordless Stick
Vacuum Cleaner - Silver/Red
EW3032
Ewbank has a British heritage to be proud of. It’s a household favourite and much loved brand that has been providing innovative cleaning solutions for over 135 years.
2
CONTENTS
Safety Instructions.............................................................................................3-6
Appliance Overview ........................................................................................7-8
Product Assembly...........................................................................................9-10
Operating Instructions........................................................................................11
Damage Prevention ...........................................................................................12
Using Your Vacuum Cleaner ...............................................................................13
Cleaning & Maintenance ..............................................................................14-15
Trouble Shooting...............................................................................................16
Fuse Replacement..............................................................................................17
Disposal of the Appliance ..................................................................................17
Warranty Terms & Conditions .............................................................................18
3
Ewbank, 38 Bluestem Road, Ipswich, Suffolk, IP3 9RR Tel. 01473 271 272
SAFETY INSTRUCTIONS
PLEASE READ ALL THE INSTRUCTIONS BEFORE
USE AND WHEN USING THE APPLIANCE, THE
FOLLOWING PRECAUTIONS MUST BE TAKEN:
WARNING! TO REDUCE THE RISK OF FIRE,
ELECTRIC SHOCK, OR INJURY:
1. Do not leave the vacuum cleaner plugged in when not in
use. Unplug from the socket before servicing.
2. To reduce the risk of electric shock, do not use outdoors
or on wet surfaces.
3. Only use as described in this manual, including
attachments. Attachments used should only be that of the
manufacturers.
4. Do not use when the cord or plug are damaged. If
the vacuum cleaner is not working as it should be or
has been dropped, damaged, left outdoors, or fallen
into water, the vacuum cleaner must be serviced by an
engineer.
5. Do not pull or carry by the cord, use the cord as a
handle, trap the cord, or pull the cord around sharp
edges and corners. Do not run the vacuum cleaner over
the cord and keep the cord away from heated surfaces.
6. Do not unplug the vacuum cleaner by pulling on the
cord. To unplug, grasp the plug.
7. Do not handle the plug or the vacuum cleaner with wet
hands.
8. Do not actively put any objects into any of the vacuum
cleaners openings. Do not use with any of the opening
blocked. Keep free of dust, lint, hair and anything that
may reduce airflow.
9. Keep hair, loose clothing, fingers and all parts of the
body away from any openings and/or moving parts.
4
10. Turn all controls off before unplugging.
11. Take extra care when cleaning the stairs.
12. Do not use to pick up flammable or combustible liquids
such as gasoline. Do not use in areas where this may be
present.
13. Hold the plug when rewinding the cord. If this is not
done, the plug may whip.
14. Unplug before connecting the hose.
15. Do not pick anything up that is burning or smoking such
as cigarettes, matches or hot ashes.
16. Do not use without filter in place.
17. If the cord is damaged, it must be replaced by the
manufacturer, or a service engineer.
18. This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge. Only when they have been given supervision
or instruction to use the appliance by a person
responsible for their safety, can they then use it.
19. Children should be supervised to ensure that they do not
play with the appliance.
20. The mains power supply should comply with the
information on the appliance’s rating plate.
21. Do not vacuum water or other liquids.
22. Do not use or store the vacuum cleaner in humid
environments.
23. Do not use with an extension cable.
24. Never dismantle any part of the appliance.
25. When cleaning the stairs, ensure the vacuum cleaner is
located below the user. Keep on the floor when possible.
26. When retaining the packaging, store out of the reach of
children.
27. Do not store outdoors. Store out of the way with the
power cord neatly wrapped up, to prevent accidents.
SAFETY INSTRUCTIONS
5
Ewbank, 38 Bluestem Road, Ipswich, Suffolk, IP3 9RR Tel. 01473 271 272
SAFETY INSTRUCTIONS
28. When vacuum cleaning static electricity may be created.
To prevent shocks, do not access any parts with your
hand until the area is clear.
29. Check the recommended cleaning instructions of your
flooring before vacuum cleaning.
30. Do not use the vacuum cleaner to vacuum powders such
as flour and cement. It can damage, block or break the
motor.
31. Do not use or store the vacuum cleaner in excessively
high or low temperatures, outside of 0-40°C. Avoid
the vacuum cleaner being in direct sunshine for a long
period.
32. If the vacuum cleaner is broken do not disassemble it.
This must be done by a qualified technician.
33. Please fully charge the battery before the first use and
when the appliance has not been used for a long time.
To avoid the battery losing performance, please use the
vacuum cleaner at least once every three months.
34. When the vacuum cleaner is fully charged, please
unplug the charger. Do not pull on the power cord
directly to unplug.
35. If the performance of the battery drops, it is advised that
a new battery is purchased.
36. The battery should be disposed of correctly and not
disposed with general waste. Make sure to remove the
battery from the vacuum cleaner before disposing of it,
37. The battery is designed for this vacuum cleaner only.
Only use the charger supplied. Do not disassemble the
battery unit as this can cause serious harm. Do not place
the battery unit close to high temperature objects or
fire. Do not attempt to access the battery unit with sharp
objects or break the battery.
6
38. Ensure that the battery is not accessible to children.
39. Switch off the appliance and remove the battery before
connecting or disconnecting the motorised brush bar.
READ AND SAVE THESE INSTRUCTIONS
This vacuum cleaner is intended for household use only.
Read the safety and operating instructions through carefully
before using the vacuum cleaner. This is the only way to
ensure safe and reliable use of the device. If the appliance is
sold or passed on, ensure it is equipped with this instruction
manual. You will also need these operating instructions
for ordering spare parts and accessories. Please keep this
booklet in a safe place.
SAFETY INSTRUCTIONS
7
Ewbank, 38 Bluestem Road, Ipswich, Suffolk, IP3 9RR Tel. 01473 271 272
APPLIANCE OVERVIEW
ON/OFF Switch
Dual Power Setting Button
Battery Indicator
Motorised Tube Release Button
Motorised Tube
Floor Head Release Button
Motorised Floor Head
Dust Container Release Button
Dust Container
Dust Release Button
Motor Unit
Battery Release Button
Wall Mount
Charger
2-in-1 Crevice Tool
Turbo Brush
8
ACCESSORIES
This vacuum cleaner comes with two attachments designed for differing applications.
The 2-in-1 crevice tool can be attached directly onto the body of the vacuum cleaner.
Floor Head This is suitable for cleaning large areas. The motorised
floor head is fitted with a removable brush so that
cleaning is smooth and simple.
The motorised floorhead is fitted with LED lights to help
identify dirt and debris in darker corners and under
furniture.
APPLIANCE OVERVIEW
Use to access material stuck in hard-to-get place. Use
without the bristles for soft surfaces, use with bristles
for hard surfaces
2-in-1 Crevice Tool
A motorised attachment which allows for a more intense
vacuum. Use when vacuuming hair and other stubborn material.
Turbo Brush
Locate a free space on a wall which is close to a plug
socket. Ensure that there sufficient room for the whole
vacuum cleaner to be mounted.
Drill two holes into the wall and insert the appropriate
wall plugs. Then, using the screws provided, securely
fix the wall mount to the wall.
Wall Mount
9
Ewbank, 38 Bluestem Road, Ipswich, Suffolk, IP3 9RR Tel. 01473 271 272
Before assembling and disassembling accessories, always ensure that
the vacuum cleaner has been unplugged from the mains socket.
ASSEMBLING THE DUST CONTAINER
Insert the main HEPA filter into the inner chamber by aligning the locking grooves
with the slots. Twist to secure.
Then insert the inner chamber into the dust container by aligning the locking grooves
with the dust containers slots.
ATTACHING THE DUST CONTAINER TO THE BODY
To attach the assembled dust container to the vacuum cleaners body align the dust
containers slot with the locking groove on the underside of the body.
Click the dust container into place.
PRODUCT ASSEMBLY
ATTACHING THE MOTORISED TUBE/FLOOR HEAD
Insert the motorised tube in the air intake opening. Push the motorised tube in until it
locks in place.
Attach the motorised floor head to the telescopic tube. Push until it locks into place.
To disassemble, press the tube release button and pull out the tube.
10
ATTACHING THE 2-IN-1 CREVICE TOOL
Simply slot the attachment directly into the
body of the vacuum cleaner.
PRODUCT ASSEMBLY
