Speciﬁcations — XPA 1002, XPA 2001 (XTRA) Series

Extron XPA 1002, XPA 2001-70V, HPA 2001-100V Half-Rack Audio Power Ampliers • Specications

Audio

Voltage gain

XPA 1002�� 16x (24 dB)

XPA 2001-70V�� 57x (35 dB)

XPA 2000-100V�� 81x (38 dB)

Stereo channel separation�� >75 dB @ 1 kHz

CMRR�� 75 dB @ 1 kHz (typical)

Audio input

Number/signal type�� 1 stereo or 2 mono, balanced/unbalanced

Connectors �� (1) 3�5 mm captive screw connector, 5 pole

Impedance�� >10k ohms unbalanced/balanced, DC coupled

Nominal level �� +4 dBu (1�23 Vrms), balanced

Maximum level�� +20 dBu (7�75 Vrms), balanced

Input sensitivity

XPA 1002�� +4 dBu (1�23 Vrms)

XPA 2001-70V, XPA-2001-100V

+4 dBu (1�23 Vrms) if driven by one input

-2 dBu (0�615 Vrms) if both inputs are summed

N 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV ≈2 dBu

Audio output

Number/signal type

XPA 1002�� 1 stereo, 4- or 8-ohm direct

XPA 2001-70V�� 1 mono, 70 V line

XPA 2001-100V�� 1 mono, 100 V line

Connectors

XPA 1002�� (1) 5 mm screw lock captive screw connector, 4 pole

XPA 2001-70V, XPA-2001-100V

(1) 5 mm screw lock captive screw connector, 2 pole

N These connectors accept wires of 22 AWG to 12 AWG.

Load impedance

XPA 1002�� 4 ohms minimum

XPA 2001-70V�� 25 ohms minimum

XPA 2001-100V�� 50 ohms minimum

Ampliﬁer type �� Class D

Output power

XPA 1002�� 60 watts rms per channel, 8 ohms, 1 kHz, <0�05% THD

100 watts rms per channel, 4 ohms, 1 kHz, <0�05% THD

XPA 2001-70V�� 200 watts rms, 70 V, 1 kHz, <0�1% THD

XPA 2001-100V�� 200 watts rms, 100 V, 1 kHz, <0�1% THD

Frequency response �� 20 Hz to 20 kHz, ±1 dB

THD + Noise

XPA 1002�� 0�05% @ 20 Hz-20 kHz, 8 ohms, at 3 dB below clipping

XPA 2001-70V, XPA-2001-100V

<0�1% @ 1 kHz at 3 dB below clipping

S/N

XPA 1002�� 105 dB, 20 Hz - 20 kHz, unweighted

XPA 2001-70V, XPA-2001-100V

100 dB, 20 Hz - 20 kHz, unweighted

Damping factor

XPA 1002�� >100 @ 8 ohms

Speciﬁcations — XPA 1002, XPA 2001 (XTRA) Series, cont’d

Extron XPA 1002, XPA 2001-70V, HPA 2001-100V Half-Rack Audio Power Ampliers • Specications

High pass ﬁlter

XPA 2001-70V, XPA-2001-100V

80 Hz, 12 dB per octave rolloff (switch selectable)

Control/remote — ampliﬁer

Control port�� (1) 3�5 mm captive screw connector, 5 pole

Pin conﬁgurations

DC volume control (analog)

Pin 1 = +10 VDC, 50 mA (max�), pin 2 = volume/mute (variable voltage),

pin 3 = GND

Volume control voltage range

0 V (mute) to 10 V (maximum volume)

Standby power control (contact closure)

Pin 4 = GND, pin 5 = standby

General

Power�� 100 VAC to 240 VAC, 50/60 Hz, internal

Typical�� 26 watts (1/8 power [pink noise] at 8 ohms)

Quiescent�� 10 watts

Standby�� <1 watt (triggered by contact closure or after 1 hour with no signal)

Temperature/humidity�� Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing

Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing

Cooling �� Convection, no vents, with internal heat sinks

Thermal dissipation

Standby�� <1 watt (3 BTU/hr)

Idle�� 10 watts (34 BTU/hr)

1/8 power (pink noise)�� 4 ohms (x2): 14 watts

8 ohms (x2): 14 watts (48 BTU/hr)

70 V (XPA 2001-70V): 14 watts (48 BTU/hr)

Protection �� Clip limiting, thermal, short circuit, DC output

Indication�� Limiter/Protect LED indicates the onset of clip limiting, thermal cycling,

short circuit, or DC output protection

Mounting

Rack mount�� Yes, with optional 1U, 9�5" deep rack shelf (RSU 129, #60-190-01;

RSB 129, #60-604-01)

Enclosure type �� Metal

Enclosure dimensions�� 1�7" H x 8�7" W x 9�5" D (1U high, half rack wide)

(4�3 cm H x 22�1 cm W x 24�1 cm D)

Product weight �� 2�5 lbs (1�1 kg)

Shipping weight �� 5 lbs (3 kg)

Vibration�� ISTA 1A in carton (International Safe Transit Association)

Regulatory compliance

Safety�� CE, CUL, UL

UL rated for use in plenum airspaces: meets UL 2043 for heat and smoke

release; meets UL 60065, IEC 60065, and BSEN 60065 for A/V equipment�

EMI/EMC �� CE, CISPR 22 Class B, C-tick, FCC Class B, ICES, VCCI Class B

Environmental�� Complies with the appropriate requirements of CEC, ENERGY STAR®

(ENERGY STAR®qualiﬁed ampliﬁer), EU code of conduct, RoHS, WEEE

MTBF�� 250,000 hours

Warranty�� 3 years parts and labor

N All nominal levels are at ±10%�

N Speciﬁcations are subject to change without notice.
