FAMOS 3 Line Manuale
DirectionsforUse
Famos3LineLabelGun
Reference:15.300.255
Contents
1. Generalinformation
2. Settingtheprint
3. Insertofthelabelroll
4. Removingtheinkroller
5. Insertinganewinkroller
2/4
1. Generalinformation
TheFamos3LineLabelGunisspeciallydesignedtobeusedwithFamos3LineDoubleLabelsfor
documentationandtraceabilitypurposesinCSSD.
ThisLabelGunworksveryefficientlyanditisveryeasytouseintermsofloading,carryingandprinting.
Belowarethestepsalsoshowninpicturesyoushouldfollowtomakeyourlabelgunreadyforuse.
2. Settingtheprint:
3. Insertofthelabelroll:
Pulladjustmentknobtothedesired
positionandturnknobtoselect
charactertobeprinted.Eachrollhasa
selectionforprintingblank.
IMPORTANT:Adjustmentknobmust
bepressedinbeforeoperatingto
avoiddamagetotheprinthead.
Pushthereleasebuttonandswingthe
coveropencompletely.Whenyou
hearaclick,don’tforcethecover
anymore.
3/4
Pleaserelease12labelsfromtheroll.
Placethelabelrollbetweenthesupply
hubs.Drapethesupplyacrossthe
labellerandcentreitoverthepeel
bar.
Closethecover.
Feedthelabelstripunderthelarge
rollerandintotheslotabovethe
arrows.
Holdthestripinplaceandsqueezethe
triggeruntilthelabelstripfeed
throughtherareexit.
4/4
4. Removingtheinkroller:
5. Insertinganewinkroller:
Openthecovercompletely.
Holdinkrolleroneachendandpush
thereleasebar.
Discardtheusedinkroller.
Openthelabellercoverandsetaside.
Holdthenewinkrolleroneachend
andsnapintoplace.
Closethecover.
