Fantom Drives Titanium Manuale utente

Thank you for choosing Fantom Drives! Your Fantom Drives

disk drive has been built to the highest standard of quality and

workmanship and, when used according to the instructions in

this guide, will provide years of trouble-free operation. We at

Fantom Drives take great pride in bringing personal satisfac-

tion to each of our customers.

Your drive is compatible with all FireWire or USB-capable

Apple Macintosh computers running MacOS 9.1 (or greater),

MacOS 10.1 and Jaguar (or greater) and PC-Compatible

computers running Windows 98SE, Millennium Edition,

Windows 2000, or Windows XP.

Revision A

YOUR FANTOM DRIVES

OWNERS MANUAL

CD RECORDERS

•

DVD-RAM

•

DVD-R/RW

•

HARD DRIVES

•

RAID ARRAYS

•

USB 2.0

•

FIREWIRE

•

SCSI

•

FIBRE CHANNEL

Table of Contents

Table of Contents................................................................ 2

Package Contents............................................................... 3

Getting to know your Fantom Drive....................................... 4

Hardware Installation

Internal Models ..................................................... 5

External FireWire Models ....................................... 6

External USB 2.0 Models ....................................... 6

Product Specication- Hard Disk Drives................................. 6

Product Installation

Hard Disk Drives- Apple Macintosh Systems .............. 7

Hard Disk Drives- Microsoft Windows Systems .......... 8

Optical Disk Drives- Microsoft Windows Systems....... 10

Optical Disk Drives- Apple Macintosh Systems.......... 11

Product Specication- Optical Disk Drives.............................. 11

Optical disk drives Operation.............................................. 12

Daily Use Tips.................................................................... 13

Troubleshooting Frequently Asked Questions ......................... 14

FCC Compliance Statement ................................................. 16

Package Contents

Fantom Drives External Disk Drives contain:

Fantom Drives External Optical Drives contain:

Fantom Drives Internal Optical Disk Drives contain:

1 External Hard Disk Drive

1 Disk Drive stand (Titanium Models)

1 Power supply and cord

1 FireWire cable (FireWire Models)

1 USB 2.0 cable (USB 2.0 Models)

1 Hard Disk Speedtools software CD

1 Users Manual

1 External Optical Disk Drive

1 Power supply and cord

1 FireWire cable (FireWire Models)

1 USB 2.0 cable (USB 2.0 Models)

1 Users Manual

DVD-RW MODELS

1 DVD Video Suite CD

1 Mac CD Burning Software CD

CD MODELS

1 PC CD Burning Software CD

1 Mac CD Burning Software CD

DVD-RAM MODELS

1 DVD-RAM Driver CD

1 Mac driver software CD

DVD-ROM MODELS

1 PC DVD Playback Software CD

1 Internal Optical Disk Drive

1 IDE Ribbon Cable

1 Audio cable

1 Mounting Screw pack

1 Users Manual

1 Registration Card

DVD MODELS

1 DVD Video Suite CD

1 Mac CD Burning Software CD

CD MODELS

1 PC CD Burning Software CD

1 Mac CD Burning Software CD

Getting to know your Fantom Drive

Microsoft Windows systems: Intel Pentium II-450MHz or compatible, running Windows

98SE or greater, Windows ME, Windows 2000, Windows XP, or Windows 2003.

MacOS systems: PCI PowerMac or newer, running MacOS 8.6 or greater, or MacOS

10.1.5 or greater. If your operating system is earlier than MacOS 9.0.4, you may need to

update your Apple FireWire extensions. Double click the “Download FireWire Drivers” icon

on your installation CD to link to Apple’s web site, or visit http://www.apple.com to obtain

the latest drivers.

Minimum System requirements

Product Details

Fantom Hard Disk Drives: Fantom Optical Drives:

Power Switch

Power Adapter Connector

USB 2.0 Port (USB 2.0 Model)

FireWire Ports (FireWire Models)

USB 2.0 Port (USB 2.0 Model)

Power Adapter Connector

Analog Audio jacks

Cooling Fan

Hardware Installation

Before beginning drive installation, disconnect power from your computer system. The fol-

lowing steps must be performed to properly install your drive:

1. Set Drive Jumper Settings

The mode select jumpers are 6 straight angle pins located on

the rear of the DVD-R/-RW Combo drive.. By placing a jumper

on the pins, you can select the ATA device operating Mode:

2. Mount Drive

Remove computer cover and faceplate if required. Refer to your computer system’s

manual for removal information. If the drive is replacing a CD-ROM, remove CD-ROM

presently installed in your system. Place the drive in any free half-height drive slot at the

front of your computer. (It can be mounted horizontally or vertically.) Carefully start slid-

ing the drive into the opening with the disc tray facing the front of the computer. Before

you push the drive all the way in complete steps 3-5.

3. Attach IDE BUS Cable

Your computer system should have a primary and secondary

IDE BUSes, with your Hard Drive most likely being the Master

on the primary BUS. Connect BUS cable as follows, assuring

that pin 1 of cable (side with red stripe) is connected to pin 1

(closest to the power connector) of the drive’s interface connec-

tor. Please remember that each BUS can only have one master

and one slave devices.

4. Attach Power Cable

Connect an internal computer power supply cable to the power

socket at the back of the drive. One side of the plug has bev-

eled edges, so the power connector ts only one way. Push plug

completely into the socket making sure the plug ts correctly

5. Attach audio cable

If you have a sound card and speakers, and would like to play

audio CDs on your computer, you will need to install a CD/

DVD audio cable. The sound cable connects to your sound

card at one end and the other end connects to the digital audio

connector at the left rear of the drive. Refer to the instructions

that came with your sound card for details on any sound-driver

software required

6. Completing the installation

After you have connected all the necessary cables, push the drive completely into the

computer’s drive slot. Mount drive per your computer’s instructions, and fasten using the

included screws. Replace computer cover and all outer screws.

Internal IDE Models

MA: Master, default position

SL: Slave conguration

CS: Cable Select conguration C

Hardware Installation

• Plug the included power cable into the power connector on your drive and plug the

other end into a grounded electrical outlet.

• Press the power switch to turn on your Fantom Drives storage device, then power-on

your computer.

• Connect one end of the included 6-pin IEEE-1394 peripheral cable to one of the

FireWire ports on the rear of your drive.

• Connect the other end to one of your computer’s FireWire ports, or to the FireWire

port on a device already connected to your computer.

FireWire

USB

•

Connect the power cable to your USB Hard Disk Drive and plug it into a grounded outlet.

•

Press the power switch to turn on your Fantom Drives FireWire/USB 2.0 Storage Device.

• Connect the square end of the included peripheral cable to the USB port on the rear

of your Fantom Drives USB Storage Device.

• Connect the rectangular end of the cable to a free USB port on your PC or USB hub.

Specications- Hard Disk Drives

Note: in order to reach USB 2.0 speeds, you must have a computer or

host adapter that has USB 2.0 support. Your Fantom Drives storage

device will autosense the highest available connection speed.

External Hard Disk Drive Models

Capacities............................................... 80,120, 160, 180, 200, 250GB

Buffer Size............................................... >2MB

Track to Track......:.................................... 0.8

Full Stroke................................................ 17

Data Transfer Rate..................................... 30-38MB/s

Sector Size............................................... 512 bytes

Latency..................................................... <4.17 ms

Seek time (average)................................... <8.5 ms

Internal Drive Interface............................... ATA 133

Cable Transfer Rate.................................... 400Mb/s (FireWire)

480Mb/s (USB 2.0)

Rotational Speed....................................... 7200RPM

Dimensions............................................... 5.3”x8.8”x1.5”

Weight..................................................... 2.4 lbs

Power Supply............................................ 110-240 Volts Auto Switching

IMPORTANT: if your drive is delivered under hot or cold conditions,

please allow the drive to reach room temperature before operating to

prevent damage.

MacOS 8.6-9.x

1. Insert the included Hard Disk Speedtools Installation CD into your

computer’s CD drive.

2. Double click the Hard Disk Speedtools installer Icon.

3.Check the Hard Disk Speedtools and the HDST Firewire support

or USB Support extensions in the installer as illustrated, and press the install button.

4a.(FireWire) Follow the on-screen instructions to nalize the installation. Please make

sure that you have no other Firewire disk

extensions enabled besides Apple’s Firewire

Enabler and Firewire Support.

4b.(USB) Follow the on-screen instructions to

nalize the installation. Please make sure

that you have no other USB disk extensions

enabled besides Apple’s USB Enabler and

USB Support.

5. Run Hard Disk Speedtools, select your drive

and press the “setup” button.

6. Your Fantom Drives Firewire storage device

is ready to use!

OS-X 10.1 and Jaguar

Launch the “Disk Utility” application

located under Applications/Utilities

folder. Highlight your new drive and select

the “Erase” tab. Select the desired le system

format and click the “Erase” button. Your Fantom

Drives FireWire Disk Drive is ready to use!

Disk Format Considerations

Your Fantom drive comes with DrivePC, a FAT32 formatter utility as part of the Hard

Disk Speedtools Suite. Should you require cross platform compatibility with Windows,

please make sure to use DrivePC to partition and format your drive. Please take note

that MacOS will only recognize FAT32 partitions of up to 128GB in size, so please

create multiple partitions on drives bigger then 128GB.

Installation on a MacOS system requires MacOS 8.6 or greater. The FireWire drivers for

your product do not support operating systems earlier than MacOS 8.6. No Additional

software is necessary for installation under MacOS X. If your operating system is earlier

than MacOS 9.0.4, you may need to update your Apple FireWire extensions. Double

click the “Download FireWire Drivers” icon on your installation CD to link to Apple’s web

site, or visit http://www.apple.com to obtain the latest drivers.

Macintosh OS 9 and X

Installation-Hard Disk Drives

Hard Disk SpeedtoolsTM

Hard Disk SpeedtoolsTM Installer

• If you have a Blue and White G3, please make sure to update your rm-

ware and have version 1.1 or greater

• Final Cut users may need to tune the drive to use smaller packet size or

load size. Consult the HDST documentation for more information.

Installation-Hard Disk Drives

Installation on a Windows system requires Windows 98SE, Windows Millennium, Windows

2000, or Windows XP. FireWire and USB are not supported on Windows 95, earlier ver-

sions of Windows 98, or Windows NT 4.0 and earlier. No Additional software is necessary

for installation under Windows ME, Windows 2000, or Windows XP.

1.Before connecting your Fantom Drives Firewire Storage Device, please install one of

the following:

Connect and power on your Fantom Drive

and reboot your computer

3. Plug and Play will detect your Fantom

Drive and will install the necessary soft-

ware. Should any Version Conict dialog

boxes pop up, click YES to keep the

existing les. Do not click on the cancel

button, as this will prohibit the drivers

from loading properly. If Windows cannot

nd the driver, please download the appropriate

driver from www.fantomdrives.com/support/

swupdates.php4, decompress it to a temporary

directory, and direct Windows to that directory

in the driver installation dialog. These dialog

boxes will only display the rst time you install

your drive.

4. Right click on “My Computer” on your desktop,

and select Properties. Click on the Device

Manager tab (top illustration,) expand the “Disk

Drives” icon, locate and select the new device,

and click the “Properties” button.

Microsoft Windows

Windows 98/ME

Please be sure to have your Windows 98/ME installation CD available as it may be

required during installation. Please skip to step 4 for Windows ME installations.

FireWire: Please install the Microsoft 1394 Supplemental Storage Update (Microsoft

Support Document Q242975). This update can be downloaded from Microsoft or

from the Fantom Drives Support web page.

USB: please insert the included driver

CD-Rom and run “TPPINST.EXE”.

Select Complete Install, and reboot the

computer when prompted.

Drivers will only be required the rst time

you install your Fantom Drives disk

drive.

Installation-Hard Disk Drives

Disk Format Considerations

The two prevalent le system formats for PCs are FAT32 and NTFS. Performance is very

similar between the two systems.

NTFS is a newer le system that is compatible only with Windows NT, Windows 2000

and Windows XP. It has fewer limitations than FAT32 and will enable a partition to be

created that is larger than 32GB.

FAT32 is a le system that is compatible with Windows 98 SE, Windows Me, Windows

2000 and Windows XP; In Windows 2000 and Windows XP, you will not be able to

create a partition greater than 32GB.

Use FAT32 if:

• You will be dual booting/accessing data

with an Operating System other than

Windows NT/Windows 2000/XP.

• You may need the ability to dual boot

down the line. Once you have con-

verted a volume from NTFS to FAT32,

there is no going back. You can convert

from FAT32 to NTFS, but not the other

way around.

• You want to connect to a Mac and have

access to the data. Please note that

MacOS cannot support FAT32 partitions

greater than 128GB.

Use NTFS if:

• You want to encrypt les, assign per-

missions to les, or want to audit les

for access.

• You will be formatting partitions larger

than 32GB.

• You need to store individual les that

are larger than 4GB, or you use a

backup program that writes large

les.

• You need a ling system that can be

mirrored or structured like a RAID 5

conguration.

5. Under the “Settings” Tab, check the “removable” check box (bottom illustration.) With

the removable box checked, you will be able to assign the drive a new letter below (be

sure you select a letter that is not already in use by another drive).

6. Press the “OK” button and reboot. Your Fantom Drives Firewire Storage Device is

ready to use!

Windows 2000/XP Installations

Windows ME, 2000, and XP will auto detect your Fantom Drives Storage Devices and

mount them automatically!

To reach USB 2.0 speeds, you must have a computer or host adapter that

has USB 2.0 support. Your Fantom Drives storage device will autosense

the highest available connection speed.

Installation: Optical Drives

Installation on a Windows system requires Windows 98 or greater. The USB drivers for your

product do not support Windows 98/Windows NT4 or earlier. No Additional software is

necessary for installation under Windows ME, Windows 2000, or Windows XP.

Windows 98

Completing the Installation

1. Turn on your computer. Wait until startup has completed.

2. Plug in the power on your Fantom Drives optical drive and turn it on. Please conrm

that the Power LED comes on, indicating that the drive is powered up.

3. Connect the drive to the computer. Windows will detect the new device and load

Microsoft’s native driver for your Fantom Drive. If this driver was not installed during

the initial installation of Windows, you may be asked to insert your Windows

installation CD-ROM in your computer’s internal CD/DVD-ROM drive. After Windows

is done with the driver installation, you may be asked to restart your computer.

Your Fantom Drives DVD drive includes DVD authoring and archive software, which

allows you master digital video and data alike! Please take a moment to review the

Hardware requirements for different mastering applications:

USB: Before connecting your Fantom Drive, please install the driver on the

included CD-Rom. Please be sure to have your Windows 98 installation CD

available as it may be required during installation.

FIREWIRE: Before connecting your Fantom Drive, please install the Microsoft 1394

(Microsoft Support Document Q242975). This update can be downloaded from

Microsoft or from the Fantom Drives Support web page. Please be sure to have your

Windows 98 installation CD available as it may be required during installation.

I Want to I Need

Create a VCD Movie a 450MHz Pentium II or better

Create a DVD Movie a 700MHz Pentium III or better

Capture DV in real time and compress to MPEGI a 700MHz Pentium III or better

Capture DV in real time and compress to MPEG2 a 1.7GHz Pentium IV or better

Capture DV in real time and compress to AVI a 450MHz Pentium II or better

Capture Non real time video a 450MHz Pentium II or better

Microsoft Windows

Indice

Altri manuali Fantom Drives Magazzinaggio

Fantom Drives

Fantom Drives DataShield Pro Manuale utente

Fantom Drives

Fantom Drives GreenDrive Manuale di istruzioni

Fantom Drives

Fantom Drives MDE4000 Manuale di istruzioni

Fantom Drives

Fantom Drives GD1000EU Manuale utente

Fantom Drives

Fantom Drives eXtreme Thunderbolt 3 Manuale utente

Fantom Drives

Fantom Drives GF1000EU Manuale di istruzioni

Fantom Drives

Fantom Drives GF2000T Manuale di istruzioni

Fantom Drives

Fantom Drives MGT-08SC08A Manuale di installazione e funzionamento

Fantom Drives

Fantom Drives MDU1000 Manuale di istruzioni

Fantom Drives

Fantom Drives MTT160 Manuale di istruzioni

Fantom Drives

Fantom Drives TFD1000U16 Manuale di istruzioni

Fantom Drives

Fantom Drives GreenDrive Quad Manuale di istruzioni

Fantom Drives

Fantom Drives MGD-16FC16A Manuale utente

Fantom Drives

Fantom Drives Black Diamond Manuale di istruzioni

Fantom Drives

Fantom Drives Gforce 3 Manuale utente

Fantom Drives

Fantom Drives DataDock II Manuale utente

Fantom Drives

Fantom Drives GDII1000EU Manuale di istruzioni

Fantom Drives

Fantom Drives GF1000T Manuale di istruzioni

Fantom Drives

Fantom Drives GD1000EU Manuale di istruzioni

Fantom Drives

Fantom Drives MGD-16FC16S Manuale di installazione e funzionamento

Fantom Drives

Fantom Drives GF1000EU Manuale di istruzioni

Fantom Drives

Fantom Drives G-Force Megadisk Manuale di istruzioni

Fantom Drives

Fantom Drives G-Force Megadisk Manuale di istruzioni

Fantom Drives

Fantom Drives Gforce 3 Manuale di istruzioni

Manuali Magazzinaggio popolari di altre marche

QNAP

QNAP TS 32PXU Series Manuale utente

LaCie

LaCie RUGGED RAID Manuale utente

Freecom

Freecom CLS DOCK Manuale utente

PNY

PNY Attache P-FD64MBATT3 Manuale utente

HP StorageWorks MSL2024 Manuale utente

OLT

OLT 6x6 Maximizer Manuale utente

Transcend

Transcend JetFlash 160 Manuale utente

LaCie

LaCie RUGGED MINI Manuale utente

Thunderbolt

Thunderbolt 600 Manuale utente

Panasonic

Panasonic LB-DH8 series Manuale

Intel

Intel RAID High Availability Manuale utente

LaCie

LaCie 12big Thunderbolt 3 Manuale utente

Spectra Logic

Spectra Logic T-Series Spectra T50e Manuale utente

Panasonic

Panasonic LKM-F931-1 Manuale utente

Tabernus

Tabernus Enterprise Erase E2400 Manuale utente

Rocstor

Rocstor COMMANDER 3F series Manuale utente

HP P9000 Manuale utente

Western Digital

Western Digital Ultrastar Data60 Manuale utente
