Fanvil CS30 Manuale utente

USB/Bluetooth Speakerphone

User Manual

www.fanvil.com

Product introduction

USB/Bluetooth Speakerphone is an omni-directional microphone

and a bluetooth speaker.

It is used as a high-quality microphone and speaker for online meeting and

compatible with apps such as Zoom\Teams. Users can enjoy clear

remote conference experience anytime, anywhere.

Product introduction

Accessories List

Speakerphone

Instructions

Data cable

Product introduction

Buttons and lighting instructions

Phone Calls

Short press to answer/

hang up calls

Volume/power indicator

means on

means off

Volume indicator

Maximum volume

Minimum volume

Power indicator (short press on power button)

Power>80%

Power≤20%

Volume down

Short press to turn down the volume

Volume up

Short press to turn up the volume

Microphone

Mute

Short press to switch microphone status

Status Indicator

Red: Microphone mute

White: Microphone unmute

Product introduction

Buttons and lighting instructions

Power

Press and hold for 3 seconds to turn on or off the device

Status Indicator

Red light breathing: battery is below 10%

White light breathing: charging

White light on: battery full or not charging

*When the power is off and charging, the light goes off to indicate that it is full

Bluetooth

Press and hold for 2 seconds to pair

Short press to disconnect Bluetooth

Status Indicator

Blue flashing: Bluetooth pairing

Blue on: Bluetooth connected

Instructions for use

1. Device connection

* Method 1: USB connection

• Connect the device to the computer via the supplied USB cable, and when you

hear a hint tone, the connection is successful.

• Choose “Fanvil CS30” as the input/output audio device in system setting or in the

online meeting software.

* Method 2: Bluetooth connection

• Press the Bluetooth key for 2 seconds until the Bluetooth indicator

flashes. Then open the phone or PC Bluetooth setting page, search the Bluetooth

device “Fanvil CS30” for pairing; Click to connect.

• If you have an Android phone that supports NFC, turn on the NFC of the phone，

and touch the device's NFC area to connect to Bluetooth.

Tip: The current version does not support OTG data cable directly connected to the

phone

Instructions for use

2.Charging instructions

* Charging

•When using the USB cable to connect to the computer, the device will enter

the charging mode.

•If you use a power adapter to supply power, you should

purchase a power adapter that is FCC/CE certified and meets the requirements of

the standard.

Tip: Before using the device for the first time, it is recommended that charge at least

1 hour to ensure sufficient power.

Instructions for use

Product name

AI Meeting Box

Product model

CS30

Product dimensions

112.5mm x 112.5mm x 35.4mm

Bluetooth

Bluetooth V5.1

Pickup radius

4 meters/13 ft

Microphone

4 omnidirectional microphone

Loudspeaker

Battery capacity

2000mAh

Charging

5V—2A Type-C port

Frequently Asked Questions

Questions

Suggestions

The volume is not synchronized when the

device is connected to the phone by

Bluetooth

1.Confirm whether the phone supports Bluetooth

sound synchronization, some Android phones do not

support volume synchronization.

2.Some phone needs to open the volume setting

permission in the system settings.

When the device is connected to the phone

by Bluetooth, the ringtone of phone

calls does not come out from the device

1.Check whether the phone volume is turned on,

or the volume is too low.

2.Check whether the device can speak normally.

3.Choose audio input/output in the

meeting software.

No sound when device is connected to

Windows PC by Bluetooth

1.It is recommended that when playing music,

select the speaker with the name “stereo”

on your PC.

2.It is recommended to choose the speaker with the

name “hand free” for the audio output speaker during

the call or meeting.

No sound when the device is connected to

FaceTime/ Zoom/Teams/Google

Hangouts etc. by Bluetooth

1.Check whether the input /output of the call

software are properly set to “Fanvil CS30”.

2.Check whether the computer audio driver

is normal, it is recommended to restart

the computer and try again.

No response when the device

is connected to the computer using USB

1.Check whether the device is connected

to phone, please disconnect the connection

first, and then use the cable to connect the device.

2.Check whether the USB data cable is damaged.

3.Reboot the device and try again.

Fanvil Technology Co., Ltd

Website: www.fanvil.com

EMail: sales@fanvil.com support@fanvil.com

Tel: +86-755-2640-2199 Fax: +86-755-2640-2618

Add: 10/F Block A, Dualshine Global Science Innovation

Center, Honglang North 2nd Road, Bao'an District, Shenzhen,

China
