Farenheit NE-S110N Manuale utente

NE-S110N

OPERATION MANUAL

11 Inch Headrest TFT-LCD Monitor

DC 12~14.4V

11 TFT LCD

16:9 Wide

2400*480

Video Input 2EA

(L)11 (W)7.7 (H)1.7inch

NTSC/PAL Auto Select

Power Requirements

Power Consumption

Screen Size

Screen Format

Resolution Pixel

A/V Inputs

Dimensions

Compatible video standard

*Although the effective pixels for the liquid crystal panel is given as

99.98% or more, 0.02% of pixels may not light or may light incorrectly.

Specifications

Caution 3

Installatlon 4

Operation Function 5

Remote

Picture Control 7

Connections 8

Troubleshooting check list 9

Specifications 10

Function 6

Thank you for your purchase.

Please read this user,s Manual in detail and use the set properly.

Contents

Troubleshooting check list

*Please make these simple checks before calling for assistance.

*If the TV is to be used in conjunction with any other equipment,

read the other product,s instruction manual.

*If you choose not follow the below checklist or any problems

you are experiencing with this product are not solved, never

attempt to repair a defective monitor yourself. Check with your

dealer .

*Power cord inserted into power source incorrectly.

*Another product,s cord inserted into TV incorrectly.

*Check the signal in AV mode.

*Adjust the contrast and brightness settings.

*Check whether the batteries have sufficient power. Replace if

necessary.

*Check whether the batteries are correctly installed in the remote

control.

*Check the remote control sensor lens on the monitor and the distance

and angle on the remote control(2m,30 ).

No picture & no sound

No picture

Monitor not responding to remote control

The driver should never operate the monitor while driving.

This can cause an accident.

Do not disassemble the device.

Use proper volume while driving.

Get advice from a qualified engineer to set up the monitor.

Do not watch monitor for long periods of time while the

stopped engine.

Protect the LCD Panel from falling or being impacted.

Do not recharge, disassemble and protect from the heat

the remote control battery.

Keep remote control battery away from children.

Use only soft cloth with non-ammonia glass cleaner to clean

the panel.

1 The range of preservation temperature for the device is from -20 to 70

Be cautious aware that the inside temperature of car may arise up to 100 in summer time.

2 The monitor picture may not be displayed normally when it is higher or lower than

recommended temperature.

In this case, the screen will be back normal condition after few minutes.

The range of recommended temperature for the device is from 0 to 40 .

3 You can have the best picture when you are in front of the monitor.

(Visual Angle)

45 45

Check Point

Read this page in detail in order to protect your safety

as well as others.

Connections

Caution

VIDEO 1

EXTERNAL DEVICE

VIDEO 2

RED BLACK

FUSE

to +12 VDC Battery to Chassis Ground R

VIDEO

Please mount the monitor where it make you have the best picture.

Installation

Picture Control

To adjust CONTRAST, BRIGHTNESS, COLOR press the MENU button until you

arrive at the screen for that item. Use the and buttons to adjust the value.

Press the buttons to make another adjustment. P leave

the MENU system.

and ress the MENU to

Contrast/Brightness/Color

1. Bring up the on-screen function menu by pressing the MENU button on the

remote control.

2. Press the and buttons on the remote control of monitor until you see the

item you wish to adjust.

3. Use the and buttons to adjust the value.

4. Press the MENU button to leave the MENU system.

REMOTE CONTROL SENSOR POWER ON/ OFF

POWER

AV1/AV2

LCD MONITOR

REMOTE CONTROL UNIT

Power: Power ON/OFF.

AV: AV1/AV2 Signal Select.

Menu: Press this button for OSD menu.

: Use the and buttons to increase current

option value or decrease current option value.

: Use the and buttons to select menu option.

Remote Function

Operation Function

2 1

REMOTE CONTROL SENSOR POWER ON/ OFF
