Fein WSG 7-100 Guida all'installazione
WSG 7-100; WSG 7-115; WSG 7-115 (A); WSG 7-115 PT; WSG 7-125
Repair instructions
C-SC_CSSM
Version 1.0
2019-07-05
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 1of 45
WSG 7-100; WSG 7-115; WSG 7-115 (A); WSG 7-115 PT; WSG 7-125
Contents
C-SC_CSSM
Version 1.0
2019-07-05
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 2of 45
1. Models described
2. Technical data
3. Notes and requirements
4. Tools required
5. Lubricants and auxiliary substances required
6. Removal
7. Fitting
8. Connection diagram
WSG 7-100; WSG 7-115; WSG 7-115 (A); WSG 7-115 PT; WSG 7-125
1. Models described
C-SC_CSSM
Version 1.0
2019-07-05
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 3of 45
These repair instructions describe how to repair the following models:
Model Order number
WSG 7-100 7 221 96 .. .. .
WSG 7-115 7 221 97 .. .. .
WSG 7-115 (A) 7 221 98 .. .. .
WSG 7 115 PT 7 222 31 .. .. .
WSG 7-125 7 222 65 .. .. .
WSG 7-100; WSG 7-115; WSG 7-115 (A); WSG 7-115 PT; WSG 7-125
2. Technical data
C-SC_CSSM
Version 1.0
2019-07-05
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 4of 45
Technical data
All the technical data can be found in the operating instructions for the model.
Tests
Up-to-date test data and test instructions after repair can be found on the FEIN Extranet (Customer Service → Repair Guides).
Lubricants / Auxiliary substances
The lubricants or auxiliary substances and their container sizes available from FEIN can be found on the FEIN Extranet
(Customer Service → Repair Guides).
Lists of spare parts
Lists of spare parts and exploded views are available online at www.fein.com
WSG 7-100; WSG 7-115; WSG 7-115 (A); WSG 7-115 PT; WSG 7-125
3. Notes and requirements
C-SC_CSSM
Version 1.0
2019-07-05
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 5of 45
Please note
These instructions are only intended for persons with suitable technical training. It is assumed that the reader has mechanical and
electrical training.
Only use original FEIN spare parts!
Provisions
Please note that power tools may only be repaired, maintained and checked by a trained electrician, as improper repair can result in
serious risks to the user.
The provisions set out in DIN VDE 0701-0702 should be observed after repairs.
The relevant accident prevention regulations of the employer’s liability insurance associations are to be observed when
commissioning.
The German Equipment and Product Safety Act [ProdSG] applies for correct use.
Outside Germany, the regulations applicable in the relevant country must be observed!
WSG 7-100; WSG 7-115; WSG 7-115 (A); WSG 7-115 PT; WSG 7-125
4. Tools required
C-SC_CSSM
Version 1.0
2019-07-05
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 6of 45
Standard tools
Special tools
PH2 cross-tip screwdriver Drawing-off socket cap 6 41 04 150 00 8
Flat-nose pliers Chuck cone 19 mm 6 41 07 019 00 7
Slotted screwdriver Assembly aid 6 41 22 121 01 0
Plastic hammer Pressure piece 6 41 22 128 00 0
Hot air gun
Socket wrench
Socket wrench insert 10 mm
Punch Dia. 9 mm; dia. 17 mm
2x flat material 2 mm
Arbor press
Puller 6-10 mm
Sleeves
•55 mm inner diameter
65 mm outer diameter
•45 mm inner diameter
62 mm outer diameter
•32 mm inner diameter
40 mm outer diameter
WSG 7-100; WSG 7-115; WSG 7-115 (A); WSG 7-115 PT; WSG 7-125
4. Tools required
C-SC_CSSM
Version 1.0
2019-07-05
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 7of 45
Standard tools
Sleeves
•22 mm inner diameter
33 mm outer diameter
•17 mm inner diameter
33 mm outer diameter
•9 mm inner diameter
22 mm outer diameter
•12 mm inner diameter
22 mm outer diameter
•16 mm inner diameter
30 mm outer diameter
Bolt
Dia. 18 mm
WSG 7-100; WSG 7-115; WSG 7-115 (A); WSG 7-115 PT; WSG 7-125
5. Lubricants and auxiliary substances required
C-SC_CSSM
Version 1.0
2019-07-05
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 8of 45
Lubricants
Grease 0 40 12 901 00 0 10 g Gearbox housing
WSG 7-100; WSG 7-115; WSG 7-115 (A); WSG 7-115 PT; WSG 7-125
6. Removal
C-SC_CSSM
Version 1.0
2019-07-05
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 9of 45
Removing the cover
1. Unscrew the screw (1).
2. Pull off the cover.
Tools:
- PH2 cross-tip
screwdriver
1
WSG 7-100; WSG 7-115; WSG 7-115 (A); WSG 7-115 PT; WSG 7-125
6. Removal
C-SC_CSSM
Version 1.0
2019-07-05
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 10 of 45
Removing the cover [applies to: WSG 7-115 PT]
1. Unscrew the two screws (1).
2. Remove the cover (2).
3. Remove the control rod (3).
4. Remove the cover (4).
Tools:
- PH2 cross-tip
screwdriver
1
2
3
4
